at - transmission case (4AT; 1998-05-01~2000-02-01) Diagram Suzuki CULTUS
- Year
- 1998 - 2011
- Sales region
- Japan
- Engine
- G15A
- drive
- 2WD
- transmission
- AT
- Number of doors
- 5DR
- grade
- TS1
- number of the gears
- 4AT
- air bag
- AB-N
- abs
- ABS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
24720-60G12-000
HOUSING,TORQUE CONVERTER
4AT:(G15A,G16A); 1998-05-01~2000-02-01 |
24720-60G12-000 |
— | ||
|
2
|
2
24725-60G10-000 BOLT,HOUSING NO.14AT; 1998-05-01~2000-02-01 |
24725-60G10-000 |
US $4.27 |
||
|
3
|
3
24729-60G10-000 Bolt4AT; 1998-05-01~2000-02-01 |
24729-60G10-000 |
US $4.12 |
||
|
4
|
4
24710-60G11-000
ケース,トランスミッション
4AT; 1998-05-01~2000-02-01 |
24710-60G11-000 |
— | ||
| replacement | |||||
|
4
|
4
24710-60G12-000
CASE,T/M
4AT; 1998-05-01~2000-02-01 |
24710-60G12-000 |
— | ||
|
5
|
5
24730-60G10-000 COVER ASSY,T/M RR4AT; 1998-05-01~2000-02-01 |
24730-60G10-000 |
US $591.36 |
||
|
6
|
6
24727-60G10-000 BOLT,HOUSING NO.34AT; 1998-05-01~2000-02-01 |
24727-60G10-000 |
US $4.75 |
||
|
7
|
7
24734-60G10-000 BOLT,RR COVER NO.24AT; 1998-05-01~2000-02-01 |
24734-60G10-000 |
US $4.05 |
||
|
8
|
8
24735-60G10-000 BOLT,T/C HOUSING N0.34AT; 1998-05-01~2000-02-01 |
24735-60G10-000 |
US $5.04 |
||
|
9
|
9
24736-60G10-000
ボルト
4AT; 1998-05-01~2000-02-01 |
24736-60G10-000 |
— | ||
| replacement | |||||
|
9
|
9
22893-59J10-000 BOLT,OIL PUMP ASSY4AT; 1998-05-01~2000-02-01 |
22893-59J10-000 |
from US $3.80 |
||
|
10
|
10
24751-65G10-000 COVER,T/M SIDE4AT:(G15A,G16A); 1998-05-01~2000-02-01 |
24751-65G10-000 |
US $351.44 |
||
|
11
|
11
24727-60G10-000 BOLT,HOUSING NO.34AT; 1998-05-01~2000-02-01 |
24727-60G10-000 |
US $4.75 |
||
|
12
|
12
24753-60G10-000 BOLT,SIDE COVER NO.24AT; 1998-05-01~2000-02-01 |
24753-60G10-000 |
US $4.56 |
||
|
13
|
13
24754-60G10-000 BOLT,SIDE COVER NO.34AT:(G15A,G16A); 1998-05-01~2000-02-01 |
24754-60G10-000 |
US $5.37 |
||
|
14
|
14
24755-65G10-000 BOLT,SIDE COVER NO.44AT:(G15A,G16A); 1998-05-01~2000-02-01 |
24755-65G10-000 |
US $5.37 |
||
|
15
|
15
24756-60G10-000
BOLT,SIDE COVER NO.5
4AT:(G15A,G16A); 1998-05-01~2000-02-01 |
24756-60G10-000 |
— | ||
|
16
|
16
24757-60G10-000 BOLT,SIDE COVER NO.64AT; 1998-05-01~2000-02-01 |
24757-60G10-000 |
US $6.26 |
||
|
17
|
17
24758-65G10-000 BOLT,SIDE COVER NO.74AT; 1998-05-01~2000-02-01 |
24758-65G10-000 |
US $5.23 |
||
|
18
|
18
24759-65G10-000
BOLT,SIDE COVER STUD
4AT; 1998-05-01~2000-02-01 |
24759-65G10-000 |
— | ||
|
19
|
19
24745-57B00-000 MAGNET,T/M OIL PAN4AT; 1998-05-01~2000-02-01 |
24745-57B00-000 |
US $5.60 |
||
|
20
|
20
