Piston,crankshaft & flywheel (1990-05-01 ~ ; ALL) Diagram Nissan PASSAT (Volkswagen)
- Year
- 1989 - 2012
- Sales region
- Japan
- Engine
- 9A
- transmission
- AT
- grade
- T/L
- body
- S
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
12010
|
12010
12010-85V00 Piston, W/pin8910--01 ~ ; 9A; STD ﾘﾝｸﾞﾂｷ |
12010-85V00 |
US $1,083.24 |
||
|
12030
|
12030
12030-85V01 Bush-Piston Pin8910--01 ~ ; 9A |
12030-85V01 |
US $19.30 |
||
|
12032
|
12032
N0012-27301 Ring-Snap8910--01 ~ ; 9A |
N0012-27301 |
US $0.72 |
||
|
12033
|
12033
12033-85V00 Ring Set-Piston8910--01 ~ ; 9A |
12033-85V00 |
US $283.68 |
||
|
12100
|
12100
12100-85V00 Rod Compl-Connecting8910--01 ~ ; 9A; 1ﾀﾞｲﾌﾞﾝｾﾂﾄ(4ｹ) |
12100-85V00 |
US $2,422 |
||
|
12109
|
12109
12109-V4900 Bolt-Connecting Rod8910--01 ~ ; 9A |
12109-V4900 |
US $14.11 |
||
|
12111
|
12111
12111-V4902 Bearing-Connecting Rod8910--01 ~ ; 9A; STD |
12111-V4902 |
US $59.18 |
||
|
12111
|
12111
12117-85V00 Bearing-Connecting Rod8910--01 ~ ; 9A; US=0.25 |
12117-85V00 |
US $24.34 |
||
|
12111
|
12111
12119-85V00 Bearing-Connecting Rod8910--01 ~ ; 9A; US=0.5 |
12119-85V00 |
US $36.58 |
||
|
12111
|
12111
12122-85V00 Bearing-Connecting Rod8910--01 ~ ; 9A; US=0.75 |
12122-85V00 |
US $36.58 |
||
|
12112
|
12112
12112-V4900 Nut-Connecting Rod8910--01 ~ ; 9A |
12112-V4900 |
US $1.73 |
||
|
12200
|
12200
12200-85V00 Crankshaft Assy8910--01 ~ ; 9A |
12200-85V00 |
US $2,926 |
||
|
12200
|
12200
N0012-70802 Key8910--01 ~ ; 9A |
N0012-70802 |
US $1.73 |
||
|
12200B
|
12200B
N0012-70802 Key8910--01 ~ ; 9A |
N0012-70802 |
US $1.73 |
||
|
12207
|
12207
12247-85V00 Bearing-Crankshaft8910--01 ~ ; 9A; STD NO1,2,3,5 |
12247-85V00 |
US $191.52 |
||
|
12207
|
12207
12247-85V10 Bearing-Crankshaft8910--01 ~ ; 9A; STD NO4 |
12247-85V10 |
US $208.80 |
||
|
12207
|
12207
12217-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.25 N0.4,ｺｳｶﾝﾖｳ |
12217-V4900 |
— | ||
|
12207
|
12207
12218-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.50 N0.4,ｺｳｶﾝﾖｳ |
12218-V4900 |
— | ||
|
12207
|
12207
12219-V4900 Bearing-Crankshaft8910--01 ~ ; 9A; US=0.75 N0.4,ｺｳｶﾝﾖｳ |
12219-V4900 |
US $40.90 |
||
|
12207
|
12207
12209-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.25 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12209-V4902 |
US $51.55 |
||
|
12207
|
12207
12210-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.50 NO.4,ｺｳｶﾝﾉ ｺﾄ |
12210-V4902 |
US $51.55 |
||
|
12207
|
12207
12211-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.75 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12211-V4902 |
US $51.55 |
||
|
12207
|
12207
12247-85V00 Bearing-Crankshaft8910--01 ~ ; 9A; STD NO1,2,3,5 |
12247-85V00 |
US $191.52 |
||
|
12207
|
12207
12247-85V10 Bearing-Crankshaft8910--01 ~ ; 9A; STD NO4 |
12247-85V10 |
US $208.80 |
||
|
12207
|
12207
12217-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.25 N0.4,ｺｳｶﾝﾖｳ |
12217-V4900 |
— | ||
|
12207
|
12207
12218-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.50 N0.4,ｺｳｶﾝﾖｳ |
12218-V4900 |
— | ||
|
12207
|
12207
12219-V4900 Bearing-Crankshaft8910--01 ~ ; 9A; US=0.75 N0.4,ｺｳｶﾝﾖｳ |
12219-V4900 |
US $40.90 |
||
|
12207
|
12207
12209-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.25 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12209-V4902 |
US $51.55 |
||
|
12207
|
12207
12210-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.50 NO.4,ｺｳｶﾝﾉ ｺﾄ |
12210-V4902 |
US $51.55 |
||
|
12207
|
12207
12211-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.75 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12211-V4902 |
US $51.55 |
||
|
12207M
|
12207M
12217-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.25 N0.4,ｺｳｶﾝﾖｳ |
12217-V4900 |
— | ||
|
12207M
|
12207M
