Front wheel brake (ALL) Diagram Mitsubishi L300
- Year
- -
- Sales region
- EUR
- Note
- DX(3DOOR),4CM/T RHD
- drive
- 2WD
- transmission
- 4CM/T
- grade
- DX
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
51026
|
51026
MV026287 CAP, GEARSHIFT LINK |
MV026287 |
from US $2.81 |
||
|
51201
|
51201
MB366146
BLEEDER, FR BRAKE CALIPER
|
MB366146 |
— | ||
| replacement | |||||
|
51201
|
51201
4610A018 BLEEDER, RR BRAKE CYLINDER |
4610A018 |
from US $7.59 |
||
|
51230
|
51230
MB193627 CUP & BOOT KIT, FR BRAKE CYLINDER |
MB193627 |
US $13.47 |
||
|
51250AL
|
51250AL
MB500860
CYLINDER ASSY, FR BRAKE, LH
|
MB500860 |
— | ||
|
51250AL
|
51250AL
MB500862 CYLINDER ASSY, FR BRAKE, LH |
MB500862 |
US $173.16 |
||
|
51250AR
|
51250AR
MB500861 CYLINDER ASSY, FR BRAKE, RH |
MB500861 |
US $173.16 |
||
|
51250AR
|
51250AR
MB500863 CYLINDER ASSY, FR BRAKE, RH |
MB500863 |
US $173.16 |
||
|
51301L
|
51301L
MT372145 ADJUSTER, FR BRAKE SHOE SLACK, LH |
MT372145 |
US $34.04 |
||
|
51301R
|
51301R
MT372146 ADJUSTER, FR BRAKE SHOE SLACK, RH |
MT372146 |
US $34.04 |
||
|
51314
|
51314
MT100169 CUP, PARKING BRAKE SHOE HOLD-DOWN SPRING |
MT100169 |
from US $2.46 |
||
|
51347AL
|
51347AL
MB316608 SHOE ASSY, FR BRAKE PRIMARY |
MB316608 |
US $36.26 |
||
|
51347AL
|
51347AL
MB316609 SHOE ASSY, FR BRAKE SECONDARY |
MB316609 |
US $36.26 |
||
|
51347AR
|
51347AR
MB316608 SHOE ASSY, FR BRAKE PRIMARY |
MB316608 |
US $36.26 |
||
|
51347AR
|
51347AR
MB316609 SHOE ASSY, FR BRAKE SECONDARY |
MB316609 |
US $36.26 |
||
|
51353
|
51353
MT141423 SPRING, FR BRAKE SHOE HOLD-DOWN |
MT141423 |
US $2.96 |
||
|
51354
|
51354
MT141421 SPRING, FR BRAKE SHOE RETURN |
MT141421 |
US $5.33 |
||
|
51356L
|
51356L
MT141428 STOPPER, FR BRAKE SHOE SLACK ADJUSTER, LH |
MT141428 |
US $7.84 |
||
|
51356R
|
51356R
MT141429 STOPPER, FR BRAKE SHOE SLACK ADJUSTER, RH |
MT141429 |
US $7.84 |
||
|
51812L
|
51812L
MB134996 COVER, FR BRAKE BACKING PLATE, LH |
MB134996 |
US $7.55 |
||
|
51812R
|
51812R
MB134997 COVER, FR BRAKE BACKING PLATE, RH |
MB134997 |
US $7.55 |
||
|
51822L
|
51822L
MB534290 PLATE, FR BRAKE BACKING, LH |
MB534290 |
US $161.32 |
||
|
51822R
|
51822R
MB534291 PLATE, FR BRAKE BACKING, RH |
MB534291 |
US $161.32 |
||
|
51969B
|
51969B
MB004359 SCREW, RADIATOR SHROUDWasher assembled,4x6 |
MB004359 |
US $3.70 |
||
|
51969C
|
51969C
MT141413 SCREW, FR BRAKE |
MT141413 |
US $14.21 |
||
|
51969C
|
51969C
MT141414 SCREW, FR BRAKE |
MT141414 |
US $12.14 |
||
|
51971B
|
51971B
MF399105 WASHER, FUEL TANKSpring,8 |
MF399105 |
US $1.63 |
||
|
51971F
|
51971F
MS450043 WASHER, ENG RR MOUNTINGSpring,10 |
MS450043 |
from US $1.76 |
||
|
51972
|
51972
MT324490
DAMPER, FR BRAKE CYLINDER TUBE
|
MT324490 |
— | ||
|
51977B
|
51977B
MB058160 PLUG, FR BRAKE |
MB058160 |
US $9.47 |
||
|
51978B
|
51978B
MF430005 NUT, ROCKER COVER8 |
MF430005 |
from US $1.01 |
||
|
51978F
|
51978F
MF430122 NUT, ENG RR MOUNTING10 |
MF430122 |
from US $0.72 |
||
|
51986B
|
51986B
MJ807374 PIN, FR BRAKE |
MJ807374 |
US $5.03 |
||
|
51987B
|
51987B
MB058535 BOLT, FR WHEEL HUB10x26.5 |
MB058535 |
US $3.55 |
||
|
51987H
|
51987H
MB134533 BOLT, FR AXLE CROSSMEMBER10x40 |
MB134533 |
US $5.34 |
||
|
51987J
|
51987J
MB081727 BOLT, FR WHEEL HUB10x51 |
MB081727 |
from US $1.83 |
||
|
56271
|
56271
MB134998 TUBE, FR BRAKE CYLINDER CONNECTING |
MB134998 |
US $13.02 |
||
