Front floor (ST90, K) Diagram Suzuki CARRY/SUPER CARRY
- Year
- -
- Sales region
- Africa
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
65400-79200-000
Panel assy, front floor
TYPE 1,TYPE 2:RHD |
65400-79200-000 |
— | ||
|
1
|
1
65400-79222-000
Panel assy, front floor
TYPE 3:RHD |
65400-79222-000 |
— | ||
|
1
|
1
65400-79210-000
Panel assy, front floor
TYPE 1,TYPE 2:LHD |
65400-79210-000 |
— | ||
|
1
|
1
65400-79291-000
Panel assy, front floor
TYPE 3:LHD |
65400-79291-000 |
— | ||
|
1
|
1
65400-79230-000
Panel assy, front floor
TYPE 1,TYPE 2: |
65400-79230-000 |
— | ||
|
1
|
1
65400-79232-000
Panel assy, front floor
TYPE 3: |
65400-79232-000 |
— | ||
|
1
|
1
65400-79240-000
Panel assy, front floor
TYPE 1,TYPE 2:Finland,Switzerland,Belgium,Holland,Channel Islands |
65400-79240-000 |
— | ||
|
1
|
1
65400-79260-000
Panel assy, front floor
TYPE 3:Switzerland,Finland,Belgium,Holland,Channel Islands,Israel,FROM 65400-79242 |
65400-79260-000 |
— | ||
|
2
|
2
65450-79000-000
PANEL,FR FLOOR INNER FR RH
|
65450-79000-000 |
— | ||
|
2
|
2
65450-79230-000
Panel, inner front rh
,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
65450-79230-000 |
— | ||
|
3
|
3
65461-79000-000
PANEL,FR FLOOR INNER FR LH
|
65461-79000-000 |
— | ||
|
3
|
3
65461-79230-000
Panel, inner front lh
,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
65461-79230-000 |
— | ||
|
4
|
4
65470-79100-000
Panel, inner rear rh
FROM 65470-79000 |
65470-79100-000 |
— | ||
|
4
|
4
65470-79220-000
Panel, inner rear rh
TYPE 3:Australia |
65470-79220-000 |
— | ||
|
4
|
4
65470-79230-000
Panel, inner rear rh
,Finland,Switzerland,Belgium,5,Channel Islands |
65470-79230-000 |
— | ||
|
5
|
5
65480-79100-000
Panel, inner rear lh
|
65480-79100-000 |
— | ||
|
5
|
5
65480-79230-000
Panel, inner rear lh
,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
65480-79230-000 |
— | ||
|
6
|
6
65492-79060-000
Cover, floor front rh
LHD |
65492-79060-000 |
— | ||
|
7
|
7
03141-06108-000
New Genuine Part
LHD |
03141-06108-000 |
— | ||
| replacement | |||||
|
7
|
7
03141-0610A-000 SCREWLHD |
03141-0610A-000 |
US $0.80 |
||
|
8
|
8
79955-70000-000
VALVE
|
79955-70000-000 |
— | ||
|
9
|
9
09250-30002-000
キャップ,OD:30
|
09250-30002-000 |
— | ||
| replacement | |||||
|
9
|
9
72999-67H00-000 CAP,OD:40 |
72999-67H00-000 |
from US $4.32 |
||
|
10
|
10
09250-26003-000
CAP(OD:32)
NONHEATER TYPE |
09250-26003-000 |
— | ||
| replacement | |||||
|
10
|
10
09250-26006-000 Cap(Od:32)NONHEATER TYPE |
09250-26006-000 |
from US $3.91 |
||
|
10
|
10
09250-40002-000 CAP(OD:52)TYPE 3:NONHEATER TYPE |
09250-40002-000 |
from US $1.82 |
||
|
11
|
11
09250-07001-000 CAP(OD:10)NONHEATER TYPE |
09250-07001-000 |
US $11 |
||
|
12
|
12
66410-79200-000
Member, engine room center
|
66410-79200-000 |
— | ||
|
12
|
12
66411-79220-000
Member, engine room center
Australia |
66411-79220-000 |
— | ||
| replacements | |||||
|
12
|
12
09250-20009-000
CAP(OD:30)
Australia |
09250-20009-000 |
— | ||
|
12
|
12
09250-20002-000
キャップ,OD:30
Australia |
09250-20002-000 |
— | ||
|
12
|
12
09250-20034-000 Cap(Od:30)Australia |
09250-20034-000 |
US $11.40 |
||
|
12
|
12
66410-79230-000
Member, engine room center
,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
66410-79230-000 |
— | ||
|
13
|
13
01517-06128-000
Bolt
|
01517-06128-000 |
— | ||
| replacement | |||||
|
13
|
13
01550-06127-000 BOLTBolt, rect |
01550-06127-000 |
from US $0.68 |
||
|
14
|
14
09250-20002-000
キャップ,OD:30
|
09250-20002-000 |
— | ||
|
15
|
15
66416-79200-000
INSULATOR,ENGINE ROOM MEMBER
|
66416-79200-000 |
— | ||
|
16
|
16
65310-79001-000
Cross member, floor
TYPE 3:RHD |
65310-79001-000 |
— | ||
| replacements | |||||
|
16
|
16
09160-06019-000 WASHER(6.5X16X1.2)Washer (6.5x16x1.2) TYPE 3:RHD |
09160-06019-000 |
from US $0.76 |
||
|
16
|
16
08321-0106A-000 WASHER,LOCKTYPE 3:RHD |
08321-0106A-000 |
from US $0.76 |
||
|
16
|
16
01500-0616A-000 BoltTYPE 3:RHD |
01500-0616A-000 |
from US $0.76 |
||
|
16
|
16
08321-21066-000
Lock washer
TYPE 3:RHD |
08321-21066-000 |
— | ||
|
16
|
16
01107-06166-000
Bolt
TYPE 3:RHD |
01107-06166-000 |
— | ||
|
16
|
16
65310-79060-000
Cross member, floor
TYPE 1,TYPE 2:LHD |
65310-79060-000 |
— | ||
|
16
|
16
65310-79061-000
Cross member, floor
TYPE 3:LHD |
65310-79061-000 |
