Rear suspension (1992-02-01 ~ 1995-08-01; スタビライザ-; 4WD.CA20S +4WD.KA24E) Diagram Nissan PRAIRIE/LIBERTY
- Year
- 1988 - 1995
- Sales region
- Japan
- Engine
- CA20S
- drive
- 4WD
- transmission
- F5
- grade
- J
- body
- S
- capacity
- 7P
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
081240251F
|
081240251F
081240251F
Bolt-hexagon
|
081240251F |
— | ||
|
081240301F
|
081240301F
08124-0301F
Bolt-hexagon
|
08124-0301F |
— | ||
|
081240351F
|
081240351F
08124-0351F
Bolt-hexagon
|
08124-0351F |
— | ||
|
089186401A
|
089186401A
089186401A NUTSLOCK |
089186401A |
US $1.83 |
||
|
55060AA
|
55060AA
01121-00763 BOLT8905--01 ~ 9009--01; (4WD.5P+4WD.6P+4WD.7P).CA20S |
01121-00763 |
US $4.03 |
||
|
55060AA
|
55060AA
56285-30R01 Bolt8809--01 ~ 8811--01; 4WD.5P +4WD.6P +4WD.7P |
56285-30R01 |
US $4.18 |
||
|
55060AA
|
55060AA
01121-00763 BOLT8905--01 ~ 9009--01; (4WD.5P+4WD.6P+4WD.7P).CA20S |
01121-00763 |
US $4.03 |
||
|
55060AA
|
55060AA
56285-30R01 Bolt8809--01 ~ 8811--01; 4WD.5P +4WD.6P +4WD.7P |
56285-30R01 |
US $4.18 |
||
|
55060B
|
55060B
0122500182 NUT8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
0122500182 |
US $1.73 |
||
|
56230
|
56230
56230-40R10 Stabilizer-Rear8901--01 ~ 9009--01; (4WD.5P+4WD.6P+4WD.7P).CA20S |
56230-40R10 |
US $279.36 |
||
|
56230
|
56230
56230-44R00 Stabilizer-Rear8809--01 ~ 8901--01; 4WD.5P +4WD.6P +4WD.7P |
56230-44R00 |
US $279.36 |
||
|
56233P
|
56233P
56233-30R00 Bracket Assy-Stabilizer Mounting8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P; ﾐｷﾞ ﾖｳ |
56233-30R00 |
US $15.53 |
||
|
56233P
|
56233P
56233-40R00 Bracket Assy-Stabilizer Mounting8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P; ﾋﾀﾞﾘ ﾖｳ |
56233-40R00 |
US $15.41 |
||
|
56233PA
|
56233PA
56233-40R00 Bracket Assy-Stabilizer Mounting8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P; ﾋﾀﾞﾘ ﾖｳ |
56233-40R00 |
US $15.41 |
||
|
56243
|
56243
56243-42R10 Bush-Rear Stabilizer8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56243-42R10 |
US $7.92 |
||
| replacement | |||||
|
56243
|
56243
56243-35R10 Bush-Rear Stabilizer8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56243-35R10 |
from US $7.20 |
||
|
56243
|
56243
56243-42R10 Bush-Rear Stabilizer8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56243-42R10 |
US $7.92 |
||
| replacement | |||||
|
56243
|
56243
56243-35R10 Bush-Rear Stabilizer8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56243-35R10 |
from US $7.20 |
||
|
56260N
|
56260N
56261-56E10 ROD ASSY-CONNECTING,STABILIZER8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56261-56E10 |
US $67.25 |
||
|
56285
|
56285
56285-30R00 Bolt8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56285-30R00 |
US $4.18 |
||
|
56285
|
56285
56285-30R00 Bolt8809--01 ~ 9009--01; 4WD.5P +4WD.6P +4WD.7P |
56285-30R00 |
US $4.18 |
||
|
56311M
|
56311M
56311-42R00 Bracket-Rear Stabilizer, Rh8809--01 ~ 8901--01; 4WD.5P +4WD.6P +4WD.7P |
56311-42R00 |
US $17.71 |
||
|
56311M
|
56311M
56311-42R01 Bracket-Rear Stabilizer, Rh8901--01 ~ 9009--01; (4WD.5P+4WD.6P+4WD.7P).CA20S |
56311-42R01 |
US $17.71 |
||
