Emission control (CARBURETOR (SWITZERLAND,SWEDEN)) Diagram Mitsubishi SPACE WAGON
- Year
- 1986 - 1988
- Sales region
- EUR
- Note
- GLX(ANTI-POLL),5FM/T LHD
- drive
- 2WD
- transmission
- 5FM/T
- grade
- GLX
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
05618
|
05618
MD026678 VALVE, PURGE CONTROL |
MD026678 |
US $25.90 |
||
|
05622
|
05622
MD015783 PIPE, FUEL VAPOR |
MD015783 |
US $15.54 |
||
|
12400
|
12400
MD026551
VALVE,EGR
|
MD026551 |
— | ||
|
12400
|
12400
MD132997
VALVE,EGR
|
MD132997 |
— | ||
|
12402
|
12402
MD076431 BRACKET, EMISSION VACUUM CONTROL SWITCH |
MD076431 |
US $25.90 |
||
|
12410
|
12410
MD026567 GASKET, EGR VALVE |
MD026567 |
US $2.74 |
||
|
12410
|
12410
MD088604
GASKET, EGR VALVE
|
MD088604 |
— | ||
| replacement | |||||
|
12410
|
12410
MD119127 GASKET, EGR VALVE |
MD119127 |
from US $2.42 |
||
|
12413A
|
12413A
MD108191
HOSE ASSY,EMISSION VACUUM CONTROL
|
MD108191 |
— | ||
|
12414
|
12414
MD090629
SUB HARNESS,EMISSION SOLENOID
|
MD090629 |
— | ||
|
12415
|
12415
MD075624 SWITCH, EMISSION VACUUM CONTROL |
MD075624 |
US $93.24 |
||
|
12416
|
12416
MD073096
THERMO-VALVE,EMISSION CONTROL
|
MD073096 |
— | ||
|
12416
|
12416
MD103867
THERMO-VALVE, EMISSION CONTROL
|
MD103867 |
— | ||
|
12421A
|
12421A
MD088432
VALVE,EMISSION SOLENOID
|
MD088432 |
— | ||
|
12421A
|
12421A
MD138871
VALVE,EMISSION SOLENOID
|
MD138871 |
— | ||
|
12421P
|
12421P
MD084955 VALVE, EMISSION SOLENOID |
MD084955 |
US $159.84 |
||
|
12421Q
|
12421Q
MD084954 VALVE, EMISSION SOLENOID |
MD084954 |
US $164.28 |
||
|
12421S
|
12421S
MD085014 VALVE, EMISSION SOLENOID |
MD085014 |
US $71.04 |
||
|
12954
|
12954
MF247222 BOLT, FUEL TANK PROTECTORWasher assembled,6x12 |
MF247222 |
from US $0.76 |
||
|
12963
|
12963
MF430005 NUT, ROCKER COVER8 |
MF430005 |
from US $1.01 |
||
|
12964
|
12964
MS605746 HOSE, FUEL TANK8x2000 |
MS605746 |
US $45.14 |
||
|
12965
|
12965
MS660164 CLAMP, T/M OIL COOLER LINED=13.1 |
MS660164 |
from US $1.13 |
||
|
12965
|
12965
MS660240 CLIP, ROCKER COVERD=13.1 |
MS660240 |
from US $0.86 |
||
|
12972
|
12972
MF140021 BOLT, ACCEL CABLE SUPPORTFlange,8x12 |
MF140021 |
from US $0.43 |
||
|
12978
|
12978
MF140023 BOLT, ACCEL CABLE SUPPORTFlange,8x16 |
MF140023 |
from US $0.53 |
||
|
12979
|
12979
MB249338 BAND, ROCKER COVERL=129.5 |
MB249338 |
US $2.87 |
||
|
12979
|
12979
MB249339 BAND, ENG BREATHERL=169.5 |
MB249339 |
from US $1.50 |
||
|
12988
|
12988
MF241236 BOLT, ENG OIL PUMPWasher assembled,6x45 |
MF241236 |
US $1.78 |
||
|
12988
|
12988
MF241263 BOLT, BALANCER BELT TRAINWasher assembled,8x50 |
MF241263 |
US $1.50 |
||