— | ||
| replacements | |||||
|
16
|
16
09160-06019-000 WASHER(6.5X16X1.2)Washer (6.5x16x1.2) TYPE 3:LHD |
09160-06019-000 |
from US $0.76 |
||
|
16
|
16
08321-0106A-000 WASHER,LOCKTYPE 3:LHD |
08321-0106A-000 |
from US $0.76 |
||
|
16
|
16
01500-0616A-000 BoltTYPE 3:LHD |
01500-0616A-000 |
from US $0.76 |
||
|
16
|
16
01107-06166-000
Bolt
TYPE 3:LHD |
01107-06166-000 |
— | ||
|
16
|
16
08321-21066-000
Lock washer
TYPE 3:LHD |
08321-21066-000 |
— | ||
|
16
|
16
65310-79230-000
Cross member, floor
TYPE 1,TYPE 2:RHD TYPE 1,TYPE 2:,Finland,Switzerland,Belgium,5,Channel Islands FROM,65310-79000 |
65310-79230-000 |
— | ||
|
16
|
16
65310-79231-000
Cross member, floor
TYPE 3:,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
65310-79231-000 |
— | ||
| replacements | |||||
|
16
|
16
09160-06019-000 WASHER(6.5X16X1.2)Washer (6.5x16x1.2) TYPE 3:,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
09160-06019-000 |
from US $0.76 |
||
|
16
|
16
01500-0616A-000 BoltTYPE 3:,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
01500-0616A-000 |
from US $0.76 |
||
|
16
|
16
08321-0106A-000 WASHER,LOCKTYPE 3:,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
08321-0106A-000 |
from US $0.76 |
||
|
16
|
16
01107-06166-000
Bolt
TYPE 3:,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
01107-06166-000 |
— | ||
|
16
|
16
08321-21066-000
Lock washer
TYPE 3:,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
08321-21066-000 |
— | ||
|
17
|
17
65130-79000-000
BRACKET,STEERING GEAR BOX RH
|
65130-79000-000 |
— | ||
|
18
|
18
65140-79060-000
BRACKET,STEERING GEAR BOX LH
|
65140-79060-000 |
— | ||
|
19
|
19
72200-79000-000
Panel assy, cab back
|
72200-79000-000 |
— | ||
|
19
|
19
72200-79220-000
Panel assy, cab back
,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
72200-79220-000 |
— | ||
|
20
|
20
72861-67001-000
BAR,BACK WINDOW GUARD
|
72861-67001-000 |
— | ||
|
21
|
21
02142-06108-000
6 x 10 screw
|
02142-06108-000 |
— | ||
| replacement | |||||
|
21
|
21
02142-06107-000 SCREW |
02142-06107-000 |
from US $0.80 |
||
|
22
|
22
03141-06128-000
Mold.inner fix.screw
|
03141-06128-000 |
— | ||
| replacement | |||||
|
22
|
22
03141-0612A-000 SCREW |
03141-0612A-000 |
US $0.76 |
||
|
23
|
23
65490-79500-000
Bracket,jack
|
65490-79500-000 |
— | ||
|
24
|
24
01517-06128-000
Bolt
|
01517-06128-000 |
— | ||
| replacement | |||||
|
24
|
24
01550-06127-000 BOLTBolt, rect |
01550-06127-000 |
from US $0.68 |
||
|
25
|
25
66471-79000-000
Bracket, seat belt center
|
66471-79000-000 |
— | ||
|
25
|
25
66471-79230-000
Bracket, seat belt center
,Finland,Switzerland,Belgium,5,Channel Islands,Israel |
66471-79230-000 |
— | ||
|
26
|
26
08316-26086-000
Nut
|
08316-26086-000 |
— | ||
| replacements | |||||
|
26
|
26
08316-2008A-000 NUT |
08316-2008A-000 |
from US $0.80 |
||
|
26
|
26
08316-20087-000 NUT |
08316-20087-000 |
from US $3.77 |
||
|
27
|
27
72871-79220-000
Connector, deck front rh
,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
72871-79220-000 |
— | ||
|
28
|
28
72876-79220-000
Connector, deck front lh
,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
72876-79220-000 |
— | ||
|
29
|
29
09111-08035-000 BOLT(8X20),Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
09111-08035-000 |
US $1.44 |
||
|
30
|
30
09161-08011-000 WASHER(8.2X18X1.2)Washer (8.2x18x1.2) ,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
09161-08011-000 |
from US $2.79 |
||
|
31
|
31
01107-08168-000
Bolt
,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
01107-08168-000 |
— | ||
| replacement | |||||
|
31
|
31
01500-0816B-000 BoltBolt ,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
01500-0816B-000 |
from US $0.80 |
||
|
32
|
32
08321-21088-000
Lock washer
,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
08321-21088-000 |
— | ||
| replacement | |||||
|
32
|
32
08321-01087-000 WASHER,LOCKWasher, lock ,Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
08321-01087-000 |
from US $0.76 |
||
|
33
|
33
09160-08010-000 Washer (8.2x20x1.6),Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
09160-08010-000 |
US $1.21 |
||
| replacement | |||||
|
33
|
33
09160-08054-000 WASHER(8.5X20X1.6),Finland,Switzerland,Belgium,4,5,7,Channel Islands,Israel |
09160-08054-000 |
from US $0.91 |
||
