Front bumper (FRONT BUMPER) Diagram Suzuki ALTO/A-STAR/CELERIO
- Year
- -
- Sales region
- Pacific
- transmission
- MT
- grade
- DX
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
71091-M8400-000
Bumper front
|
71091-M8400-000 |
— | ||
|
2
|
2
09136-06104-000 SCREW(6X16) |
09136-06104-000 |
US $13.20 |
||
|
3
|
3
57515-M7901-100
Retainer, licence plate
|
57515-M7901-100 |
— | ||
|
4
|
4
71712-M8400-000
Holder, frt bumper side
|
71712-M8400-000 |
— | ||
|
5
|
5
03511-05123-000
SCREW 5X12
|
03511-05123-000 |
— | ||
| replacement | |||||
|
5
|
5
03511-0512A-000 SCREW |
03511-0512A-000 |
from US $0.96 |
||
|
6
|
6
71713-M8430-000
Stay, front bumper rh
|
71713-M8430-000 |
— | ||
|
7
|
7
71714-M8430-000
Stay, front bumper lh
|
71714-M8430-000 |
— | ||
|
8
|
8
01514-M0612-600
Screw, stay
|
01514-M0612-600 |
— | ||
|
9
|
9
71715-M8430-000
Bracket, bumper rh
|
71715-M8430-000 |
— | ||
|
10
|
10
71716-M8430-000
Bracket, bumper lh
|
71716-M8430-000 |
— | ||
|
11
|
11
71717-M8430-000
Bracket, bumper ctr
|
71717-M8430-000 |
— | ||
|
12
|
12
02142-M0616-600
Screw
|
02142-M0616-600 |
— | ||
|
13
|
13
01514-M0612-600
Screw, stay
|
01514-M0612-600 |
— | ||
|
14
|
14
02142-M0612-600
Screw
|
02142-M0612-600 |
— | ||
|
15
|
15
03541-05123-000
Screw
|
03541-05123-000 |
— | ||
| replacement | |||||
|
15
|
15
03541-0512B-000 SCREW |
03541-0512B-000 |
from US $0.76 |
||
|
16
|
16
72111-M8400-000
Grille, radiator
|
72111-M8400-000 |
— | ||
|
17
|
17
72121-M8400-000
Panel, water proof plug
|
72121-M8400-000 |
— | ||
|
18
|
18
09136-04005-000 SCREW(4X12) |
09136-04005-000 |
US $15.80 |
||
| replacement | |||||
|
18
|
18
09136-04003-000 SCREW(4X10)Screw, inner panel upper |
09136-04003-000 |
from US $4.28 |
||
|
19
|
19
77811-M8431-000
Emblem maruti grille
|
77811-M8431-000 |
— | ||
|
20
|
20
09329-M0300-200
Cushion
|
09329-M0300-200 |
— | ||
|
21
|
21
09139-05035-000
スクリュ
|
09139-05035-000 |
— | ||
| replacement | |||||
|
21
|
21
09139-05056-000 SCREW(5X15.5) |
09139-05056-000 |
US $1.22 |
||
|
22
|
22
09165-05006-000
ワッシャ
|
09165-05006-000 |
— | ||
|
23
|
23
09148-M0500-300
Split nut 2 way valve mtg
|
09148-M0500-300 |
— | ||
|
24
|
24
09320-M0501-400
Cushion
|
09320-M0501-400 |
— | ||
|
25
|
25
72124-M8400-000
Bezel, head lamp rh
|
72124-M8400-000 |
— | ||
|
26
|
26
72134-M8400-000
Bezel, head lamp lh
|
72134-M8400-000 |
— | ||
|
27
|
27
09409-10304-000 CLIP |
09409-10304-000 |
from US $1.22 |
||
| replacement | |||||
|
27
|
27
09409-10304-5ES CLIP(BLACK) |
09409-10304-5ES |
from US $0.88 |
||
