Front suspension (1981-12-01 ~ ; $スプリング & ショックアブソーバー; LB) Diagram Nissan ATLAS/CONDOR
- Year
- 1983 - 1986
- Sales region
- Japan
- Engine
- Z20D
- transmission
- MT
- body
- TH
- body type
- SB/2T
- transmission/shift type
- R5
- tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
0811082510
|
0811082510
08110-82510
Bolt-hexagon
|
08110-82510 |
— | ||
|
0811402010
|
0811402010
08114-02010
Bolt-hexagon
|
08114-02010 |
— | ||
|
0891110810
|
0891110810
08911-10810
NUT
|
08911-10810 |
— | ||
| replacement | |||||
|
0891110810
|
0891110810
089111082A NUTHEX |
089111082A |
US $0.52 |
||
|
0891114410
|
0891114410
08911-14410
NUTHEX
|
08911-14410 |
— | ||
|
0891114610
|
0891114610
08911-14610
ﾅﾂﾄ,ﾍｸｻｺﾞﾝ
|
08911-14610 |
— | ||
|
0891124410
|
0891124410
08911-24410
ﾅﾂﾄ,ﾍｸｻｺﾞﾝ
|
08911-24410 |
— | ||
|
0891124410
|
0891124410
08911-24410
ﾅﾂﾄ,ﾍｸｻｺﾞﾝ
|
08911-24410 |
— | ||
|
0891124610
|
0891124610
08911-24610
ﾅﾂﾄ,ﾍｸｻｺﾞﾝ
|
08911-24610 |
— | ||
|
0891274010
|
0891274010
08912-74010 NUTHEX |
08912-74010 |
from US $0.52 |
||
|
0891513810
|
0891513810
08915-13810
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
08915-13810 |
— | ||
|
0891514010
|
0891514010
08915-14010
WASHER-LOCK
|
08915-14010 |
— | ||
| replacement | |||||
|
0891514010
|
0891514010
089151401A Washer-Lock |
089151401A |
from US $0.59 |
||
|
0891514410
|
0891514410
08915-14410
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
08915-14410 |
— | ||
|
0891514610
|
0891514610
08915-14610
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
08915-14610 |
— | ||
|
0891524410
|
0891524410
08915-24410
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
08915-24410 |
— | ||
|
0891524610
|
0891524610
08915-24610
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
08915-24610 |
— | ||
|
54009
|
54009
54009-T8201 Spring-Front, Lh8905--01 ~ 9006--01; 3SB.TL#.(Z20#+TD27) SB.TL#.BD30 SB.TH.ST+WC; [B502] |
54009-T8201 |
US $882.17 |
||
|
54009
|
54009
54010-T8201 Spring-Front, Lh8312--01 ~ 8611--01; Z20D+Z20S-TH.WT SD25; H=152.4[B502] |
54010-T8201 |
US $882.17 |
||
|
54010
|
54010
54009-T8200 Spring-Front, Rh8206--01 ~ 8312--01; Z20#-TH.WT; [B502] |
54009-T8200 |
US $882.17 |
||
|
54010
|
54010
54009-T8201 Spring-Front, Lh8312--01 ~ 8611--01; Z20#-TH.WT SD25.2T; H=164.4[B502] |
54009-T8201 |
US $882.17 |
||
|
54010
|
54010
54010-T8201 Spring-Front, Lh8905--01 ~ 9006--01; 3SB.TL#.(Z20#+TD27) SB.TL#.BD30 SB.TH.ST+WC; [B502] |
54010-T8201 |
US $882.17 |
||
|
54010
|
54010
54010-T9416 Spring-Front, Lh8905--01 ~ 9006--01; "SB.TH# +WC +DP +VC +F *LB.(TLF+TH); H=150.5 *=ﾊ-ﾄﾞ ｻｽﾍﾟﾝｼﾖﾝ[B502] |
54010-T9416 |
US $882.17 |
||
|
54026
|
54026
54026-T8000 Spacer-Spring8112--01 ~ 8301--01; ALL; ｾﾝﾀｸ T=3.2 T=3.2 |
54026-T8000 |
US $12.10 |
||
|
54026
|
54026
54026-T8001 Spacer-Spring8112--01 ~ 8301--01; ALL; ｾﾝﾀｸ T=5.6 T=5.6 |
54026-T8001 |
US $11.95 |
||
|
54026
|
54026
54026-T8002 Spacer-Spring8301--01 ~ ; ALL; ｾﾝﾀｸ T=3.2 |
54026-T8002 |
US $9.22 |
||
|
54026
|
54026
54026-T8003 Spacer-Spring8301--01 ~ ; ALL; ｾﾝﾀｸ T=5.6 |
54026-T8003 |
US $11.81 |
||
|
54041
|
54041
35129-4401P Bush-Rubber8112--01 ~ 8611--01; ALL |
35129-4401P |
from US $3.85 |
||
|
54041
|
54041
55046S9000 Bush-Rubber8611--01 ~ ; ALL |
55046S9000 |
US $10.95 |
||
|
54041
|
54041
35129-4401P Bush-Rubber8112--01 ~ 8611--01; ALL |
35129-4401P |
from US $3.85 |
||
|
54041
|
54041
55046S9000 Bush-Rubber8611--01 ~ ; ALL |
55046S9000 |
US $10.95 |
||
|
54041
|
54041
35129-4401P Bush-Rubber8112--01 ~ 8611--01; ALL |
35129-4401P |