24823-60G11-000 PLUG,DRAIN4AT; 1998-05-01~2000-02-01 |
24823-60G11-000 |
from US $9.54 |
||
|
21
|
21
24824-60G10-000 GASKET,DRAIN PLUG4AT; 1998-05-01~2000-02-01 |
24824-60G10-000 |
from US $2.56 |
||
|
22
|
22
24831-65G30-000
GAUGE,T/M OIL LEVER
4AT; 1998-05-01~2000-02-01 |
24831-65G30-000 |
— | ||
|
23
|
23
24839-61A31-000 EMBLEM,ATF4AT:(FS,TR,TS,TZ); 1998-05-01~2000-02-01 |
24839-61A31-000 |
US $2.47 |
||
|
24
|
24
24841-60G10-000 TUBE,T/M OIL FILLER4AT; 1998-05-01~2000-02-01 |
24841-60G10-000 |
US $37.90 |
||
|
25
|
25
24842-60G10-000 O-RING4AT; 1998-05-01~2000-02-01 |
24842-60G10-000 |
US $2.69 |
||
|
26
|
26
02162-06163-000
Screw
4AT; 1998-05-01~2000-02-01 |
02162-06163-000 |
— | ||
| replacement | |||||
|
26
|
26
02162-0616B-000 SCREWBolt, adjust 4AT; 1998-05-01~2000-02-01 |
02162-0616B-000 |
from US $0.80 |
||
|
27
|
27
29849-57B00-000 PLUG,T/M CASE4AT; 1998-05-01~2000-02-01 |
29849-57B00-000 |
US $5.89 |
||
|
28
|
28
29738-57B00-000 O-RING4AT; 1998-05-01~2000-02-01 |
29738-57B00-000 |
US $2.40 |
||
|
29
|
29
24851-60G10-000 PLUG,BREATHER4AT; 1998-05-01~2000-02-01 |
24851-60G10-000 |
US $8.35 |
||
|
30
|
30
24856-60G10-000 HOSE,BREATHER4AT; 1998-05-01~2000-02-01 |
24856-60G10-000 |
US $5.74 |
||
|
31
|
31
27991-65D01-000 PLUG,BREATHER4AT; 1998-05-01~2000-02-01 |
27991-65D01-000 |
from US $1.92 |
||
|
32
|
32
24791-60G10-000 STIFFENER,HOUSING FRONT4AT; 1998-05-01~2000-02-01 |
24791-60G10-000 |
US $33.30 |
||
|
33
|
33
01550-10253-000
Bolt
4AT; 1998-05-01~2000-02-01 |
01550-10253-000 |
— | ||
| replacements | |||||
|
33
|
33
01550-1025B-000 BoltBolt, rr swgarm bracket, l 4AT; 1998-05-01~2000-02-01 |
01550-1025B-000 |
from US $5.59 |
||
|
33
|
33
01550-1025A-000 BOLTBolt, drive gear 4AT; 1998-05-01~2000-02-01 |
01550-1025A-000 |
from US $1.06 |
||
|
34
|
34
08316-10103-000
Nut
4AT; 1998-05-01~2000-02-01 |
08316-10103-000 |
— | ||
| replacement | |||||
|
34
|
34
08316-1010B-000 NUT4AT; 1998-05-01~2000-02-01 |
08316-1010B-000 |
from US $0.80 |
||
|
35
|
35
01550-10253-000
Bolt
4AT; 1998-05-01~2000-02-01 |
01550-10253-000 |
— | ||
| replacements | |||||
|
35
|
35
01550-1025B-000 BoltBolt, rr swgarm bracket, l 4AT; 1998-05-01~2000-02-01 |
01550-1025B-000 |
from US $5.59 |
||
|
35
|
35
01550-1025A-000 BOLTBolt, drive gear 4AT; 1998-05-01~2000-02-01 |
01550-1025A-000 |
from US $1.06 |
||
|
36
|
36
26143-60G10-000 SENSOR,SPEED INPUT4AT; 1998-05-01~2000-02-01 |
26143-60G10-000 |
from US $127.58 |
||
|
37
|
37
26141-60G10-000 SENSOR,SPEED OUTPUT4AT; 1998-05-01~2000-02-01 |
26141-60G10-000 |
US $129.54 |
||
|
38
|
38
