Panel van body (FRONT DOOR..RH) Diagram Mitsubishi MINICA
- Year
- 1990 - 1995
- Sales region
- Japan
- Note
- WALK-THROUGH VAN(4WD/2SEATER),5FM/T
- drive
- 4WD/4WD
- transmission
- 5FM/T
- grade
- WALK-THROUGH
- body
- VAN
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
67019B
|
67019B
MB177555
BOLT, FR DOOR HINGE
|
MB177555 |
— | ||
|
67019C
|
67019C
MS240216 BOLT, ENG MOUNTINGWasher assembled,10x25 |
MS240216 |
US $2.60 |
||
|
67020AR
|
67020AR
MB593174 PANEL ASSY, FR DOOR, RH |
MB593174 |
US $2,016 |
||
|
67033
|
67033
MB800134 SHIM, FR DOOR HINGE |
MB800134 |
US $9.62 |
||
|
67033
|
67033
MB800135 SHIM, FR DOOR HINGE |
MB800135 |
US $9.62 |
||
|
67033
|
67033
MB800136 SHIM, FR DOOR HINGE |
MB800136 |
US $9.62 |
||
|
67040R
|
67040R
MB593762 HINGE, FR DOOR, RH |
MB593762 |
US $43.66 |
||
|
67050R
|
67050R
MB593762 HINGE, FR DOOR, RH |
MB593762 |
US $43.66 |
||
|
67323
|
67323
MB567849 HANDLE, FR DOOR PULL |
MB567849 |
US $11.40 |
||
|
67414
|
67414
MB704298 POCKET, FR DOOR |
MB704298 |
US $28.12 |
||
|
67414
|
67414
MB772427 POCKET, FR DOOR |
MB772427 |
US $34.04 |
||
|
67421R
|
67421R
MB766385 TRIM, FR DOOR, RH |
MB766385 |
US $149.48 |
||
|
67441R
|
67441R
MB671187 WEATHERSTRIP, FR DOOR OPENING, RH |
MB671187 |
US $155.40 |
||
|
67441R
|
67441R
MB671188 WEATHERSTRIP, FR DOOR OPENING, RH |
MB671188 |
US $182.04 |
||
|
67485
|
67485
MF450003 WASHER, EXTERIOR MARKPlain,5 |
MF450003 |
from US $0.82 |
||
|
67488
|
67488
MB199327 SCREW, FR DOOR TRIMTapping,4x12 |
MB199327 |
US $2.37 |
||
|
67496
|
67496
MB634371 CLIP, FR DOOR TRIM |
MB634371 |
US $2.96 |
||
|
67596
|
67596
MS450935 SCREW, RR DOOR LOCKINGTapping,6x25 |
MS450935 |
US $2.52 |
||
|
67598
|
67598
MS480003 GROMMET, FUEL FILLER LID PANELScrew,6 |
MS480003 |
from US $1.11 |
||
|
67752
|
67752
MB800137 WEATHERSTRIP, FR DOOR, UPR |
MB800137 |
US $22.94 |
