air cleaner (2V:EPI; 1994-10-01~1997-03-01) Diagram Suzuki ALTO/A-STAR/CELERIO
- Year
- 1995 - 1997
- Sales region
- Japan
- Engine
- 2V
- supercharge
- EPI
- drive
- 2WD
- transmission
- MT
- Number of doors
- 3DR
- grade
- AV
- number of the gears
- 5MT
- body
- S
- air bag
- AB-N
- abs
- ABS-N
- power steering
- PWST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
13700-72G10-000 CLEANER ASSY,AZR2V:EPI; 1994-10-01~1997-03-01 |
13700-72G10-000 |
US $187.68 |
||
|
2
|
2
13780-73B50-000 ELEMENT,AIR CLEANERDENSO; 2V:EPI; 1994-10-01~1997-03-01 |
13780-73B50-000 |
US $31.68 |
||
|
3
|
3
09320-11017-000 CUSHION2V:EPI; 1994-10-01~1997-03-01 |
09320-11017-000 |
from US $10.24 |
||
|
4
|
4
13772-72G10-000 SPACER2V:EPI; 1994-10-01~1997-03-01 |
13772-72G10-000 |
US $4.82 |
||
|
5
|
5
09116-06146-000 BOLT(6X25)Bolt (6x20) 2V:EPI; 1994-10-01~1997-03-01 |
09116-06146-000 |
from US $0.79 |
||
| replacement | |||||
|
5
|
5
09116-06150-000 BOLT(6X25)Bolt, air cleaner chamber 2V:EPI; 1994-10-01~1997-03-01 |
09116-06150-000 |
from US $1.28 |
||
|
6
|
6
13810-52E00-000
ブラケット,エアクリーナ,NO.1
2V:EPI; 1994-10-01~1997-03-01 |
13810-52E00-000 |
— | ||
|
7
|
7
02162-06123-000
Bolt (6x12)
2V:EPI; 1994-10-01~1997-03-01 |
02162-06123-000 |
— | ||
| replacements | |||||
|
7
|
7
02162-0612B-000 SCREWBolt 2V:EPI; 1994-10-01~1997-03-01 |
02162-0612B-000 |
from US $0.80 |
||
|
7
|
7
02162-0612A-000 SCREWBolt, bracket 2V:EPI; 1994-10-01~1997-03-01 |
02162-0612A-000 |
from US $0.79 |
||
|
8
|
8
13820-73B50-000
ブラケット,エアクリーナ,NO.2
2V:EPI; 1994-10-01~1997-03-01 |
13820-73B50-000 |
— | ||
|
9
|
9
13870-64F00-000
ホース,インテークエア
2V:EPI; 1994-10-01~1997-03-01 |
13870-64F00-000 |
— | ||
|
10
|
10
18495-50E00-000 Bolt2V:EPI; 1994-10-01~1997-03-01 |
18495-50E00-000 |
US $2.36 |
||
|
11
|
11
13881-64F00-000
ホース,エアクリーナ,アウトレット
2V:EPI; 1994-10-01~1997-03-01 |
13881-64F00-000 |
— | ||
|
12
|
12
13885-64F10-000
パイプ,スロットルボディ
2V:EPI; 1994-10-01~1997-03-01 |
13885-64F10-000 |
— | ||
|
13
|
13
13765-51E00-000
カラー,レゾネータ,NO.1
2V:EPI; 1994-10-01~1997-03-01 |
13765-51E00-000 |
— | ||
|
14
|
14
13766-51E00-000
カラー,レゾネータ,NO.2
2V:EPI; 1994-10-01~1997-03-01 |
13766-51E00-000 |
— | ||
|
15
|
15
02162-06163-000
Screw
2V:EPI; 1994-10-01~1997-03-01 |
02162-06163-000 |
— | ||
| replacement | |||||
|
15
|
15
02162-0616B-000 SCREWBolt, adjust 2V:EPI; 1994-10-01~1997-03-01 |
02162-0616B-000 |
from US $0.96 |
||
|
16
|
16
13499-51E00-000 HOSE,THROTTLE BODY2V:EPI; 1994-10-01~1997-03-01 |
13499-51E00-000 |
US $3.02 |
||
|
17
|
17
13760-64F00-000
レゾネータ,エアインテーク
2V:EPI; 1994-10-01~1997-03-01 |
13760-64F00-000 |
— | ||
|
18
|
18
09402-46208-000 CLAMP2V:EPI; 1994-10-01~1997-03-01 |
09402-46208-000 |
from US $1.96 |
||
|
19
|
19
09402-50208-000 CLAMP2V:EPI; 1994-10-01~1997-03-01 |
09402-50208-000 |
from US $5.76 |
||
|
20
|
20
13888-64F00-000
ホース,レゾネータ
2V:EPI; 1994-10-01~1997-03-01 |
13888-64F00-000 |
— | ||
|
21
|
21
13991-64F00-000
ブラケット,レゾネータ,NO.1
2V:EPI; 1994-10-01~1997-03-01 |
13991-64F00-000 |
— | ||
|
22
|
22
13993-64F00-000
ブラケット,レゾネータ,NO.2
2V:EPI; 1994-10-01~1997-03-01 |
13993-64F00-000 |
— | ||
|
23
|
23
13878-64F00-000
クッション
2V:EPI; 1994-10-01~1997-03-01 |
13878-64F00-000 |
— | ||
|
24
|
24
02162-06163-000
Screw
2V:EPI; 1994-10-01~1997-03-01 |
02162-06163-000 |
— | ||
| replacement | |||||
|
24
|
24
02162-0616B-000 SCREWBolt, adjust 2V:EPI; 1994-10-01~1997-03-01 |
02162-0616B-000 |
from US $0.96 |
||
|
25
|
25
01550-08163-000
Bolt, holder
2V:EPI; 1994-10-01~1997-03-01 |
01550-08163-000 |
— | ||
| replacements | |||||
|
25
|
25
01550-0816B-000 Bolt2V:EPI; 1994-10-01~1997-03-01 |
01550-0816B-000 |
from US $0.91 |
||
|
25
|
25
01550-0816A-000 BoltBolt, rear 2V:EPI; 1994-10-01~1997-03-01 |
01550-0816A-000 |
from US $0.91 |
||
|
26
|
26
17879-84300-000 BLIND2V:EPI; 1994-10-01~1997-03-01 |
17879-84300-000 |
from US $2.09 |
||
