Air duct ('07MY-; 255; 2006-04-01~) Diagram Subaru LEGACY
- Year
- 2006 - 2011
- Sales region
- Europe
- Engine
- 255
- drive
- 4W
- transmission
- 6MT
- grade
- 25GTB
- body
- S
- Suspension
- N/S
- Destinat
- RH
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
0104S
|
0104S
010408160 FLANGE BOLT2006-04-01 ~ 2007-06-01; 204 +255 +25# +30D |
010408160 |
from US $0.35 |
||
|
0104S
|
0104S
010410200 FLANGE BOLT2006-04-01 ~ 2007-06-01; 204 +255 +25# +30D |
010410200 |
US $0.71 |
||
|
0104S
|
0104S
010408160 FLANGE BOLT2006-04-01 ~ 2007-06-01; 204 +255 +25# +30D |
010408160 |
from US $0.35 |
||
|
0104S
|
0104S
010410200 FLANGE BOLT2006-04-01 ~ 2007-06-01; 204 +255 +25# +30D |
010410200 |
US $0.71 |
||
|
0104S
|
0104S
010408160 FLANGE BOLT2006-04-01 ~ 2007-06-01; 204 +255 +25# +30D |
010408160 |
from US $0.35 |
||
|
0104S
|
0104S
010410200 FLANGE BOLT2006-04-01 ~ 2007-06-01; 204 +255 +25# +30D |
010410200 |
US $0.71 |
||
|
14411
|
14411
14411AA670 CHGR ASSYTURBO2006-04-01 ~ 2007-06-01; 255 |
14411AA670 |
US $2,115.50 |
||
|
14421
|
14421
14421AA021 STAYTURBO2006-04-01 ~ 2007-06-01; 255 |
14421AA021 |
US $66.13 |
||
|
14427
|
14427
14427AA022 Stay-turbocharger,NO.22006-04-01 ~ 2007-06-01; 255 |
14427AA022 |
from US $5.25 |
||
|
14430
|
14430
14430AA18A
Pipe complete-turbo,no.2
2006-04-01 ~ 2007-01-01; 255 |
14430AA18A |
— | ||
|
14430A
|
14430A
14430AA230 ﾊﾟｲﾌﾟ ｺﾝﾌﾟﾘｰﾄ,ﾀｰﾎﾞ NO.22007-01-01 ~ 2007-06-01; 255 |
14430AA230 |
US $37.95 |
||
|
14430B
|
14430B
14430AA240 ﾊﾟｲﾌﾟ ｺﾝﾌﾟﾘｰﾄ,ﾀｰﾎﾞ NO.22007-01-01 ~ 2007-06-01; 255 |
14430AA240 |
US $37.95 |
||
|
14447
|
14447
14447AA150 HOSE ASSYTURBO2006-04-01 ~ 2007-06-01; 255 |
14447AA150 |
US $20.25 |
||
|
15194
|
15194
15194AA100 SCRUNION2006-04-01 ~ 2007-06-01; 255; M12 |
15194AA100 |
US $8.92 |
||
|
15194
|
15194
15194AA100 SCRUNION2006-04-01 ~ 2007-06-01; 255; M12 |
15194AA100 |
US $8.92 |
||
|
15196
|
15196
15196AA000 GSKTOIL TURBO2006-04-01 ~ 2007-06-01; 255 |
15196AA000 |
from US $0.46 |
||
|
15197
|
15197
15197AA070 OUTLETTURBO OIL2006-04-01 ~ 2007-06-01; 255 |
15197AA070 |
US $30.59 |
||
|
A30605
|
A30605
800306050 BOLTSKT 6X102006-04-01 ~ 2007-06-01; 255 |
800306050 |
US $1.56 |
||
|
A30605
|
A30605
800306050 BOLTSKT 6X102006-04-01 ~ 2007-06-01; 255 |
800306050 |
US $1.56 |
||
|
A70673
|
A70673
800706730 BOLT6X13X132006-04-01 ~ 2007-06-01; 255 |
800706730 |
US $1.42 |
||
|
A91034
|
A91034
800910340 STUD10X37X122006-04-01 ~ 2007-06-01; 255 |
800910340 |
from US $6.79 |
||
|
D91204
|
D91204
803912040 GASKET (12X16X1)2006-04-01 ~ 2007-06-01; 255; 12X6X1 |
803912040 |
from US $0.28 |
||
|
D91204
|
D91204
803912040 GASKET (12X16X1)2006-04-01 ~ 2007-06-01; 255; 12X6X1 |
803912040 |
from US $0.28 |
||
|
D91204
|
D91204
803912040 GASKET (12X16X1)2006-04-01 ~ 2007-06-01; 255; 12X6X1 |
803912040 |
from US $0.28 |
||
|
D91204
|
D91204
803912040 GASKET (12X16X1)2006-04-01 ~ 2007-06-01; 255; 12X6X1 |
803912040 |
from US $0.28 |
