air cleaner (J18A; 1998-05-01~2000-02-01) Diagram Suzuki CULTUS
- Year
- 1998 - 2011
- Sales region
- Japan
- Engine
- J18A
- drive
- 2WD
- transmission
- AT
- Number of doors
- 5DR
- grade
- TZ1
- number of the gears
- 4AT
- air bag
- AB-N
- abs
- ABS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
13700-60G00-000 CLEANER ASSY,AIRJ18A; 1998-05-01~2000-02-01 |
13700-60G00-000 |
US $217.12 |
||
|
2
|
2
13780-60G00-000 ELEMENT,AIR CLEANERJ18A; 1998-05-01~2000-02-01 |
13780-60G00-000 |
US $35.70 |
||
|
3
|
3
13813-57BT0-000 GROMMET SET,AIR CLEANERJ18A; 1998-05-01~2000-02-01 |
13813-57BT0-000 |
US $14.56 |
||
|
4
|
4
09103-06169-000 BOLT(6X30)J18A; 1998-05-01~2000-02-01 |
09103-06169-000 |
US $23.90 |
||
|
5
|
5
13810-60G00-000 BRACKET,AIR CLNRJ18A; 1998-05-01~2000-02-01 |
13810-60G00-000 |
US $4.12 |
||
|
6
|
6
09122-86002-000 SCREW(6X12)J18A; 1998-05-01~2000-02-01 |
09122-86002-000 |
US $11.80 |
||
|
7
|
7
13881-62G00-000
HOSE,AIR CLEANER OUTLET
J18A; 1998-05-01~2000-02-01 |
13881-62G00-000 |
— | ||
|
8
|
8
09402-82511-000 CLAMPJ18A; 1998-05-01~2000-02-01 |
09402-82511-000 |
US $65.90 |
||
|
9
|
9
09402-00512-000 CLAMPJ18A; 1998-05-01~2000-02-01 |
09402-00512-000 |
from US $17.37 |
||
|
10
|
10
13760-64G00-000 RESONATOR,AIR CLNR SUCTIONJ18A; 1998-05-01~2000-02-01 |
13760-64G00-000 |
US $75.07 |
||
|
11
|
11
13769-64G00-000 BRACKET,RESONATORJ18A; 1998-05-01~2000-02-01 |
13769-64G00-000 |
US $7.07 |
||
|
12
|
12
02162-06123-000
Bolt (6x12)
J18A; 1998-05-01~2000-02-01 |
02162-06123-000 |
— | ||
| replacements | |||||
|
12
|
12
02162-0612B-000 SCREWBolt J18A; 1998-05-01~2000-02-01 |
02162-0612B-000 |
from US $0.80 |
||
|
12
|
12
02162-0612A-000 SCREWBolt, bracket J18A; 1998-05-01~2000-02-01 |
02162-0612A-000 |
from US $0.80 |
||
|
13
|
13
13766-56B00-000 CUSHION,RESOANTOR LOWERJ18A; 1998-05-01~2000-02-01 |
13766-56B00-000 |
US $4.82 |
||
|
14
|
14
09180-08197-000 SPACER(8.5X12X23.5)J18A; 1998-05-01~2000-02-01 |
09180-08197-000 |
from US $6.29 |
||
|
15
|
15
09113-06501-000 BOLT(6X35)J18A; 1998-05-01~2000-02-01 |
09113-06501-000 |
US $21.70 |
||
|
16
|
16
13765-60G02-000 PIPE,AIR CLNR SUCTION NO.1J18A; 1998-05-01~2000-02-01 |
13765-60G02-000 |
US $49.68 |
||
|
17
|
17
13766-60G00-000 PIPE,AIR CLNR SUCTION NO.2J18A; 1998-05-01~2000-02-01 |
13766-60G00-000 |
US $47.10 |
||
|
18
|
18
13766-64B00-000 GROMMET,RESONATORJ18A; 1998-05-01~2000-02-01 |
13766-64B00-000 |
US $21.60 |
||
|
19
|
19
13761-62G00-000 RESONATOR,AIR CLNR SUCTJ18A; 1998-05-01~2000-02-01 |
13761-62G00-000 |
US $33.49 |
||
|
20
|
20
09320-09501-000 CUSHIONJ18A; 1998-05-01~2000-02-01 |
09320-09501-000 |
from US $0.92 |
||
|
21
|
21
13650-52G00-000 SENSOR,INLET AIR TEMPSensor, inlet air temp J18A; 1998-05-01~2000-02-01 |
13650-52G00-000 |
from US $50.92 |
||
