Front seat (ST90V:Thailand,Bangladesh) Diagram Suzuki CARRY/SUPER CARRY
- Year
- -
- Sales region
- Africa
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
81001-79531-42S
Cushion assy, seat rh
TYPE 1 |
81001-79531-42S |
— | ||
|
1
|
1
81001-79531-45U
Cushion assy, seat rh
TYPE 2,FROM 81001-79530-45U |
81001-79531-45U |
— | ||
|
1
|
1
81001-79070-90V
Cushion assy, seat rh
TYPE 3 |
81001-79070-90V |
— | ||
|
2
|
2
81002-79722-42S
Cushion assy, seat lh
TYPE 1,FROM 81002-79721-42S |
81002-79722-42S |
— | ||
|
2
|
2
81002-79721-42S
Cushion assy, seat lh
TYPE 1,ST90-719980~ TO,81002-79722-42S |
81002-79721-42S |
— | ||
|
2
|
2
81002-79722-45U
Cushion assy, seat lh
TYPE 2,FROM 81002-79721-45U |
81002-79722-45U |
— | ||
|
2
|
2
81002-79260-90V
Cushion assy, seat lh
TYPE 3 |
81002-79260-90V |
— | ||
|
3
|
3
81003-79020-42S
Cushion assy, seat center
TYPE 1 |
81003-79020-42S |
— | ||
|
3
|
3
81003-79021-45U
Cushion assy, seat center
TYPE 2,FROM 81003-79020-45U |
81003-79021-45U |
— | ||
|
3
|
3
81003-79021-90V
Cushion assy, seat center
TYPE 3 |
81003-79021-90V |
— | ||
|
4
|
4
81004-79720-42S
Back assy, seat
TYPE 1 |
81004-79720-42S |
— | ||
|
4
|
4
81004-79721-45U
Back assy, seat
TYPE 2 |
81004-79721-45U |
— | ||
|
4
|
4
81004-79540-90V
Back assy, seat
TYPE 3 |
81004-79540-90V |
— | ||
|
5
|
5
82320-79511-000
Panel, lh
ST90-719980~ |
82320-79511-000 |
— | ||
| replacement | |||||
|
5
|
5
82320-79515-000
PANEL,FR SEAT RISER,L
ST90-719980~ |
82320-79515-000 |
— | ||
|
6
|
6
08316-26068-000
Nut
ST90-719980~ |
08316-26068-000 |
— | ||
| replacement | |||||
|
6
|
6
08316-2006A-000 NUTST90-719980~ |
08316-2006A-000 |
from US $0.76 |
||
|
7
|
7
81920-79002-000
LOCK,FR SEAT CUSHION
FROM 81920-79001 |
81920-79002-000 |
— | ||
|
8
|
8
01107-06128-000
Bolt, earth lead
|
01107-06128-000 |
— | ||
| replacement | |||||
|
8
|
8
01500-06127-000 Bolt |
01500-06127-000 |
from US $0.76 |
||
|
9
|
9
08321-21068-000
Lock washer
|
08321-21068-000 |
— | ||
| replacement | |||||
|
9
|
9
08321-01067-000 WASHER,LOCK |
08321-01067-000 |
from US $0.76 |
||
|
10
|
10
08322-21068-000
Washer
|
08322-21068-000 |
— | ||
| replacement | |||||
|
10
|
10
08322-01067-000 WASHER |
08322-01067-000 |
from US $0.76 |
||
|
11
|
11
81930-79720-000
Support, seat back
|
81930-79720-000 |
— | ||
|
12
|
12
01107-06128-000
Bolt, earth lead
|
01107-06128-000 |
— | ||
| replacement | |||||
|
12
|
12
01500-06127-000 Bolt |
01500-06127-000 |
from US $0.76 |
||
|
13
|
13
08321-21068-000
Lock washer
|
08321-21068-000 |
— | ||
| replacement | |||||
|
13
|
13
08321-01067-000 WASHER,LOCK |
08321-01067-000 |
from US $0.76 |
||
|
14
|
14
08322-21068-000
Washer
|
08322-21068-000 |
— | ||
| replacement | |||||
|
14
|
14
08322-01067-000 WASHER |
08322-01067-000 |
from US $0.76 |
||
|
15
|
15
08316-16066-000
Nut
|
08316-16066-000 |
— | ||
| replacement | |||||
|
15
|
15
08316-1006B-000 NUT |
08316-1006B-000 |
from US $0.76 |
||
