Air cleaner (1979-06-01 ~ ; Z20) Diagram Nissan PICKUP
- Year
- 1983 - 2011
- Sales region
- U.S.A.
- Engine
- Z20
- drive
- 2WD
- transmission
- F5
- body
- K/CAB
- trim lvl
- STD
- emission
- FED
- length
- LONG
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
14844
|
14844
14856-W7000 Valve Assy-Air Induce, W/case1983-01-01 ~ ; Z20; , |
14856-W7000 |
US $11.66 |
||
|
14845
|
14845
14845-W7000
Valve Assy-Air Induce
1983-01-01 ~ ; Z20; , |
14845-W7000 |
— | ||
| replacement | |||||
|
14845
|
14845
14845-H9901
Valve Assy-Air Induce
1983-01-01 ~ ; Z20; , |
14845-H9901 |
— | ||
|
14856A
|
14856A
16516-W0400 Bolt1983-01-01 ~ ; Z20; , |
16516-W0400 |
US $0.86 |
||
|
16500
|
16500
16500-48W00
Air Cleaner
1983-01-01 ~ 1984-07-01; Z20; , |
16500-48W00 |
— | ||
|
16500
|
16500
16500-82W00
Air Cleaner
1984-07-01 ~ ; Z20; , |
16500-82W00 |
— | ||
|
16510
|
16510
16510-82W00
Motor Assy-Vacuum
1984-07-01 ~ ; Z20; , |
16510-82W00 |
— | ||
|
16510
|
16510
16510-N0901
Motor Assy-Vacuum
1983-01-01 ~ 1984-07-01; Z20; , |
16510-N0901 |
— | ||
|
16510
|
16510
16516-G2100 Bolt1983-01-01 ~ ; Z20; , |
16516-G2100 |
US $0.86 |
||
|
16510
|
16510
16510-82W00
Motor Assy-Vacuum
1984-07-01 ~ ; Z20; , |
16510-82W00 |
— | ||
|
16510
|
16510
16510-N0901
Motor Assy-Vacuum
1983-01-01 ~ 1984-07-01; Z20; , |
16510-N0901 |
— | ||
|
16510
|
16510
16516-G2100 Bolt1983-01-01 ~ ; Z20; , |
16516-G2100 |
US $0.86 |
||
|
16510A
|
16510A
16516-G2100 Bolt1983-01-01 ~ ; Z20; , |
16516-G2100 |
US $0.86 |
||
|
16510A
|
16510A
16516-G2100 Bolt1983-01-01 ~ ; Z20; , |
16516-G2100 |
US $0.86 |
||
|
16515
|
16515
16515-W1160
Bracket-Vacuum Motor
1984-07-01 ~ ; Z20; , |
16515-W1160 |
— | ||
|
16521M
|
16521M
16520-48W01
Hose-Vacuum Control, Air Cleaner
1983-01-01 ~ ; Z20; L=420 S/#B2320-Y4000 |
16520-48W01 |
— | ||
|
16521M
|
16521M
B2320-Y4000 Hose-Vacuum Control1983-04-01 ~ ; Z20; L=5000(CUT USE) |
B2320-Y4000 |
US $32.26 |
||
|
16521Q
|
16521Q
02187-14601
HOSE-VACUUM CONTROL,AIR CLEANER
1984-07-01 ~ ; Z20; L=460 S/#B2320-Y4000 |
02187-14601 |
— | ||
|
16521Q
|
16521Q
02187-15801
HOSE-VACUUM CONTROL,AIR CLEANER
1984-07-01 ~ ; Z20; L=580 S/#B2320-Y4000 |
02187-15801 |
— | ||
|
16521Q
|
16521Q
16520-48W00
Hose-Vacuum
1983-01-01 ~ ; Z20; L=460 S/#B2320-Y4000 |
16520-48W00 |
— | ||
|
16521Q
|
16521Q
B2320-Y4000 Hose-Vacuum Control1983-01-01 ~ ; Z20; L=5000(CUT USE) |
B2320-Y4000 |
US $32.26 |
||
|
16521Q
|
16521Q
02187-14601
HOSE-VACUUM CONTROL,AIR CLEANER
1984-07-01 ~ ; Z20; L=460 S/#B2320-Y4000 |
02187-14601 |
— | ||
|
16521Q
|
16521Q
02187-15801
HOSE-VACUUM CONTROL,AIR CLEANER
1984-07-01 ~ ; Z20; L=580 S/#B2320-Y4000 |
02187-15801 |
— | ||
|
16521Q
|
16521Q
16520-48W00
