Front panel (ST90V) Diagram Suzuki CARRY/SUPER CARRY
- Year
- -
- Sales region
- Africa
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
61200-79810-000
Panel assy, front
TO 61200-79830, USED WITH,38480-80000:TYPE 1:RHD |
61200-79810-000 |
— | ||
|
1
|
1
61200-79830-000
Panel assy, front
TYPE 2:RHD |
61200-79830-000 |
— | ||
|
1
|
1
61200-79820-000
Panel assy, front
TO 61200-79840, USED WITH,38480-80000:TYPE 1:LHD |
61200-79820-000 |
— | ||
|
1
|
1
61200-79840-000
Panel assy, front
TYPE 2:LHD |
61200-79840-000 |
— | ||
|
2
|
2
61200-79850-000
Panel assy, front
TYPE 3:RHD |
61200-79850-000 |
— | ||
| replacements | |||||
|
2
|
2
09160-06019-000 WASHER(6.5X16X1.2)Washer (6.5x16x1.2) TYPE 3:RHD |
09160-06019-000 |
from US $0.76 |
||
|
2
|
2
01500-0616A-000 BoltTYPE 3:RHD |
01500-0616A-000 |
from US $0.76 |
||
|
2
|
2
08321-0106A-000 WASHER,LOCKTYPE 3:RHD |
08321-0106A-000 |
from US $0.76 |
||
|
2
|
2
08321-21066-000
Lock washer
TYPE 3:RHD |
08321-21066-000 |
— | ||
|
2
|
2
01107-06166-000
Bolt
TYPE 3:RHD |
01107-06166-000 |
— | ||
|
2
|
2
61200-79860-000
Panel assy, front
TYPE 3:LHD |
61200-79860-000 |
— | ||
| replacements | |||||
|
2
|
2
09160-06019-000 WASHER(6.5X16X1.2)Washer (6.5x16x1.2) TYPE 3:LHD |
09160-06019-000 |
from US $0.76 |
||
|
2
|
2
08321-0106A-000 WASHER,LOCKTYPE 3:LHD |
08321-0106A-000 |
from US $0.76 |
||
|
2
|
2
01500-0616A-000 BoltTYPE 3:LHD |
01500-0616A-000 |
from US $0.76 |
||
|
2
|
2
01107-06166-000
Bolt
TYPE 3:LHD |
01107-06166-000 |
— | ||
|
2
|
2
08321-21066-000
Lock washer
TYPE 3:LHD |
08321-21066-000 |
— | ||
|
2
|
2
61200-79870-000
Panel assy, front
TYPE 3:Finland |
61200-79870-000 |
— | ||
| replacements | |||||
|
2
|
2
09160-06019-000 WASHER(6.5X16X1.2)Washer (6.5x16x1.2) TYPE 3:Finland |
09160-06019-000 |
from US $0.76 |
||
|
2
|
2
08321-0106A-000 WASHER,LOCKTYPE 3:Finland |
08321-0106A-000 |
from US $0.76 |
||
|
2
|
2
01500-0616A-000 BoltTYPE 3:Finland |
01500-0616A-000 |
from US $0.76 |
||
|
2
|
2
01107-06166-000
Bolt
TYPE 3:Finland |
01107-06166-000 |
— | ||
|
2
|
2
08321-21066-000
Lock washer
TYPE 3:Finland |
08321-21066-000 |
— | ||
|
3
|
3
61271-79001-000 PILLAR,FR OUTER UPPER RHFROM 61271-79000 |
61271-79001-000 |
US $63.09 |
||
|
4
|
4
61281-79000-000 PILLAR,FR OUTER UPPER LH |
61281-79000-000 |
US $54.72 |
||
|
5
|
5
61291-79000-000
Frame, roof front inner
|
61291-79000-000 |
— | ||
| replacement | |||||
|
5
|
5
61290-79000-000
Frame,roof front inner
|
61290-79000-000 |
— | ||
|
5
|
5
61291-79220-000
Frame, roof front inner
TYPE 3:Australia |
61291-79220-000 |
— | ||
|
6
|
6
67220-79001-000
Panel, front inner rh
RHD |
67220-79001-000 |
— | ||
| replacement | |||||
|
6
|
6
67220-79400-000
