Front brake (1978-10-01 ~ 1979-05-01; T) Diagram Nissan VANETTE
- Year
- 1978 - 1981
- Sales region
- Japan
- Engine
- A14S
- Number of doors
- 2
- grade
- DX
- body
- TH
- Roof
- STD
- body type
- SB
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
0812082210
|
0812082210
08120-82210
Bolt-hexagon
|
08120-82210 |
— | ||
|
0813401610
|
0813401610
08134-01610
Bolt-hexagon
|
08134-01610 |
— | ||
|
0891110810
|
0891110810
08911-10810
NUT
|
08911-10810 |
— | ||
| replacement | |||||
|
0891110810
|
0891110810
089111082A
NUTHEX
|
089111082A |
— | ||
|
0891513610
|
0891513610
08915-13610
ﾜﾂｼﾔ-,ｽﾌﾟﾘﾝｸﾞ
|
08915-13610 |
— | ||
|
41000
|
41000
41000-G3200 Brake Assy-Front, Rh7810--01 ~ 7907--01; T; ﾄﾞﾗﾑ ﾌﾞﾚ-ｷ |
41000-G3200 |
US $327.10 |
||
|
41000
|
41000
41000-G3610 ﾌﾞﾚ-ｷ ｱﾂｾﾝﾌﾞﾘ-,ﾌﾛﾝﾄ rh8209--01 ~ ; V+T+WV; ﾃﾞｲｽｸ ﾌﾞﾚ-ｷ |
41000-G3610 |
US $460.20 |
||
|
41000
|
41000
41060-W2786 Pad Kit-Disc Brake, Front8209--01 ~ ; V+T+WV; [B102] |
41060-W2786 |
US $90.72 |
||
|
41000
|
41000
AY600NS025 Seal Kit-Disc Brake8209--01 ~ ; "V+K+T WV+WK.(LX,LXG) |
AY600NS025 |
US $66.10 |
||
|
41010
|
41010
41010-G3200
Brake Assy-Front, Lh
7810--01 ~ 7907--01; T; ﾄﾞﾗﾑ ﾌﾞﾚ-ｷ |
41010-G3200 |
— | ||
|
41010
|
41010
41010-G3610 ﾌﾞﾚ-ｷ ｱﾂｾﾝﾌﾞﾘ-,ﾌﾛﾝﾄ lh8209--01 ~ ; V+T+WV; ﾃﾞｲｽｸ ﾌﾞﾚ-ｷ |
41010-G3610 |
US $471.53 |
||
|
41020
|
41020
41020-G3200 Plate Assy-Back, Front Brake Rh7810--01 ~ 7907--01; T |
41020-G3200 |
US $84.82 |
||
|
41027
|
41027
41027U8600 Spring-Adjusting, Front Brake7810--01 ~ 7907--01; T+V.SB.(CT,DX) |
41027U8600 |
US $1.58 |
||
|
41028
|
41028
41028-G3200 Cam-Adjusting, Front Brake7810--01 ~ 7907--01; T |
41028-G3200 |
US $13.82 |
||
|
41029
|
41029
41029-G3200 Stud-Adjusting7810--01 ~ 7907--01; T |
41029-G3200 |
US $13.68 |
||
|
41030
|
41030
41030-G3200 Plate Assy-Back, Front Brake Lh7810--01 ~ 7907--01; T |
41030-G3200 |
US $84.82 |
||
|
41060K
|
41060K
41060-G3225 Shoe Set-Front Brake7810--01 ~ 7907--01; T; [B102] |
41060-G3225 |
US $111.89 |
||
|
41081
|
41081
44081-M4901 Pin-Fixing Shoe7810--01 ~ 7907--01; T |
44081-M4901 |
from US $1.04 |
||
|
41082
|
41082
44082-U9200
Seat-Spring
7810--01 ~ 7907--01; T |
44082-U9200 |
— | ||
| replacement | |||||
|
41082
|
41082
44082U920A Seat-Spring7810--01 ~ 7907--01; T |
44082U920A |
from US $2.64 |
||
|
41083
|
41083
44083-32200 Spring7810--01 ~ 7907--01; T |
44083-32200 |
US $1.01 |
||
|
41084
|
41084
44084-U9200
Retainer-Spring, Anti Shoe Rattle
7810--01 ~ 7907--01; T |
44084-U9200 |
— | ||
| replacement | |||||
|
41084
|
41084
44084U920A Retainer-Spring, Anti Shoe Rattle7810--01 ~ 7907--01; T |
44084U920A |
from US $1.67 |
||
|
41084
|
41084
41084-06E00 SHIM-DISC BRAKE PAD,INNER8209--01 ~ ; V+K+T WV+WK; ｼｶｸ |
41084-06E00 |
US $15.70 |
||
|
41084
|
41084
41085-06E00 SHIM-PISTON COVER,INNER8209--01 ~ ; V+K+T WV+WK; ｼｶｸ |
41085-06E00 |
US $15.70 |
||
|
41090
|
41090
41090-10602 Spring-Return, Front Brake Shoe7810--01 ~ 7907--01; V.SB.(CT,DX)+T |
41090-10602 |
US $4.03 |
||
|
41090
|
41090
41090-10602 Spring-Return, Front Brake Shoe7810--01 ~ 7907--01; V.SB.(CT,DX)+T |
41090-10602 |
US $4.03 |
||
|
41100
|
41100
41101-G2500 Cylinder Assy-Front Wheel, After Rh7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
41101-G2500 |
US $46.22 |
||
|
41100
|
41100
D1100-G2526
Cup Kit-Brake Wheel Cylinder, Front
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