Hose-Vacuum
1983-01-01 ~ ; Z20; L=460 S/#B2320-Y4000 |
16520-48W00 |
— | ||
|
16521Q
|
16521Q
B2320-Y4000 Hose-Vacuum Control1983-01-01 ~ ; Z20; L=5000(CUT USE) |
B2320-Y4000 |
US $32.26 |
||
|
16521Q
|
16521Q
02187-14601
HOSE-VACUUM CONTROL,AIR CLEANER
1984-07-01 ~ ; Z20; L=460 S/#B2320-Y4000 |
02187-14601 |
— | ||
|
16521Q
|
16521Q
02187-15801
HOSE-VACUUM CONTROL,AIR CLEANER
1984-07-01 ~ ; Z20; L=580 S/#B2320-Y4000 |
02187-15801 |
— | ||
|
16521Q
|
16521Q
16520-48W00
Hose-Vacuum
1983-01-01 ~ ; Z20; L=460 S/#B2320-Y4000 |
16520-48W00 |
— | ||
|
16521Q
|
16521Q
B2320-Y4000 Hose-Vacuum Control1983-01-01 ~ ; Z20; L=5000(CUT USE) |
B2320-Y4000 |
US $32.26 |
||
|
16523
|
16523
16523-W7000
Insulator
1983-01-01 ~ ; Z20; , |
16523-W7000 |
— | ||
| replacement | |||||
|
16523
|
16523
16523-24G00 Insulator-Air Cleaner1983-01-01 ~ ; Z20; , |
16523-24G00 |
from US $9.98 |
||
|
16523
|
16523
14875-06W61
Connector, A
1984-07-01 ~ ; Z20 +Z24; , |
14875-06W61 |
— | ||
|
16523
|
16523
16523-W7000
Insulator
1983-01-01 ~ ; Z20; , |
16523-W7000 |
— | ||
| replacement | |||||
|
16523
|
16523
16523-24G00 Insulator-Air Cleaner1983-01-01 ~ ; Z20; , |
16523-24G00 |
from US $9.98 |
||
|
16523
|
16523
14875-06W61
Connector, A
1984-07-01 ~ ; Z20 +Z24; , |
14875-06W61 |
— | ||
|
16546
|
16546
16546-S0100 Air Cleaner Element1983-01-01 ~ ; Z20; VISCOUS |
16546-S0100 |
from US $18.59 |
||
|
16546
|
16546
16546-S0100 Air Cleaner Element1983-01-01 ~ ; Z20; VISCOUS |
16546-S0100 |
from US $18.59 |
||
|
16547
|
16547
16547-73000 Packing1983-01-01 ~ ; Z20; , |
16547-73000 |
US $11.23 |
||
|
16547
|
16547
16547-73000 Packing1983-01-01 ~ ; Z20; , |
16547-73000 |
US $11.23 |
||
|
16547
|
16547
16547-73000 Packing1983-01-01 ~ ; Z20; , |
16547-73000 |
US $11.23 |
||
|
16547
|
16547
16547-73000 Packing1983-01-01 ~ ; Z20; , |
16547-73000 |
US $11.23 |
||
|
16548
|
16548
16548-U0100 Packing1983-01-01 ~ ; Z20; , |
16548-U0100 |
US $11.38 |
||
|
16548
|
16548
16548-U0100 Packing1983-01-01 ~ ; Z20; , |
16548-U0100 |
US $11.38 |
||
|
16551
|
16551
16551-W7000
Nut-Wing
1983-01-01 ~ ; Z20; , |
16551-W7000 |
— | ||
| replacement | |||||
|
16551
|
16551
16551W700A Nut-Wing1983-01-01 ~ ; Z20; , |
16551W700A |
from US $4.85 |
||
|
16551
|
16551
16551-W7000
Nut-Wing
1983-01-01 ~ ; Z20; , |
16551-W7000 |
— | ||
| replacement | |||||
|
16551
|
16551
16551W700A Nut-Wing1983-01-01 ~ ; Z20; , |
16551W700A |
from US $4.85 |
||
|
16557
|
16557
16557-D1100 Mounting Rubber1983-01-01 ~ ; Z20; , |
16557-D1100 |
US $5.27 |
||
|
16557
|
16557
16557-D1100 Mounting Rubber1983-01-01 ~ ; Z20; , |
16557-D1100 |
US $5.27 |
||
|
16563
|
16563
16563-82W00 Valve Assy-Air Induce, W/case1984-07-01 ~ ; Z20; , |
