Front bumper & support (ALL) Diagram Mitsubishi PAJERO/MONTERO
- Year
- 1997
- Sales region
- Japan
- Note
- EVOLUTION,5FM/T
- transmission
- 5FM/T
- grade
- EVOLUTION
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
62000
|
62000
MR392785
FACE KIT, FR BUMPER
|
MR392785 |
— | ||
| replacement | |||||
|
62000
|
62000
MR555631 FACE KIT, FR BUMPER |
MR555631 |
US $731.43 |
||
|
62000
|
62000
MR392787 BUMPER KIT, FR CORNER |
MR392787 |
US $1,172.08 |
||
|
62000
|
62000
MR414902 BUMPER KIT, FR CORNER |
MR414902 |
US $1,172.08 |
||
|
62000
|
62000
MR555631 FACE KIT, FR BUMPER |
MR555631 |
US $731.43 |
||
|
62002L
|
62002L
MR419219
BRACKET, FR BUMPER SIDE, LH
|
MR419219 |
— | ||
|
62002R
|
62002R
MR419220 BRACKET, FR BUMPER SIDE, RH |
MR419220 |
US $73.87 |
||
|
62012L
|
62012L
MB930707 BRACKET, FR BUMPER MOUNTING, LH |
MB930707 |
US $87.32 |
||
|
62012R
|
62012R
MB930708 BRACKET, FR BUMPER MOUNTING, RH |
MB930708 |
US $87.32 |
||
|
62015
|
62015
MR419682
BRACKET, FR BUMPER, CTR
|
MR419682 |
— | ||
|
62022B
|
62022B
MB121032 CLIP, FR BUMPER9x11 |
MB121032 |
from US $2.13 |
||
|
62022D
|
62022D
MB115492 CLIP, AIR CLEANER5.4 |
MB115492 |
from US $1.62 |
||
|
62035
|
62035
MR365339 NET, FR BUMPER |
MR365339 |
US $113.54 |
||
|
62054
|
62054
MR371696 REINFORCEMENT, FR BUMPER |
MR371696 |
US $455.62 |
||
|
62986E
|
62986E
MF351668
SCREW, ACCEL CONTROL EQUIP
|
MF351668 |
— | ||
|
62986F
|
62986F
MF351690
SCREW, ABS CONTROL EQUIP
|
MF351690 |
— | ||
|
62986G
|
62986G
MS452352 SCREW, A/C PIPINGWasher assembled,5x16 |
MS452352 |
from US $0.21 |
||
|
62986G
|
62986G
MU468001
SCREW, FR BUMPER
|
MU468001 |
— | ||
|
62989C
|
62989C
MS440523 NUT, FUEL TANKWasher assembled,8 |
MS440523 |
from US $0.70 |
||
|
62994D
|
62994D
MU242004
BOLT, FR BUMPER
|
MU242004 |
— | ||
|
62994J
|
62994J
MS240122 BOLT, ENG FR MOUNTINGWasher assembled,6x20 |
MS240122 |
from US $0.84 |
||
|
62994K
|
62994K
MS240180 BOLT, FR BUMPERWasher assembled,8x20 |
MS240180 |
from US $1.31 |
||
|
62994N
|
62994N
MU140009 BOLT, FR BUMPERFlange,6x20 |
MU140009 |
from US $1.23 |
||
|
62994P
|
62994P
MS240582 BOLT, ENG WIRINGWasher assembled,6x20 |
MS240582 |
US $2.46 |
||
|
99338
|
99338
MZ101810
TOUCH-UP PAINT (Cannot supply)
|
MZ101810 |
— | ||
|
99338
|
99338
MZ101933
TOUCH-UP PAINT
|
MZ101933 |
— | ||
|
99338
|
99338
MZ101974
TOUCH-UP PAINT
|
MZ101974 |
— | ||