29999-57B00-000 Bolt4AT; 1998-05-01~2000-02-01 |
29999-57B00-000 |
US $5.89 |
||
|
39
|
39
22911-65G10-000 PIPE,OIL OUTLET4AT; 1998-05-01~2000-02-01 |
22911-65G10-000 |
US $28.15 |
||
|
40
|
40
22921-65G11-000
PIPE,OIL INLET
4AT:(G15A,G16A); 1998-05-01~2000-02-01 |
22921-65G11-000 |
— | ||
|
41
|
41
09168-14015-000 GASKET(14X20X1.5)Gasket, oil hose union 4AT; 1998-05-01~2000-02-01 |
09168-14015-000 |
from US $1.17 |
||
|
42
|
42
09360-14012-000 BOLT,14X27Bolt, union (14x27) 4AT; 1998-05-01~2000-02-01 |
09360-14012-000 |
from US $6.88 |
||
|
43
|
43
22931-65G10-000 HOSE,OIL COOLER INLET4AT; 1998-05-01~2000-02-01 |
22931-65G10-000 |
US $21.53 |
||
|
44
|
44
22932-65G10-000
HOSE,OIL COOLER OUTLET
4AT:(G15A,G16A); 1998-05-01~2000-02-01 |
22932-65G10-000 |
— | ||
|
45
|
45
09401-15408-000 CLIPClip, 2nd air cleaner hose no.2 4AT; 1998-05-01~2000-02-01 |
09401-15408-000 |
from US $3.26 |
||
|
46
|
46
24815-60G10-000 GASKET,T/M CASE OIL LINE NO.14AT; 1998-05-01~2000-02-01 |
24815-60G10-000 |
US $10.88 |
||
|
47
|
47
24816-60G10-000 GASKET,T/M CASE OIL LINE NO.24AT; 1998-05-01~2000-02-01 |
24816-60G10-000 |
from US $6.10 |
||
|
48
|
48
24818-60G10-000
ガスケット,トランスミッションケースオイルライン,NO.4
4AT; 1998-05-01~2000-02-01 |
24818-60G10-000 |
— | ||
| replacement | |||||
|
48
|
48
24818-68J10-000 GASKET,GOVERNOR APPLY NO.14AT; 1998-05-01~2000-02-01 |
24818-68J10-000 |
from US $5.18 |
||
|
49
|
49
24881-60G10-000
プレート,オイルリザーバ,ライト
4AT; 1998-05-01~2000-02-01 |
24881-60G10-000 |
— | ||
| replacement | |||||
|
49
|
49
24881-65G10-000 PLATE,OIL RESERVOIR,R4AT; 1998-05-01~2000-02-01 |
24881-65G10-000 |
US $53.36 |
||
|
50
|
50
24882-60G10-000
プレート,オイルリザーバ,レフト
4AT; 1998-05-01~2000-02-01 |
24882-60G10-000 |
— | ||
| replacement | |||||
|
50
|
50
24882-54G10-000 PLATE,OIL RESERVOIR,L4AT; 1998-05-01~2000-02-01 |
24882-54G10-000 |
US $53.36 |
||
|
51
|
51
24883-60G10-000 TUBE,DIFF SIDE4AT; 1998-05-01~2000-02-01 |
24883-60G10-000 |
US $25.21 |
||
|
52
|
52
24884-60G10-000 TUBE,DIFF SIDE4AT; 1998-05-01~2000-02-01 |
24884-60G10-000 |
US $19.32 |
||
|
53
|
53
24885-60G10-000 CLAMP,R LUBRICATION TUBE4AT; 1998-05-01~2000-02-01 |
24885-60G10-000 |
US $4.75 |
||
|
54
|
54
24732-60GT0-000 RING SET,REAR COVER SEAL4AT; 1998-05-01~2000-02-01 |
24732-60GT0-000 |
US $64.77 |
||
|
55
|
55
29970-57B00-000 Bolt4AT; 1998-05-01~2000-02-01 |
29970-57B00-000 |
US $5.89 |
||
|
57
|
57
08316-10083-000
Nut
4AT; 1998-05-01~2000-02-01 |
08316-10083-000 |
— | ||
| replacement | |||||
|
57
|
57
08316-1008B-000 NUT4AT; 1998-05-01~2000-02-01 |
08316-1008B-000 |
from US $0.76 |
||