D1100-G2526 |
— | ||
|
41100K
|
41100K
D1100-G2526
Cup Kit-Brake Wheel Cylinder, Front
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
D1100-G2526 |
— | ||
|
41100K
|
41100K
D1100-G2526
Cup Kit-Brake Wheel Cylinder, Front
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
D1100-G2526 |
— | ||
|
41101
|
41101
41100-G2500 Cylinder Assy-Front Wheel, Fore Rh7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
41100-G2500 |
US $46.22 |
||
|
41102
|
41102
41103-G2500 Cylinder Assy-Front Wheel, After Lh7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
41103-G2500 |
US $46.22 |
||
|
41103
|
41103
41102-G2500 Cylinder Assy-Front Wheel, Fore Lh7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ 15/16 |
41102-G2500 |
US $46.22 |
||
|
41112
|
41112
41112-G2510 Cup-Piston7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41112-G2510 |
US $3.17 |
||
|
41112
|
41112
41112-G2510 Cup-Piston7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41112-G2510 |
US $3.17 |
||
|
41116
|
41116
41116-G2510 Seat-Spring7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41116-G2510 |
US $4.32 |
||
|
41116
|
41116
41116-G2510 Seat-Spring7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41116-G2510 |
US $4.32 |
||
|
41121
|
41121
41121-D0100 Piston-Cylinder8209--01 ~ ; !V+K+T WV+WK(LX,LXG) |
41121-D0100 |
US $82.08 |
||
|
41121
|
41121
41122-71410
Piston-Cylinder
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41122-71410 |
— | ||
|
41121
|
41121
41121-D0100 Piston-Cylinder8209--01 ~ ; !V+K+T WV+WK(LX,LXG) |
41121-D0100 |
US $82.08 |
||
|
41121
|
41121
41122-71410
Piston-Cylinder
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41122-71410 |
— | ||
|
41123
|
41123
41123-10610 Cover-Dust7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41123-10610 |
US $2.02 |
||
|
41123
|
41123
41123-10610 Cover-Dust7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41123-10610 |
US $2.02 |
||
|
41125
|
41125
41125-18411 Spring-Return7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41125-18411 |
US $1.58 |
||
|
41125
|
41125
41125-18411 Spring-Return7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41125-18411 |
US $1.58 |
||
|
41128
|
41128
41128-21015
ｽｸﾘﾕ-,ﾌﾞﾘ-ﾀﾞ-
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41128-21015 |
— | ||
|
41128
|
41128
41128-U3400
Screw-Bleeder
8209--01 ~ ; V+K+T WV+WK |
41128-U3400 |
— | ||
| replacement | |||||
|
41128
|
41128
4112880Z0A Screw-Bleeder8209--01 ~ ; V+K+T WV+WK |
4112880Z0A |
US $7.35 |
||
|
41129
|
41129
41129-A2410
Cap-Bleeder Screw
7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
41129-A2410 |
— | ||
| replacement | |||||
|
41129
|
41129
4112940F00 Cap-Bleeder Screw7810--01 ~ 7907--01; V.SB.(CT,DX)+T; ﾄｷｺ |
4112940F00 |
from US $1.07 |
||
|
41129
|
41129
41129-U3400 Cap-Bleeder8209--01 ~ ; V+K+T WV+WK |
41129-U3400 |
US $1.73 |
||
|
41140
|
41140
41140-G3200 Tube Assy-Bridge, Front Rh7810--01 ~ 7907--01; T |
41140-G3200 |
US $36.43 |
||
|
41140
|
41140
41140-G3201 Tube Assy-Bridge, Front Rh7906--01 ~ 8106--01; V.LB T.DX |
41140-G3201 |
US $36.43 |
||
|
41141
|
41141
41141-G3200 Tube Assy-Bridge, Front Lh7810--01 ~ 7907--01; T |
41141-G3200 |
US $36.43 |
||
|
41141
|
41141
41141-G3201 Tube Assy-Bridge, Front Lh7906--01 ~ 8106--01; V.LB T.DX |
41141-G3201 |
US $36.43 |
||