16563-82W00 |
US $5.18 |
||
|
16565M
|
16565M
14858-W1100 Filter Assy1983-01-01 ~ ; Z20; , |
14858-W1100 |
US $10.51 |
||
|
16565M
|
16565M
16858-W1100 Filter Assy1983-01-01 ~ ; Z20; , |
16858-W1100 |
US $9.65 |
||
|
16565N
|
16565N
16565-W8800 Filter Assy1983-01-01 ~ ; Z20; , |
16565-W8800 |
US $2.45 |
||
|
16565N
|
16565N
16565-W8800 Filter Assy1983-01-01 ~ ; Z20; , |
16565-W8800 |
US $2.45 |
||
|
16568
|
16568
16568-W7000 Packing1983-01-01 ~ ; Z20; , |
16568-W7000 |
US $3.06 |
||
|
16568
|
16568
16568-W7000 Packing1983-01-01 ~ ; Z20; , |
16568-W7000 |
US $3.06 |
||
|
16576E
|
16576E
16566-82W00
Holder Assy-Valve
1984-07-01 ~ ; Z20; , |
16566-82W00 |
— | ||
|
16577C
|
16577C
16589-48W00
Packing
1983-01-01 ~ ; Z20; , |
16589-48W00 |
— | ||
|
16580
|
16580
16580-01B01 Intake Air Temperature Sensor1983-01-01 ~ 1984-07-01; Z20; , |
16580-01B01 |
US $50.04 |
||
|
16580
|
16580
16580-H3900
Intake Air Temperature Sensor
1983-01-01 ~ 1984-07-01; Z20; , |
16580-H3900 |
— | ||
|
16580
|
16580
16580-W7000 Intake Air Temperature Sensor1984-07-01 ~ ; Z20; , |
16580-W7000 |
US $43.92 |
||
|
16580
|
16580
16529-B9800 Grommet1983-01-01 ~ ; Z20; , |
16529-B9800 |
US $1.67 |
||
|
16580
|
16580
16582-H3901 Stopper1983-01-01 ~ ; Z20; , |
16582-H3901 |
US $8.87 |
||
|
16580
|
16580
16580-01B01 Intake Air Temperature Sensor1983-01-01 ~ 1984-07-01; Z20; , |
16580-01B01 |
US $50.04 |
||
|
16580
|
16580
16580-H3900
Intake Air Temperature Sensor
1983-01-01 ~ 1984-07-01; Z20; , |
16580-H3900 |
— | ||
|
16580
|
16580
16580-W7000 Intake Air Temperature Sensor1984-07-01 ~ ; Z20; , |
16580-W7000 |
US $43.92 |
||
|
16580
|
16580
16529-B9800 Grommet1983-01-01 ~ ; Z20; , |
16529-B9800 |
US $1.67 |
||
|
16580
|
16580
16582-H3901 Stopper1983-01-01 ~ ; Z20; , |
16582-H3901 |
US $8.87 |
||
|
16580H
|
16580H
16529-B9800 Grommet1983-01-01 ~ ; Z20; , |
16529-B9800 |
US $1.67 |
||
|
16580H
|
16580H
16529-B9800 Grommet1983-01-01 ~ ; Z20; , |
16529-B9800 |
US $1.67 |
||
|
16580J
|
16580J
16582-H3901 Stopper1983-01-01 ~ ; Z20; , |
16582-H3901 |
US $8.87 |
||
|
16580J
|
16580J
16582-H3901 Stopper1983-01-01 ~ ; Z20; , |
16582-H3901 |
US $8.87 |
||
|
16598
|
16598
16509-99009 Clip1983-01-01 ~ ; Z20; , |
16509-99009 |
US $3.75 |
||
|
16598
|
16598
16598-73600 Clip1983-01-01 ~ ; Z20; , |
16598-73600 |
US $2.45 |
||
|
16598
|
16598
16509-99009 Clip1983-01-01 ~ ; Z20; , |
16509-99009 |
US $3.75 |
||
|
16598
|
16598
16598-73600 Clip1983-01-01 ~ ; Z20; , |
16598-73600 |
US $2.45 |
||
|
16860P
|
16860P
16567-82W00 Filter Assy1984-07-01 ~ ; Z20; , |
16567-82W00 |
US $4.42 |
||
|
17090E
|
17090E
16569-82W00 Mounting Rubber1984-07-01 ~ ; Z20; , |
16569-82W00 |
US $1.67 |
||