PANEL,PILLAR INNER,R
RHD |
67220-79400-000 |
— | ||
|
6
|
6
67220-79060-000
Panel, front inner rh
TO 67220-79061, USED WITH,67310-79061,LHD GRIP NUT:1PC. |
67220-79060-000 |
— | ||
| replacements | |||||
|
6
|
6
67220-79061-000
PANEL,FR PILLAR INNER RH
TO 67220-79061, USED WITH,67310-79061,LHD GRIP NUT:1PC. |
67220-79061-000 |
— | ||
|
6
|
6
67310-79061-000
FRAME,ROOF SIDE INNER RH
TO 67220-79061, USED WITH,67310-79061,LHD GRIP NUT:1PC. |
67310-79061-000 |
— | ||
|
6
|
6
67220-79061-000
PANEL,FR PILLAR INNER RH
LHD GRIP NUT:0PC. |
67220-79061-000 |
— | ||
|
6
|
6
67220-79070-000
Panel, front inner rh
TYPE 3:Finland |
67220-79070-000 |
— | ||
|
7
|
7
67270-79001-000
Panel, front inner lh
TO 67270-79002, USED WITH,67360-79001,RHD, FROM 67270-79000,GRIP NUT:1PC. |
67270-79001-000 |
— | ||
| replacement | |||||
|
7
|
7
67270-79400-000
PANEL,PILLAR INNER,L
TO 67270-79002, USED WITH,67360-79001,RHD, FROM 67270-79000,GRIP NUT:1PC. |
67270-79400-000 |
— | ||
|
7
|
7
67270-79002-000
Panel, front inner lh
RHD GRIP NUT:0PC. |
67270-79002-000 |
— | ||
| replacement | |||||
|
7
|
7
67270-79400-000
PANEL,PILLAR INNER,L
RHD GRIP NUT:0PC. |
67270-79400-000 |
— | ||
|
7
|
7
67270-79061-000
Panel, front inner lh
LHD, FROM 67270-79060 |
67270-79061-000 |
— | ||
|
8
|
8
67310-79061-000
FRAME,ROOF SIDE INNER RH
FROM 67310-79060 |
67310-79061-000 |
— | ||
|
9
|
9
67360-79001-000
FRAME,ROOF SIDE INNER LH
FROM 67360-79000 |
67360-79001-000 |
— | ||
|
10
|
10
67510-79501-000
PANEL,CENTER PILLAR INNER RH
FROM 67510-79500 |
67510-79501-000 |
— | ||
|
10
|
10
67510-79722-000
Panel, center inner rh
,,Finland,Switzerland,Belgium,2,4,5,Austria,Channel Islands,Israel FROM 67510-79721 |
67510-79722-000 |
— | ||
|
10
|
10
67510-79711-000
Panel, center inner rh
New Zealand |
67510-79711-000 |
— | ||
|
11
|
11
67560-79500-000
PANEL,CENTER PILLAR INNER LH
|
67560-79500-000 |
— | ||
|
11
|
11
67560-79721-000
Panel, center inner lh
,,Finland,Switzerland,Belgium,2,4,5,Austria,Channel Islands,Israel |
67560-79721-000 |
— | ||
|
11
|
11
67560-79710-000
Panel, center inner lh
New Zealand |
67560-79710-000 |
— | ||
|
12
|
12
67341-79001-000 REINFORCEMENT,ROOF SIDE INR,RFROM 67341-79000 |
67341-79001-000 |
US $12.77 |
||
|
13
|
13
67391-79001-000 REINFORCEMENT,ROOF SIDE INR,LFROM 67391-79000 |
67391-79001-000 |
US $12.77 |
||
|
14
|
14
68230-79000-000 PANEL,FR PILLAR OUTER LOWER RH |
68230-79000-000 |
US $105.25 |
||
|
15
|
15
68280-79000-000 PANEL,FR PILLAR OUTER LOWER LH |
68280-79000-000 |
US $105.25 |
||
|
16
|
16
68311-79000-000 FRAME,ROOF SIDE OUTER RH |
68311-79000-000 |
US $25.94 |
||
|
17
|
17
68361-79000-000 FRAME,ROOF SIDE OUTER LH |
68361-79000-000 |
US $25.58 |
||
|
