Rear axle (2000-12-01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4) Diagram Nissan PRIMERA
- Year
- 1997 - 2012
- Sales region
- Japan
- Engine
- SR20DE
- drive
- 4WD
- transmission
- MT.F5
- grade
- G/4
- body
- W
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
43052
|
43052
43018-4J500 Housing-Rear Axle, Rh9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
43018-4J500 |
US $802.87 |
||
|
43053
|
43053
43019-4J500 Housing-Rear Axle, Lh9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
43019-4J500 |
US $802.87 |
||
|
43084
|
43084
402622Y000 Nut-Lock0012--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
402622Y000 |
from US $3.13 |
||
|
431
|
Rear suspension
431
|
||||
|
431
|
Rear suspension
431
|
||||
|
43202
|
43202
43202-65J07 Hub Assy-Rear9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
43202-65J07 |
US $270.72 |
||
|
43207
|
43207
43206-42R05 Rotor-Disc Brake, Rear9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
43206-42R05 |
US $171.36 |
||
|
43210
|
43210
4021030R01 Bearing Assy-Front Wheel9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NSK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
4021030R01 |
from US $46.66 |
||
|
43210
|
43210
40210-30R06
Bearing Assy-Front Wheel
9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NTN ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
40210-30R06 |
— | ||
| replacement | |||||
|
43210
|
43210
4021030R01 Bearing Assy-Front Wheel9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NTN ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
4021030R01 |
from US $46.66 |
||
|
43210
|
43210
4021430R00 Ring-Snap9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
4021430R00 |
US $4.18 |
||
|
43210A
|
43210A
4021430R00 Ring-Snap9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
4021430R00 |
US $4.18 |
||
|
43210A
|
43210A
4021430R00 Ring-Snap9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
4021430R00 |
US $4.18 |
||
|
43222
|
43222
4322241B00 Bolt-Hub9709--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
4322241B00 |
from US $1.42 |
||
|
43222
|
43222
4003701E00 WASHER-FRONT WHEEL BEARING9709--01 ~ 0012--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
4003701E00 |
from US $3.06 |
||
|
43232
|
43232
4023233P00 Seal-Grease, Front Hub9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NDK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
4023233P00 |
from US $10.28 |
||
|
43232
|
43232
40232-33P10
Seal-Grease, Front Hub
9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NOK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
40232-33P10 |
— | ||
| replacement | |||||
|
43232
|
43232
4023233P00 Seal-Grease, Front Hub9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NOK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
4023233P00 |
from US $10.28 |
||
|
43232
|
43232
4023233P00 Seal-Grease, Front Hub9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NDK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
4023233P00 |
from US $10.28 |
||
|
43232
|
43232
40232-33P10
Seal-Grease, Front Hub
9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NOK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
40232-33P10 |
— | ||
| replacement | |||||
|
43232
|
43232
4023233P00 Seal-Grease, Front Hub9709--01 ~ 9809--01; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4; NOK ﾄﾞﾁﾗﾃﾞﾓｼﾖｳｶ |
4023233P00 |
from US $10.28 |
||
|
43262A
|
43262A
400730L700 Pin-Cotter0012--01 ~ ; 4WD.SR20DE.MT.F5 +SR20DE.AT.F4 |
400730L700 |
from US $0.52 |
||
|
476
|
Anti skid control
476
|
||||
|
476
|
Anti skid control
476
|
||||
