intermediate shaft (M18A:2WD; 2005-12-01~2007-05-01) Diagram Suzuki AERIO
- Year
- 2005 - 2011
- Sales region
- Japan
- Engine
- M18A
- drive
- 2WD
- transmission
- AT
- Number of doors
- 4DR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
27800-54G10-000
シャフトアッシ,ドライブインタメジェート
M18A:2WD; 2005-12-01~2007-05-01 |
27800-54G10-000 |
— | ||
| replacement | |||||
|
1
|
1
27800-54G11-000 SHAFT ASSY,DRIVE INTERMEDIATEM18A:2WD; 2005-12-01~2007-05-01 |
27800-54G11-000 |
US $425.92 |
||
|
2
|
2
09381-25002-000 RING,SNAPM18A:2WD; 2005-12-01~2007-05-01 |
09381-25002-000 |
from US $1.85 |
||
|
3
|
3
27841-64G00-000 SEAL,DRIVE INTERMEDIATEM18A:2WD; 2005-12-01~2007-05-01 |
27841-64G00-000 |
from US $10.19 |
||
|
4
|
4
08331-41586-000
Circlip
M18A:2WD; 2005-12-01~2007-05-01 |
08331-41586-000 |
— | ||
| replacement | |||||
|
4
|
4
08331-4158A-000 CIRCLIPM18A:2WD; 2005-12-01~2007-05-01 |
08331-4158A-000 |
from US $2.56 |
||
|
5
|
5
09262-28030-000
Bearing,28x58x16
M18A:2WD; 2005-12-01~2007-05-01 |
09262-28030-000 |
— | ||
| replacement | |||||
|
5
|
5
27831-68L10-000 BEARING,DRIVE INTERMEDIATEM18A:2WD; 2005-12-01~2007-05-01 |
27831-68L10-000 |
from US $29.61 |
||
|
6
|
6
01550-1040A-000 BOLTM18A:2WD; 2005-12-01~2007-05-01 |
01550-1040A-000 |
from US $1.12 |
||
