Rear brake (2003-01-01 ~ 2005-08-01; CALIPER; VQ35DE) Diagram Nissan MAXIMA
- Year
- 2003 - 2005
- Sales region
- U.S.A.
- Engine
- VQ35DE
- transmission
- 5AT
- body
- 4S
- seat
- 4 SEAT
- trim lvl
- SE
- trim mtl
- LEATHER
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
080442351A
|
080442351A
08044-2351A Bolt-hexagon |
08044-2351A |
US $1.76 |
||
|
44000C
|
44000C
0131101251 WASHER2003-01-01 ~ 2005-08-01; VQ35DE; , |
0131101251 |
from US $0.57 |
||
|
44000K
|
44000K
44060-AL585
Pad Kit-Disc Brake, Rear
2003-01-01 ~ 2003-02-01; VQ35DE; , |
44060-AL585 |
— | ||
|
44000K
|
44000K
44060-AL586
Pad Kit-Disc Brake, Rear
2003-02-01 ~ 2005-08-01; VQ35DE; , |
44060-AL586 |
— | ||
|
44000L
|
44000L
44120-8H325
Seal Kit-Disc Brake
2003-01-01 ~ 2005-08-01; VQ35DE; , |
44120-8H325 |
— | ||
|
44001
|
44001
44001-7Y005
Caliper Assy-Rear Rh, W/o Pad & Shim
2004-05-01 ~ 2005-08-01; VQ35DE; , |
44001-7Y005 |
— | ||
| replacement | |||||
|
44001
|
44001
44001-8J10A Caliper Assy-Rear Rh, W/o Pads Or Shims2004-05-01 ~ 2005-08-01; VQ35DE; , |
44001-8J10A |
US $376.66 |
||
|
44001
|
44001
44001-8J100 Caliper Assy-Rear Rh, W/o Pads Or Shims2003-01-01 ~ 2004-05-01; VQ35DE; , |
44001-8J100 |
US $376.66 |
||
| replacement | |||||
|
44001
|
44001
44001-8J10A Caliper Assy-Rear Rh, W/o Pads Or Shims2003-01-01 ~ 2004-05-01; VQ35DE; , |
44001-8J10A |
US $376.66 |
||
|
44011
|
44011
44011-7Y005
Caliper Assy-Rear Lh, W/o Pad & Shim
2004-05-01 ~ 2005-08-01; VQ35DE; , |
44011-7Y005 |
— | ||
| replacement | |||||
|
44011
|
44011
44011-8J10A Caliper Assy-Rear Lh, W/o Pads Or Shims2004-05-01 ~ 2005-08-01; VQ35DE; , |
44011-8J10A |
US $376.66 |
||
|
44011
|
44011
44011-8J100 Caliper Assy-Rear Lh, W/o Pads Or Shims2003-01-01 ~ 2004-05-01; VQ35DE; , |
44011-8J100 |
US $376.66 |
||
| replacement | |||||
|
44011
|
44011
44011-8J10A Caliper Assy-Rear Lh, W/o Pads Or Shims2003-01-01 ~ 2004-05-01; VQ35DE; , |
44011-8J10A |
US $376.66 |
||
|
44044
|
44044
44044-8J100 Washer2003-01-01 ~ 2005-08-01; VQ35DE; , |
44044-8J100 |
US $13.82 |
||
|
44044
|
44044
44044-8J101 Washer2003-01-01 ~ 2005-08-01; VQ35DE; , |
44044-8J101 |
US $13.82 |
||
|
44044+A
|
44044+A
44044-8J101 Washer2003-01-01 ~ 2005-08-01; VQ35DE; , |
44044-8J101 |
US $13.82 |
||
|
44080K
|
44080K
440808J125 Hardware Kit-Rear Disc Brake Pad2003-01-01 ~ 2005-08-01; VQ35DE; , |
440808J125 |
US $64.08 |
||
|
44122
|
44122
44126-8J100 Piston2003-01-01 ~ 2005-08-01; VQ35DE; , |
44126-8J100 |
US $78.19 |
||
|
44128
|
44128
411288J100 Screw-Bleeder2003-01-01 ~ 2005-08-01; VQ35DE; , |
411288J100 |
from US $6.91 |
||
|
44139
|
44139
44140-8J100
Pin-Slide
2003-01-01 ~ 2005-08-01; VQ35DE; , |
44140-8J100 |
— | ||
| replacement | |||||
|
44139
|
44139
44140JA01A Pin-Slide2003-01-01 ~ 2005-08-01; VQ35DE; , |
44140JA01A |
from US $10.69 |
||
|
44139
|
44139
44141-8J100
Bolt-Pin
2003-01-01 ~ 2005-08-01; VQ35DE; , |
44141-8J100 |
— | ||
| replacement | |||||
|
44139
|
44139
44141JA01A Bolt-Pin2003-01-01 ~ 2005-08-01; VQ35DE; , |
44141JA01A |
from US $5.31 |
||
|
44139+A
|
44139+A
44141-8J100
Bolt-Pin
2003-01-01 ~ 2005-08-01; VQ35DE; , |
44141-8J100 |
— | ||
| replacement | |||||
|
44139+A
|
44139+A
44141JA01A Bolt-Pin2003-01-01 ~ 2005-08-01; VQ35DE; , |
44141JA01A |
from US $5.31 |
||
