Brake & clutch pedal (LHD..A/T) Diagram Mitsubishi LANCER
- Year
- 1992 - 1996
- Sales region
- EUR
- Note
- GLI,4FA/T LHD
- drive
- 2WD
- transmission
- 4FA/T
- grade
- GLI
- body
- SEDAN
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
53007B
|
53007B
MB003682 BUSHING, CLUTCH PEDAL14x10 |
MB003682 |
from US $2.40 |
||
|
53007B
|
53007B
MB500966 BUSHING, BRAKE PEDAL14x10 |
MB500966 |
US $4.14 |
||
|
53010
|
53010
MA152260 PAD, BRAKE PEDAL61x112 |
MA152260 |
from US $5.19 |
||
|
53010
|
53010
MB599609 PAD, BRAKE PEDAL61x132 |
MB599609 |
from US $4.43 |
||
|
53012
|
53012
MB807256
PEDAL,BRAKE
|
MB807256 |
— | ||
|
53034
|
53034
MB911101
SPRING,BRAKE PEDAL RETURN
|
MB911101 |
— | ||
|
53035
|
53035
MB500595 STOPPER, BRAKE PEDAL |
MB500595 |
US $3.55 |
||
|
53038
|
53038
MB807265
LEVER,CLUTCH CABLE
|
MB807265 |
— | ||
|
53084
|
53084
MF450406 WASHERSpring,10 |
MF450406 |
from US $0.43 |
||
|
53092
|
53092
MF430006 NUT10 |
MF430006 |
from US $1.35 |
||
|
53098B
|
53098B
MS240125 BOLT, FUEL TANKWasher assembled,8x20 |
MS240125 |
from US $1.05 |
||
|
53098B
|
53098B
MS240139 BOLT, STEERING COLUMNWasher assembled,8x20 |
MS240139 |
from US $1.23 |
||
|
53098C
|
53098C
MB911455
BOLT,BRAKE PEDAL
|
MB911455 |
— | ||
|
53305
|
53305
MB911503
MEMBER,PEDAL SUPPORT
|
MB911503 |
— | ||
|
82110
|
82110
MB435457 SWITCH, STOP LAMP |
MB435457 |
from US $9.52 |
