Ignition System (1997-05-01 ~ 1998-10-01; QD32ETI) Diagram Nissan ELGRAND
- Year
- 1997 - 1999
- Sales region
- Japan
- Engine
- QD32ETI
- drive
- 2WD
- transmission
- AT
- grade
- J
- body
- K
- capacity
- 8P
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
081466162G
|
081466162G
081466162G Bolt-hexagon |
081466162G |
from US $0.67 |
||
|
0891513410
|
0891513410
0891513410
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
0891513410 |
— | ||
|
11065
|
11065
110650W801
Plug-Glow
9705--01 ~ 9810--01; QD32ETI; NTK[B512] |
110650W801 |
— | ||
| replacement | |||||
|
11065
|
11065
11065-0W80A Glow Plug9705--01 ~ 9810--01; QD32ETI; NTK[B512] |
11065-0W80A |
US $115.32 |
||
|
11065
|
11065
11065-65N01 Plug-Glow9705--01 ~ 9810--01; QD32ETI; ｷﾖｳｾﾗ |
11065-65N01 |
US $72 |
||
|
11065
|
11065
110660W800 Nut9705--01 ~ 9810--01; QD32ETI |
110660W800 |
US $2.88 |
||
|
11065B
|
11065B
110660W800 Nut9705--01 ~ 9810--01; QD32ETI |
110660W800 |
US $2.88 |
||
|
11086
|
11086
1108643G00 Cable Assy9705--01 ~ 9810--01; QD32ETI |
1108643G00 |
US $15.55 |
||
|
24024L
|
24024L
24024VE000 Harness Assy-Glow9705--01 ~ 9810--01; QD32ETI |
24024VE000 |
US $49.54 |
||
|
25215G
|
25215G
252300W800
Relay Assy-Glow Plug
9705--01 ~ 9810--01; QD32ETI |
252300W800 |
— | ||
| replacement | |||||
|
25215G
|
25215G
25230-0W80A RELAY ASSY-GLOW9705--01 ~ 9810--01; QD32ETI |
25230-0W80A |
US $56.83 |
||
|
25239P
|
25239P
25239-3C000 Cover-Relay9705--01 ~ 9810--01; QD32ETI |
25239-3C000 |
US $7.34 |
||
