water hose (2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01) Diagram Suzuki ALTO/A-STAR/CELERIO
- Year
- 1993 - 1994
- Sales region
- Japan
- Engine
- 2V
- supercharge
- TURBO
- drive
- 2WD
- transmission
- 3AT
- Number of doors
- 3DR
- grade
- SX
- type
- TYPE4
- body
- S
- air bag
- NAB
- abs
- NABS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
17561-72B52-000
キャップ,ウォータサーモスタツト
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17561-72B52-000 |
— | ||
| replacement | |||||
|
1
|
1
17561-72B53-000 CAP,WATER THERMOSTAT2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17561-72B53-000 |
US $64 |
||
|
2
|
2
01550-08253-000
Bolt, rear
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-08253-000 |
— | ||
| replacements | |||||
|
2
|
2
01550-0825B-000 Bolt2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-0825B-000 |
from US $1.06 |
||
|
2
|
2
01550-0825A-000 Bolt2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-0825A-000 |
from US $0.47 |
||
|
3
|
3
17600-85811-000 THERMOSTAT SET,WATER 82 DEG2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17600-85811-000 |
from US $21.38 |
||
|
4
|
4
17569-82001-H17 GASKET,WTR THERMO CAP2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17569-82001-H17 |
from US $1.82 |
||
|
5
|
5
17680-50F00-000
SWITCH,FAN THERMO
ガスケットアリ; 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17680-50F00-000 |
— | ||
| replacement | |||||
|
5
|
5
17680-50F01-000 Switch Comp,rdtr Fanガスケットアリ; 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17680-50F01-000 |
from US $36.80 |
||
|
6
|
6
17689-50F00-000 O-RING2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17689-50F00-000 |
from US $0.74 |
||
|
7
|
7
17550-72X50-000
CAP,WATER INLET
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17550-72X50-000 |
— | ||
|
8
|
8
17559-73000-H17
ガスケット,ウォータ,インレット
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17559-73000-H17 |
— | ||
| replacement | |||||
|
8
|
8
17559-73010-000 GASKET,WATER INLET PIPE2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17559-73010-000 |
from US $1.52 |
||
|
9
|
9
01550-06203-000
Bolt
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-06203-000 |
— | ||
| replacement | |||||
|
9
|
9
01550-0620B-000 BoltBolt, inspection cap 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-0620B-000 |
from US $0.76 |
||
|
10
|
10
17840-60D22-000
パイプ,ラジエータ,アウトレット
2V:TURBO:2WD:3AT; 1991-08-01~1994-09-01 |
17840-60D22-000 |
— | ||
| replacements | |||||
|
10
|
10
17840-60D2V-000
New Genuine Part
2V:TURBO:2WD:3AT; 1991-08-01~1994-09-01 |
17840-60D2V-000 |
— | ||
|
10
|
10
17854-50E60-000
HOSE,RDTR OUTLET
2V:TURBO:2WD:3AT; 1991-08-01~1994-09-01 |
17854-50E60-000 |
— | ||
|
10
|
10
17840-60D24-000
パイプ,ラジエータ,アウトレット
2V:TURBO:2WD:3AT; 1994-09-01~1994-11-01 |
17840-60D24-000 |
— | ||
| replacement | |||||
|
10
|
10
17840-60D2V-000
New Genuine Part
2V:TURBO:2WD:3AT; 1994-09-01~1994-11-01 |
17840-60D2V-000 |
— | ||
|
11
|
11
01550-06103-000
Bolt, front
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-06103-000 |
— | ||
| replacements | |||||
|
11
|
11
01550-0610B-000 BoltBolt 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-0610B-000 |
from US $0.96 |
||
|
11
|
11
01550-0610A-000 Bolt2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
01550-0610A-000 |
from US $0.96 |
||
|
12
|
12
17568-50F00-000 UNION BOLT,AIR VENTBolt, thermostat cover 2V:TURBO:2WD:3AT; 1991-08-01~1994-05-01 |
17568-50F00-000 |
from US $2.08 |
||
|
13
|
13
09168-06026-000 GASKET(6.4X11.5X0.8)2V:TURBO:2WD:3AT; 1991-08-01~1994-05-01 |
09168-06026-000 |
from US $0.91 |
||
|
14
|
14
17852-60D01-000
ホース,ラジエータ,インレット
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17852-60D01-000 |
— | ||
| replacement | |||||
|
14
|
14
17852-60D02-000
HOSE,RADIATOR INLET
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17852-60D02-000 |
— | ||
|
15
|
15
17854-50E51-000
ホース,ラジエータ,アウトレット
2V:TURBO:2WD:3AT; 1994-09-01~1994-11-01 |
17854-50E51-000 |
— | ||
| replacement | |||||
|
15
|
15
17854-50E60-000
HOSE,RDTR OUTLET
2V:TURBO:2WD:3AT; 1994-09-01~1994-11-01 |
17854-50E60-000 |
— | ||
|
15
|
15
17854-60D10-000
HOSE,RDTR OUTLET
2V:TURBO:2WD:3AT; 1991-08-01~1994-09-01 |
17854-60D10-000 |
— | ||
|
16
|
16
17856-50F10-000 HOSE,RADIATORL:210>120; 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17856-50F10-000 |
US $11.25 |
||
|
17
|
17
09400-34311-000 CLAMPCollier 2V:TURBO:2WD:3AT; 1991-08-01~1993-03-01 |
09400-34311-000 |
from US $1.92 |
||
|
17
|
17
09402-32511-000 CLAMP2V:TURBO:2WD:3AT; 1993-03-01~1994-11-01 |
09402-32511-000 |
from US $3.98 |
||
|
18
|
18
09402-32511-000 CLAMP2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
09402-32511-000 |
from US $3.98 |
||
|
19
|
19
17871-72B01-000
ホース,ヒータ,インレット
2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17871-72B01-000 |
— | ||
|
20
|
20
17872-72B50-000 HOSE,HEATER OUTLET2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
17872-72B50-000 |
US $67.20 |
||
|
21
|
21
09401-18403-000 CLIPClip, heater hose 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
09401-18403-000 |
from US $1.53 |
||
|
22
|
22
09401-18403-000 CLIPClip, heater hose 2V:TURBO:2WD:3AT; 1991-08-01~1994-11-01 |
09401-18403-000 |
from US $1.53 |
||
|
23
|
23
09251-07004-000 CAP2V:TURBO:2WD:3AT:(TYPE4,TYPE5); 1993-10-01~1994-11-01 |
09251-07004-000 |
US $43.40 |
||
|
24
|
24
09401-12404-000 CLIPClip 2V:TURBO:2WD:3AT:(TYPE4,TYPE5); 1993-10-01~1994-11-01 |
09401-12404-000 |
from US $1.10 |
||
