Front panel (FRONT PANEL) Diagram Suzuki CARRY/SUPER CARRY
- Year
- -
- Sales region
- Africa
- grade
- TA
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
58300-85200-000
Panel assy, front
LHD:TA |
58300-85200-000 |
— | ||
|
1
|
1
58300-85220-000
Panel assy, front
TYPE 1, LHD:TX |
58300-85220-000 |
— | ||
|
1
|
1
58300-85730-000
Panel assy, front
TYPE 2, LHD:TX |
58300-85730-000 |
— | ||
|
2
|
2
58300-85010-000
Panel assy, front
RHD:TA |
58300-85010-000 |
— | ||
|
2
|
2
58300-85710-000
Panel assy, front
TYPE 1, RHD:TX |
58300-85710-000 |
— | ||
|
2
|
2
58300-85740-000
Panel assy, front
TYPE 2, RHD:TX |
58300-85740-000 |
— | ||
|
2
|
2
58300-85270-000
Panel assy, front
|
58300-85270-000 |
— | ||
|
2
|
2
58300-85750-000
Panel assy, front
TYPE 2:Finland |
58300-85750-000 |
— | ||
|
3
|
3
65931-85210-000 COVER,HEATER CONTROL BOX HOLELHD:N/HEATER |
65931-85210-000 |
US $7.88 |
||
|
3
|
3
65931-85200-000
Cover, htr control box hole
RHD:N/HEATER |
65931-85200-000 |
— | ||
|
4
|
4
02142-06108-000
6 x 10 screw
N/HEATER |
02142-06108-000 |
— | ||
| replacement | |||||
|
4
|
4
02142-06107-000 SCREWN/HEATER |
02142-06107-000 |
from US $0.80 |
||
