A/t oil cooler & tube (W/TURBO..2WD) Diagram Mitsubishi EK-SERIES
- Year
- 2006 - 2009
- Sales region
- Japan
- Note
- R/SOUND BEAT ED R(2WD/TURBO),4A/T<SPORT>
- drive
- 2WD
- grade
- R/SOUND BEAT ED
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
25878A
|
25878A
MN135367 TUBE ASSY, T/M OIL COOLER LINE |
MN135367 |
US $16.28 |
||
|
25887B
|
25887B
2922A288 HOSE, T/M OIL COOLER LINE |
2922A288 |
US $28.86 |
||
|
25887B
|
25887B
2922A382 HOSE, T/M OIL COOLER LINE |
2922A382 |
US $28.86 |
||
|
25887B
|
25887B
MN114166 HOSE, T/M OIL COOLER LINE |
MN114166 |
US $45.14 |
||
|
25887D
|
25887D
MN135380 HOSE, T/M OIL COOLER LINE |
MN135380 |
US $11.54 |
||
|
25887E
|
25887E
MN114170 HOSE, T/M OIL COOLER LINE |
MN114170 |
US $8.29 |
||
|
25892
|
25892
MR204390
CLIP, T/M OIL COOLER LINE
|
MR204390 |
— | ||
| replacement | |||||
|
25892
|
25892
MR281416 CLIP, T/M OIL COOLER LINED=13.5 |
MR281416 |
from US $1.81 |
||
|
25897B
|
25897B
MF140005 BOLT, ROCKER COVERFlange,6x16 |
MF140005 |
from US $0.41 |
||
|
25897B
|
25897B
MS240125 BOLT, FUEL TANKWasher assembled,8x20 |
MS240125 |
from US $1.05 |
||
|
14 010
|
Radiator,hose & condenser tank
14 010
|
||||
|
23 110
|
A/t case
23 110
|
||||
|
23 110
|
A/t case
23 110
|
||||