18
|
18
68331-79500-000 RAIL,ROOF DRIP RH |
68331-79500-000 |
US $47.47 |
||
|
19
|
19
68381-79500-000 RAIL,ROOF DRIP LH |
68381-79500-000 |
US $35.70 |
||
|
20
|
20
68410-79401-000
PANEL,SIDE SILL OUTER RH
FROM 68410-79400 |
68410-79401-000 |
— | ||
|
20
|
20
68412-79231-000
Panel, side sill outer rh
,,Finland,Switzerland,Belgium,2,5,Austria,Channel Islands,Israel,Iceland FROM 68412-79230 |
68412-79231-000 |
— | ||
| replacement | |||||
|
20
|
20
68410-79401-000
PANEL,SIDE SILL OUTER RH
,,Finland,Switzerland,Belgium,2,5,Austria,Channel Islands,Israel,Iceland FROM 68412-79230 |
68410-79401-000 |
— | ||
|
21
|
21
68460-79401-000 PANEL,SIDE SILL OUTER LHFROM 68460-79400 |
68460-79401-000 |
US $294.40 |
||
|
21
|
21
68462-79231-000
Panel, side sill outer lh
,,Finland,Switzerland,Belgium,2,5,Austria,Channel Islands,Israel,Iceland FROM 68462-79230 |
68462-79231-000 |
— | ||
| replacement | |||||
|
21
|
21
68460-79401-000 PANEL,SIDE SILL OUTER LH,,Finland,Switzerland,Belgium,2,5,Austria,Channel Islands,Israel,Iceland FROM 68462-79230 |
68460-79401-000 |
US $294.40 |
||
|
22
|
22
68411-79000-000
Panel, outer rh
|
68411-79000-000 |
— | ||
| replacement | |||||
|
22
|
22
68411-79230-000 PANEL,FR WHEEL HOUSE OUTER,R |
68411-79230-000 |
US $16.80 |
||
|
22
|
22
68411-79230-000 PANEL,FR WHEEL HOUSE OUTER,R,,Finland,Switzerland,Belgium,2,5,Austria,Channel Islands,Israel,Iceland |
68411-79230-000 |
US $16.80 |
||
|
23
|
23
68461-79000-000
Panel, outer lh
|
68461-79000-000 |
— | ||
| replacement | |||||
|
23
|
23
68461-79230-000 PANEL,FR WHEEL HOUSE OUTER,L |
68461-79230-000 |
US $16.80 |
||
|
23
|
23
68461-79230-000 PANEL,FR WHEEL HOUSE OUTER,L,,Finland,Switzerland,Belgium,2,5,Austria,Channel Islands,Israel,Iceland |
68461-79230-000 |
US $16.80 |
||
|
24
|
24
68510-79511-000
Panel, center outer rh
FROM 68510-79510 |
68510-79511-000 |
— | ||
|
25
|
25
68560-79501-000
PANEL,CTR PILLAR OUTER,L
FROM 68560-79500 |
68560-79501-000 |
— | ||
|
26
|
26
61295-79050-000
Cover, hole
TYPE 1,TYPE 2,NONHEATER TYPE |
61295-79050-000 |
— | ||
|
27
|
27
61295-79051-000
Cover, hole
TYPE 3:RHD NONHEATER TYPE |
61295-79051-000 |
— | ||
|
27
|
27
61295-79061-000
Cover, hole
TYPE 3:LHD NONHEATER |
61295-79061-000 |
— | ||
|
28
|
28
02142-06108-000
6 x 10 screw
NONHEATER TYPE |
02142-06108-000 |
— | ||
| replacement | |||||
|
28
|
28
02142-06107-000 SCREWNONHEATER TYPE |
02142-06107-000 |
from US $0.80 |
||
|
29
|
29
09250-02001-000
CAP(OD:6)
NON RADIO TYPE |
09250-02001-000 |
— | ||
| replacement | |||||
|
29
|
29
09250-02002-000 Cap(Od:6)NON RADIO TYPE |
09250-02002-000 |
US $1.92 |
||
|
30
|
30
09250-14003-000 CAP(OD:18)NON RADIO TYPE |
09250-14003-000 |
US $2.08 |
||