from US $3.85 |
||
|
54041
|
54041
55046S9000 Bush-Rubber8611--01 ~ ; ALL |
55046S9000 |
US $10.95 |
||
|
54041
|
54041
35129-4401P Bush-Rubber8112--01 ~ 8611--01; ALL |
35129-4401P |
from US $3.85 |
||
|
54041
|
54041
55046S9000 Bush-Rubber8611--01 ~ ; ALL |
55046S9000 |
US $10.95 |
||
|
54050
|
54050
54050-T8001 Bumper Assy-Bound, Rh8112--01 ~ 8212--01; Z20S+SB.(TL,TH.ST); F/RH&LH |
54050-T8001 |
US $44.21 |
||
|
54050
|
54050
54050-T8002 Bumper Assy-Bound, Rh8406--01 ~ 8611--01; 'SB.TH#.TH.2T+WC+VC SB.TL#.(ST,Z20#.WT); F/RH&LH |
54050-T8002 |
US $37.15 |
||
|
54052
|
54052
54054-T8005 Seat-Front Spring8611--01 ~ 8905--01; 1SB.TL# SB.TH#.TH.ST SB.DP.TLF |
54054-T8005 |
US $16.42 |
||
|
54052
|
54052
54054-T8006 Seat-Front Spring8406--01 ~ 8611--01; SD25.ST+TH#.TH.R5 TH#.THS.275T |
54054-T8006 |
US $27.36 |
||
|
54052
|
54052
54054-T8007 Seat-Front Spring8406--01 ~ 8611--01; $Z20#.(TL#,TH#.ST)+WCSB.2T.THS+DP.THS |
54054-T8007 |
US $16.42 |
||
|
54215
|
54215
55210-J5110 Pin-Front Spring8112--01 ~ ; ALL |
55210-J5110 |
from US $12.53 |
||
|
54219
|
54219
54219-T8000 Clip-Front Spring8112--01 ~ 8212--01; Z20#.TLF+TL+SB.TH#.TH.ST +WC |
54219-T8000 |
US $13.25 |
||
|
54222
|
54222
55220-T8100 Shackle-Front Spring8112--01 ~ 8611--01; ALL-(SD25.TLF,SB.CV); ﾐｷﾞ,ﾋﾀﾞﾘ |
55220-T8100 |
US $31.33 |
||
|
54223
|
54223
55221-T8100 Shackle-Front Spring8112--01 ~ 8611--01; ALL-(SD25.TLF,SB.CV); ﾐｷﾞ,ﾋﾀﾞﾘ |
55221-T8100 |
from US $9.30 |
||
|
56110K
|
56110K
56110-T8125 Absorber Kit-Shock, Front8406--01 ~ 8611--01; !SB.2T.TL#.TL +SB.2T.TH#.TH.ST +WC; ｺｸｲﾝNO 56110-T8101 |
56110-T8125 |
US $174.24 |
||
|
56110K
|
56110K
56110-T8128 Absorber Kit-Shock, Front8112--01 ~ 8212--01; 6TL+WC+DP SB.(TH#-SD25).ST THS+SH.ED33.TL; ｺｸｲﾝNO 56110-T8122 |
56110-T8128 |
US $136.08 |
||
|
56110K
|
56110K
56110-T8185 Absorber Kit-Shock, Front8905--01 ~ 9006--01; )SB.ST+SB.TH#.DIE.WT LB.(TLF+TH)+DP.THS F; ｺｸｲﾝNO 56110-T8124 |
56110-T8185 |
US $136.08 |
||
|
56110K
|
56110K
56110-T8186 Absorber Kit-Shock, Front8805--01 ~ 8905--01; 5SB.Z20#.(TL#+TH#.ST)SB.TD27 SB.ED33.TH.ST; ｺｸｲﾝNO 56110-T8102 |
56110-T8186 |
US $174.24 |
||
|
56112
|
56112
5612750000 Bush-Shock Absorber8112--01 ~ 8205--01; ALL-(SD25.TLF,SB.CV) |
5612750000 |
from US $1.59 |
||
|
56112
|
56112
56127T8000 Bush8205--01 ~ ; ALL |
56127T8000 |
US $7.20 |
||
|
56112
|
56112
5612750000 Bush-Shock Absorber8112--01 ~ 8205--01; ALL-(SD25.TLF,SB.CV) |
5612750000 |
from US $1.59 |
||
|
56112
|
56112
56127T8000 Bush8205--01 ~ ; ALL |
56127T8000 |
US $7.20 |
||
|
56113
|
56113
56129-32700
Washer-Special
8112--01 ~ ; ALL |
56129-32700 |
— | ||
| replacement | |||||
|
56113
|
56113
56129-3270A Washer-Special8112--01 ~ ; ALL |
56129-3270A |
from US $1.15 |
||
|
56113
|
56113
56129-32700
Washer-Special
8112--01 ~ ; ALL |
56129-32700 |
— | ||
| replacement | |||||
|
56113
|
56113
56129-3270A Washer-Special8112--01 ~ ; ALL |
56129-3270A |
from US $1.15 |
||
|
56113
|
56113
56129-32700
Washer-Special
8112--01 ~ ; ALL |
56129-32700 |
— | ||
| replacement | |||||
|
56113
|
56113
56129-3270A Washer-Special8112--01 ~ ; ALL |
56129-3270A |
from US $1.15 |
||
|
56119
|
56119
56119T8000 Bush-Shock Absorber8112--01 ~ ; ALL |
56119T8000 |
US $5.04 |
||
|
56127
|
56127
56127-T8101 Pin-Front Shock Absorber8112--01 ~ ; ALL |
56127-T8101 |
US $13.25 |
||
|
56128
|
56128
351833901P Washer-Special8112--01 ~ ; ALL; ｱｳﾀ- |
351833901P |
US $0.86 |
||
|
56129
|
56129
351833902P Washer-Special8112--01 ~ ; ALL; ｲﾝﾅ- |
351833902P |
US $1.58 |
||
