throttle body (2V:EPI; 1994-10-01~1997-03-01) Diagram Suzuki ALTO/A-STAR/CELERIO
- Year
- 1995 - 1997
- Sales region
- Japan
- Engine
- 2V
- supercharge
- EPI
- drive
- 2WD
- transmission
- MT
- Number of doors
- 3DR
- grade
- AV
- number of the gears
- 5MT
- body
- S
- air bag
- AB-N
- abs
- ABS-N
- power steering
- PWST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
13400-64F02-000
ボディアッシ,スロットル
2V:EPI:MT; 1994-10-01~1997-03-01 |
13400-64F02-000 |
— | ||
|
2
|
2
13419-84150-000
PLUG
2V:EPI; 1994-10-01~1997-03-01 |
13419-84150-000 |
— | ||
|
3
|
3
13420-64D00-000
SENSOR,THROTTLE POSITION
2V:EPI:MT; 1994-10-01~1997-03-01 |
13420-64D00-000 |
— | ||
|
4
|
4
02112-74103-000
Screw
2V:EPI:MT; 1994-10-01~1997-03-01 |
02112-74103-000 |
— | ||
| replacement | |||||
|
4
|
4
02112-7410B-000 SCREW2V:EPI:MT; 1994-10-01~1997-03-01 |
02112-7410B-000 |
from US $3.71 |
||
|
5
|
5
13421-64D03-000 GASKET,THROTTLE BODY2V:EPI; 1994-10-01~1997-03-01 |
13421-64D03-000 |
US $2.40 |
||
|
6
|
6
01550-06203-000
Bolt
2V:EPI; 1994-10-01~1997-03-01 |
01550-06203-000 |
— | ||
| replacement | |||||
|
6
|
6
01550-0620B-000 BoltBolt, inspection cap 2V:EPI; 1994-10-01~1997-03-01 |
01550-0620B-000 |
from US $0.76 |
||
|
7
|
7
01550-06453-000
Bolt
2V:EPI; 1994-10-01~1997-03-01 |
01550-06453-000 |
— | ||
| replacement | |||||
|
7
|
7
01550-0645A-000 Bolt2V:EPI; 1994-10-01~1997-03-01 |
01550-0645A-000 |
from US $0.96 |
||
|
8
|
8
09352-70121-600 HOSE(7X12.1X600)Hose (inmani to iac) L:600>390; 2V:EPI; 1994-10-01~1997-03-01 |
09352-70121-600 |
from US $5.93 |
||
|
9
|
9
09352-70121-600 HOSE(7X12.1X600)Hose (inmani to iac) L:600>190; 2V:EPI; 1994-10-01~1997-03-01 |
09352-70121-600 |
from US $5.93 |
||
|
10
|
10
09352-13162-600 HOSE(13.5X16.5X600)Protector, seat damper L:600>120; 2V:EPI; 1994-10-01~1997-03-01 |
09352-13162-600 |
from US $11.40 |
||
|
11
|
11
09401-11407-000
CLIP
2V:EPI; 1994-10-01~1997-02-01 |
09401-11407-000 |
— | ||
| replacement | |||||
|
11
|
11
09401-11415-000 CLIP2V:EPI; 1994-10-01~1997-02-01 |
09401-11415-000 |
from US $1.06 |
||
|
11
|
11
09401-11415-000 CLIP2V:EPI; 1997-02-01~1997-03-01 |
09401-11415-000 |
from US $1.06 |
||
|
12
|
12
09408-00100-000 CLIP2V:EPI; 1994-10-01~1997-03-01 |
09408-00100-000 |
US $19.50 |
||
|
13
|
13
15910-64D00-000
ケーブルアッシ,アクセル
2V:EPI; 1994-10-01~1997-03-01 |
15910-64D00-000 |
— | ||
| replacement | |||||
|
13
|
13
15910-64D01-000
CABLE ASSY,ACCEL
2V:EPI; 1994-10-01~1997-03-01 |
15910-64D01-000 |
— | ||
|
14
|
14
09408-00079-000 CLAMP2V:EPI; 1994-10-01~1997-03-01 |
09408-00079-000 |
from US $0.65 |
||
|
15
|
15
15919-64D00-000
ガイド,アクセルケーブル
2V:EPI; 1994-10-01~1997-03-01 |
15919-64D00-000 |
— | ||
|
16
|
16
01550-06163-000
Bolt
2V:EPI; 1994-10-01~1997-03-01 |
01550-06163-000 |
— | ||
| replacements | |||||
|
16
|
16
01550-0616B-000 Bolt2V:EPI; 1994-10-01~1997-03-01 |
01550-0616B-000 |
from US $0.76 |
||
|
16
|
16
01550-0616A-000 Bolt2V:EPI; 1994-10-01~1997-03-01 |
01550-0616A-000 |
from US $0.76 |
||
