Rear door lock & handle (2006-09-01 ~ 2008-09-01; 4S) Diagram Nissan SENTRA/200SX
- Year
- 2006 - 2008
- Sales region
- U.S.A.
- Engine
- MR20DE
- transmission
- CVT
- grade
- 2.0
- body
- 4S
- area
- FED
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
085436122A
|
085436122A
08543-6122A
ｽｸﾘﾕ-,ﾀﾂﾋﾟﾝｸﾞ
|
08543-6122A |
— | ||
|
82500
|
82500
82500-ET200
Controller-Lock & Remote, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82500-ET200 |
— | ||
|
82501
|
82501
82501-ET200
Controller-Lock & Remote, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82501-ET200 |
— | ||
|
82512A
|
82512A
80599-AX000 Screw2006-09-01 ~ 2006-11-01; 4S; , |
80599-AX000 |
US $2.45 |
||
|
82512A
|
82512A
80599AX00E Screw2006-11-01 ~ 2008-09-01; 4S; , |
80599AX00E |
US $2.45 |
||
|
82512A
|
82512A
01433-00171 SCREW2006-09-01 ~ 2007-03-01; 4S; , |
01433-00171 |
from US $0.96 |
||
|
82512A
|
82512A
0143300181 SCREW2007-03-01 ~ 2008-09-01; 4S; , |
0143300181 |
US $2.45 |
||
|
82512AA
|
82512AA
01433-00171 SCREW2006-09-01 ~ 2007-03-01; 4S; , |
01433-00171 |
from US $0.96 |
||
|
82512AA
|
82512AA
0143300181 SCREW2007-03-01 ~ 2008-09-01; 4S; , |
0143300181 |
US $2.45 |
||
|
82550B
|
82550B
0114100471 BOLT2006-09-01 ~ 2008-09-01; 4S; , |
0114100471 |
US $2.45 |
||
|
82570M
|
82570M
80570-4Z000
Striker Assy-Front Door Lock
2006-09-01 ~ 2007-03-01; 4S; , |
80570-4Z000 |
— | ||
|
82570M
|
82570M
80570AA20A Striker Assy-Front Door Lock2007-03-01 ~ 2008-09-01; 4S; , |
80570AA20A |
from US $32.98 |
||
|
82605
|
82605
82606-ET00A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET00A |
— | ||
|
82605
|
82605
82606-ET00B
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET00B |
— | ||
|
82605
|
82605
82606-ET01A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET01A |
— | ||
|
82605
|
82605
82606-ET01B
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET01B |
— | ||
|
82605
|
82605
82606-ET02A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET02A |
— | ||
|
82605
|
82605
82606-ET03A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET03A |
— | ||
|
82605
|
82605
82606-ET04A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET04A |
— | ||
|
82605
|
82605
82606-ET05A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET05A |
— | ||
|
82605
|
82605
82606-ET06A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET06A |
— | ||
|
82605
|
82605
82606-ET07A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET07A |
— | ||
|
82605
|
82605
82606-ET08A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET08A |
— | ||
|
82605
|
82605
82606-ET09A
Handle Assy-Outside, Rear Door Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82606-ET09A |
— | ||
|
82605
|
82605
82610-ET00A
Bracket-Outside Handle, Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82610-ET00A |
— | ||
|
82605H
|
82605H
82610-ET00A
Bracket-Outside Handle, Rh
2006-09-01 ~ 2008-09-01; 4S; , |
82610-ET00A |
— | ||
|
82606
|
82606
82607-ET00A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET00A |
— | ||
|
82606
|
82606
82607-ET00B
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET00B |
— | ||
|
82606
|
82606
82607-ET01A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET01A |
— | ||
|
82606
|
82606
82607-ET01B
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET01B |
— | ||
|
82606
|
82606
82607-ET02A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET02A |
— | ||
|
82606
|
82606
82607-ET03A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET03A |
— | ||
|
82606
|
82606
82607-ET04A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET04A |
— | ||
|
82606
|
82606
82607-ET05A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET05A |
— | ||
|
82606
|
82606
82607-ET06A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET06A |
— | ||
|
82606
|
82606
82607-ET07A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET07A |
— | ||
|
82606
|
82606
82607-ET08A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET08A |
— | ||
|
82606
|
82606
82607-ET09A
Handle Assy-Outside, Rear Door Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82607-ET09A |
— | ||
|
82606
|
82606
82611-ET00A
Bracket-Outside Handle, Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82611-ET00A |
— | ||
|
82606H
|
82606H
82611-ET00A
Bracket-Outside Handle, Lh
2006-09-01 ~ 2008-09-01; 4S; , |
82611-ET00A |
— | ||
|
82652N
|
82652N
80652-ET000 Gasket-Outside Handle, Front Door2006-09-01 ~ 2008-09-01; 4S; , |
80652-ET000 |
US $2.24 |
||
|
82654N
|
82654N
80654-ET000
Gasket-Outside Handle, Front Door
2006-09-01 ~ 2008-09-01; 4S; , |
80654-ET000 |
— | ||
|
82670
|
82670
80670-ET005
Handle Assy-Rear Door Inside, Rh
2006-09-01 ~ 2008-09-01; 4S.2.0; , |
80670-ET005 |
— | ||
|
82670
|
82670
80670-ET006
Handle Assy-Rear Door Inside, Rh
2006-09-01 ~ 2008-09-01; 4S.2.0; , |
80670-ET006 |
— | ||
|
82670
|
82670
0128100111 GROMMET-SCREW2006-09-01 ~ 2007-08-01; 4S.2.0; , |
0128100111 |
from US $0.85 |
||
|
82670J
|
82670J
0128100111 GROMMET-SCREW2006-09-01 ~ 2007-08-01; 4S.2.0; , |
0128100111 |
from US $0.85 |
||
|
82671
|
82671
80671-ET005
Handle Assy-Rear Door Inside, Lh
2006-09-01 ~ 2008-09-01; 4S.2.0; , |
80671-ET005 |
— | ||
|
82671
|
82671
80671-ET006
Handle Assy-Rear Door Inside, Lh
2006-09-01 ~ 2008-09-01; 4S.2.0; , |
80671-ET006 |
— | ||
|
82676P
|
82676P
80676-ET005
Cap-Inside Handle, Rh
2006-09-01 ~ 2007-08-01; 4S.2.0; CHROME PLATED |
80676-ET005 |
— | ||
|
82676P
|
82676P
80676-ET006
Cap-Inside Handle, Rh
2007-08-01 ~ 2008-09-01; 4S.MR20DE; STD |
80676-ET006 |
— | ||
|
82677P
|
82677P
80677-ET005
Cap-Inside Handle, Lh
2006-09-01 ~ 2007-08-01; 4S.2.0; CHROME PLATED |
80677-ET005 |
— | ||
|
82677P
|
82677P
80677-ET006
Cap-Inside Handle, Lh
2007-08-01 ~ 2008-09-01; 4S.MR20DE; STD |
80677-ET006 |
— |
