transfer control & linkage (1986-05-01 ~ ; 4WD) Diagram Nissan PULSAR/LANGLEY/LIBERTA VILLA
- Year
- 1986 - 1988
- Sales region
- Japan
- Engine
- E15S
- drive
- 4WD
- transmission
- AT
- grade
- J1
- body
- S
- transmission/shift type
- F3
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
080108452A
|
080108452A
08010-8452A Bolt-hexagon |
08010-8452A |
US $2 |
||
|
081108452D
|
081108452D
08110-8452D
Bolt-hexagon
|
08110-8452D |
— | ||
|
081108452D
|
081108452D
08110-8452D
Bolt-hexagon
|
08110-8452D |
— | ||
|
081110252D
|
081110252D
08111-0252D
Bolt-hexagon
|
08111-0252D |
— | ||
|
081110452D
|
081110452D
08111-0452D
Bolt-hexagon
|
08111-0452D |
— | ||
|
083608252D
|
083608252D
08360-8252D
SCREWMACHINE
|
08360-8252D |
— | ||
|
089154382A
|
089154382A
089154382A
WASHERPLAIN
|
089154382A |
— | ||
|
34310
|
34310
34310-06R00 Actuator Assy-Transfer8605--01 ~ 8804--01; E15#.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
34310-06R00 |
US $672.60 |
||
|
34310
|
34310
0122500102 NUT8605--01 ~ 8804--01; E15#.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
0122500102 |
from US $1.89 |
||
|
34310B
|
34310B
0122500102 NUT8605--01 ~ 8804--01; E15#.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
0122500102 |
from US $1.89 |
||
|
34320
|
34320
34320-10R00 Bracket8605--01 ~ 8804--01; E15#.AT.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
34320-10R00 |
US $46.22 |
||
|
34341
|
34341
34341-06R00 Lever-Transfer8605--01 ~ 8804--01; E15#.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
34341-06R00 |
US $40.46 |
||
|
34341
|
34341
0122500102 NUT8605--01 ~ 8804--01; E15#.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
0122500102 |
from US $1.89 |
||
|
34341B
|
34341B
0122500102 NUT8605--01 ~ 8804--01; E15#.4WD; ﾊﾟ-ﾄﾀｲﾑ ﾖｳ |
0122500102 |
from US $1.89 |
