Electrical unit (2006-12-01 ~ ; ボディ-2; W) Diagram Nissan CUBE/CUBE CUBIC
- Year
- 2005 - 2012
- Sales region
- Japan
- Engine
- CR14DE
- drive
- 2WD
- transmission
- AT
- grade
- 14RS
- body
- W
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
081466165H
|
081466165H
081466165H Scr-Hex-Hd M6 |
081466165H |
from US $0.63 |
||
|
081A66351A
|
081A66351A
081A6-6351A
ﾎﾞﾙﾄ,ﾌﾗﾝｼﾞ
|
081A6-6351A |
— | ||
|
25085J
|
25085J
0165801491 PLUG0505--01 ~ 0612--01; W; ﾊｲﾄｾﾝｻｰ |
0165801491 |
US $2.45 |
||
|
25231A
|
25231A
0114100461 BOLT0305--01 ~ 0505--01; W |
0114100461 |
from US $1.48 |
||
|
25347D
|
25347D
0145600031 SCREW0505--01 ~ 0612--01; *W |
0145600031 |
from US $1.05 |
||
|
25732A
|
25732A
0145600031 SCREW0305--01 ~ 0505--01; W |
0145600031 |
from US $1.05 |
||
|
28556B
|
28556B
0122500881 NUT0305--01 ~ 0505--01; *W |
0122500881 |
from US $0.67 |
||
|
28556M
|
28556M
28556-3U025 Sensor & Diagnosis-Air Bag0305--01 ~ 0505--01; W |
28556-3U025 |
US $758.98 |
||
|
53820Q
|
53820Q
53810-4V01A New Genuine Part0505--01 ~ 0612--01; *W.HR15DE +*W.(14S+14RS) |
53810-4V01A |
US $515.42 |
||
|
53830U
|
53830U
53830ED200 Brkt Assy-Sen0505--01 ~ 0612--01; *W |
53830ED200 |
US $10.08 |
||
|
740
|
Floor panel
740
|
||||
|
740
|
Floor panel
740
|
||||
|
740
|
Floor panel
740
|
||||
|
760
|
Body side panel
760
|
||||
|
760
|
Body side panel
760
|
||||
|
760
|
Body side panel
760
|
||||
|
98820
|
98820
98820-3U025 Sensor-Side Air Bag Center0305--01 ~ 0505--01; *W |
98820-3U025 |
US $758.98 |
||
|
98830
|
98830
98830AU025 Sensor-Side Air Bag, Rh0305--01 ~ 0505--01; *W |
98830AU025 |
US $337.01 |
||
|
98830
|
98830
K8830-AU00A Sensor-Side Air Bag, Rh0607--01 ~ 0612--01; *W.(14RS+15RX+14RSFOUR) |
K8830-AU00A |
US $285.12 |
||
