Front floor (T/K) Diagram Suzuki CARRY/SUPER CARRY
- Year
- -
- Sales region
- Africa
- transmission
- 5MT
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
61100-85200-000
PANEL ASSY,FRONT FLOOR
LHD |
61100-85200-000 |
— | ||
|
1
|
1
61100-85000-000
パネルアッシ,フロントフロア
RHD |
61100-85000-000 |
— | ||
| replacement | |||||
|
1
|
1
09250-10016-000 CAP(OD:16.2)RHD |
09250-10016-000 |
US $9.90 |
||
|
2
|
2
61140-74D00-000
パネル,サイドシルインナリヤ,ライト
|
61140-74D00-000 |
— | ||
| replacement | |||||
|
2
|
2
61140-72D20-000 PANEL,SIDE SILL INNER RR,R |
61140-72D20-000 |
US $105.64 |
||
|
3
|
3
61150-72D20-000
PANEL,SIDE SILL INNER RR,L
|
61150-72D20-000 |
— | ||
|
4
|
4
75431-85001-000
VALVE,SIDE SILL INNER,REAR
|
75431-85001-000 |
— | ||
|
4
|
4
75431-70D00-000
バルブ,サイドシルインナ,リヤ
DA21T-120830~ DA21V-133347~,JSAEDA21V00132928~,JSAEDA21V0B130226~ |
75431-70D00-000 |
— | ||
| replacements | |||||
|
4
|
4
09409-10304-5ES CLIP(BLACK)DA21T-120830~ DA21V-133347~,JSAEDA21V00132928~,JSAEDA21V0B130226~ |
09409-10304-5ES |
US $1.28 |
||
|
4
|
4
75431-70D01-000 VALVE,SIDE SILL INNER REARDA21T-120830~ DA21V-133347~,JSAEDA21V00132928~,JSAEDA21V0B130226~ |
75431-70D01-000 |
US $8.98 |
||
|
5
|
5
59710-75D50-000
Crossmember comp,floor,front
|
59710-75D50-000 |
— | ||
|
6
|
6
65400-85401-000 PANEL ASSY,CABIN BACKN/E.L.R SEAT BELT |
65400-85401-000 |
US $418.88 |
||
|
6
|
6
65400-85241-000
Panel assy, cabin back
W/E.L.R SEAT BELT |
65400-85241-000 |
— | ||
| replacements | |||||
|
6
|
6
09118-08128-000 BOLT(8X16)Bolt, front fender, front W/E.L.R SEAT BELT |
09118-08128-000 |
US $1.28 |
||
|
6
|
6
65400-85221-000
PANEL ASSY,CABIN BACK
W/E.L.R SEAT BELT |
65400-85221-000 |
— | ||
|
6
|
6
09118-08001-000
Bolt
W/E.L.R SEAT BELT |
09118-08001-000 |
— | ||
|
7
|
7
81111-85000-000 BAR,BACK WINDOW GUARD |
81111-85000-000 |
US $12.01 |
||
|
8
|
8
02142-06103-000
Screw
|
02142-06103-000 |
— | ||
| replacements | |||||
|
8
|
8
02142-0610B-000 SCREWStopper, cl rlse cam shaft |
02142-0610B-000 |
from US $0.76 |
||
|
8
|
8
02142-0610A-000 SCREW |
02142-0610A-000 |
from US $0.80 |
||
|
9
|
9
03141-06123-000
Screw 6x12
|
03141-06123-000 |
— | ||
| replacement | |||||
|
9
|
9
03141-0612A-000 SCREW |
03141-0612A-000 |
US $0.76 |
||
|
10
|
10
75410-85200-000
Member, engine room center
->75410-85720 USED WITH,09250-17001(2PCS) |
75410-85200-000 |
— | ||
| replacements | |||||
|
10
|
10
09250-17001-000 CAP(OD:25.5)->75410-85720 USED WITH,09250-17001(2PCS) |
09250-17001-000 |
US $1.06 |
||
|
10
|
10
75410-85720-000
MEMBER,ENG ROOM CTR
->75410-85720 USED WITH,09250-17001(2PCS) |
75410-85720-000 |
— | ||
|
10
|
10
75410-85720-000
MEMBER,ENG ROOM CTR
DA21T-132803~ |
75410-85720-000 |
— | ||
|
11
|
11
65921-85001-000
ブラケット,シートベルト,センタ
|
65921-85001-000 |
— | ||
|
12
|
12
08316-16083-000 NutNut |
08316-16083-000 |
US $3.06 |
||
| replacement | |||||
|
12
|
12
08316-1008B-000 NUT |
08316-1008B-000 |
from US $0.76 |
||
|
13
|
13
01550-06127-000 BOLTBolt, rect |
01550-06127-000 |
from US $0.68 |
||
|
14
|
14
75421-85000-000 BRACKET,JACK |
75421-85000-000 |
US $6.66 |
||
|
15
|
15
01550-06123-000
Bolt
|
01550-06123-000 |
— | ||
| replacements | |||||
|
15
|
15
01550-0612B-000 BOLTBolt, clamp |
01550-0612B-000 |
from US $0.76 |
||
|
15
|
15
01550-0612A-000 BOLT |
01550-0612A-000 |
from US $0.76 |
||
|
16
|
16
09250-30015-000
Cap
|
09250-30015-000 |
— | ||
| replacement | |||||
|
16
|
16
72999-67H00-000 CAP,OD:40 |
72999-67H00-000 |
from US $4.32 |
||
|
17
|
17
09250-10005-000 CAP(OD:15) |
09250-10005-000 |
US $14.70 |
||
|
18
|
18
09250-10017-000 PLUG(OD:22) |
09250-10017-000 |
US $17.70 |
||
|
19
|
19
66511-79060-000
COVER,ACCEL WIRE,L
|
66511-79060-000 |
— | ||
|
20
|
20
03142-05109-000
Screw 5x10
|
03142-05109-000 |
— | ||
| replacement | |||||
|
20
|
20
03142-0510B-000 SCREW |
03142-0510B-000 |
US $0.80 |
||
|
21
|
21
09250-07001-000 CAP(OD:10)N/HEATER |
09250-07001-000 |
US $11 |
||
|
22
|
22
09250-25007-000 CAP(OD:25.0)N/HEATER |
09250-25007-000 |
from US $0.97 |
||
|
23
|
23
09250-20002-000
キャップ,OD:30
|
09250-20002-000 |
— | ||
| replacements | |||||
|
23
|
23
09250-20009-000
CAP(OD:30)
|
09250-20009-000 |
— | ||
|
23
|
23
09250-20034-000 Cap(Od:30) |
09250-20034-000 |
US $11.40 |
||
|
24
|
24
09250-20002-000
キャップ,OD:30
|
09250-20002-000 |
— | ||
| replacements | |||||
|
24
|
24
09250-20009-000
CAP(OD:30)
|
09250-20009-000 |
— | ||
|
24
|
24
09250-20034-000 Cap(Od:30) |
09250-20034-000 |
US $11.40 |
||
|
25
|
25
09409-05308-5PK CLIP(BLACK)DA21T-120830~ DA21V-133347~,JSAEDA21V00132928~,JSAEDA21V0B130226~ |
09409-05308-5PK |
from US $1.60 |
||
|
26
|
26
09250-17001-000 CAP(OD:25.5)DA21T-132803~ |
09250-17001-000 |
US $1.06 |
||