12218-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.50 N0.4,ｺｳｶﾝﾖｳ |
12218-V4900 |
— | ||
|
12207M
|
12207M
12219-V4900 Bearing-Crankshaft8910--01 ~ ; 9A; US=0.75 N0.4,ｺｳｶﾝﾖｳ |
12219-V4900 |
US $40.90 |
||
|
12207M
|
12207M
12217-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.25 N0.4,ｺｳｶﾝﾖｳ |
12217-V4900 |
— | ||
|
12207M
|
12207M
12218-V4900
Bearing-Crankshaft
8910--01 ~ ; 9A; US=0.50 N0.4,ｺｳｶﾝﾖｳ |
12218-V4900 |
— | ||
|
12207M
|
12207M
12219-V4900 Bearing-Crankshaft8910--01 ~ ; 9A; US=0.75 N0.4,ｺｳｶﾝﾖｳ |
12219-V4900 |
US $40.90 |
||
|
12207S
|
12207S
12209-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.25 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12209-V4902 |
US $51.55 |
||
|
12207S
|
12207S
12210-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.50 NO.4,ｺｳｶﾝﾉ ｺﾄ |
12210-V4902 |
US $51.55 |
||
|
12207S
|
12207S
12211-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.75 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12211-V4902 |
US $51.55 |
||
|
12207S
|
12207S
12209-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.25 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12209-V4902 |
US $51.55 |
||
|
12207S
|
12207S
12210-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.50 NO.4,ｺｳｶﾝﾉ ｺﾄ |
12210-V4902 |
US $51.55 |
||
|
12207S
|
12207S
12211-V4902 Bearing Set-Crankshaft8910--01 ~ ; 9A; US=0.75 NO.4ｵｺｳｶﾝﾉ ｺﾄ |
12211-V4902 |
US $51.55 |
||
|
12208S
|
12208S
12280-85V00 Washer Set-Thrust8910--01 ~ ; 9A |
12280-85V00 |
US $80.64 |
||
|
12208S
|
12208S
12280-85V00 Washer Set-Thrust8910--01 ~ ; 9A |
12280-85V00 |
US $80.64 |
||
|
12208S
|
12208S
12280-85V00 Washer Set-Thrust8910--01 ~ ; 9A |
12280-85V00 |
US $80.64 |
||
|
12208S
|
12208S
12280-85V00 Washer Set-Thrust8910--01 ~ ; 9A |
12280-85V00 |
US $80.64 |
||
|
12275
|
12275
12334-85V00 Shim8910--01 ~ ; 9A |
12334-85V00 |
US $5.47 |
||
|
12303
|
12303
12303-80V00 Pulley-Crankshaft8910--01 ~ ; 9A |
12303-80V00 |
US $1,264.49 |
||
|
12303
|
12303
N1100-89001 Bolt-Pulley, Crankshaft8910--01 ~ ; 9A |
N1100-89001 |
US $9.50 |
||
|
12303
|
12303
12308-V4961 Washer-Pulley, Crankshaft8910--01 ~ ; 9A |
12308-V4961 |
US $9.65 |
||
|
12303
|
12303
N1903-39601 Bolt-Pulley8910--01 ~ ; 9A |
N1903-39601 |
US $3.46 |
||
|
12303A
|
12303A
N1100-89001 Bolt-Pulley, Crankshaft8910--01 ~ ; 9A |
N1100-89001 |
US $9.50 |
||
|
12303C
|
12303C
12308-V4961 Washer-Pulley, Crankshaft8910--01 ~ ; 9A |
12308-V4961 |
US $9.65 |
||
|
12303G
|
12303G
N1903-39601 Bolt-Pulley8910--01 ~ ; 9A |
N1903-39601 |
US $3.46 |
||
|
12305
|
12305
12304-80V00 Pulley-Power Steering8910--01 ~ ; 9A |
12304-80V00 |
US $156.96 |
||
|
12310
|
12310
12310-85V00 Flywheel Assy8910--01 ~ ; 9A |
12310-85V00 |
US $986.95 |
||
|
12310
|
12310
N1903-64701 Bolt-Flywheel8910--01 ~ 9007--01; 9A.AT |
N1903-64701 |
US $3.46 |
||
|
12310
|
12310
N1904-65601 Bolt-Flywheel9007--01 ~ ; 9A |
N1904-65601 |
US $4.18 |
||
|
12310
|
12310
N1101-05801 Dowel-Clutch To Flywheel8910--01 ~ ; 9A |
N1101-05801 |
US $2.16 |
||
|
12310A
|
12310A
N1903-64701 Bolt-Flywheel8910--01 ~ 9007--01; 9A.AT |
N1903-64701 |
US $3.46 |
||
|
12310A
|
12310A
N1904-65601 Bolt-Flywheel9007--01 ~ ; 9A |
N1904-65601 |
US $4.18 |
||
|
12310E
|
12310E
N1101-05801 Dowel-Clutch To Flywheel8910--01 ~ ; 9A |
N1101-05801 |
US $2.16 |
||
|
12312
|
12312
12312-80V00 Gear-Ring8910--01 ~ ; 9A |
12312-80V00 |
US $266.40 |
||
|
12331
|
12331
12331-85V00 Plate Assy-Drive & Gear8910--01 ~ ; 9A.AT |
12331-85V00 |
US $146.88 |
||
|
13021
|
13021
13021-80V00 Sprocket-Crankshaft8910--01 ~ ; 9A |
13021-80V00 |
US $127.87 |
||
|
31009Y
|
31009Y
12315-V4900
Bolt-Self Lock
8910--01 ~ ; 9A.AT |
12315-V4900 |
— | ||
|
32202
|
32202
32202-V4000 Bushing-Crankshaft8910--01 ~ ; 9A |
32202-V4000 |
US $27.65 |
