power steering oil pump (5DR:J18A; 1998-05-01~2000-02-01) Diagram Suzuki CULTUS
- Year
- 1998 - 2011
- Sales region
- Japan
- Engine
- J18A
- drive
- 2WD
- transmission
- AT
- Number of doors
- 5DR
- grade
- TZ1
- number of the gears
- 4AT
- air bag
- AB-N
- abs
- ABS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
49110-64G21-000 PUMP ASSY,POWER STEERING5DR:J18A; 1998-05-01~2000-02-01 |
49110-64G21-000 |
US $682.88 |
||
|
2
|
2
49111-64G20-000 PULLEY SET5DR:J18A; 1998-05-01~2000-02-01 |
49111-64G20-000 |
US $140.58 |
||
|
3
|
3
49112-64G20-000 CONNECTOR SET5DR:J18A; 1998-05-01~2000-02-01 |
49112-64G20-000 |
US $42.32 |
||
|
4
|
4
49113-63G10-000
Terminal set
5DR:J18A; 1998-05-01~2000-02-01 |
49113-63G10-000 |
— | ||
|
5
|
5
49114-64G11-000
シールセット
5DR:J18A; 1998-05-01~2000-02-01 |
49114-64G11-000 |
— | ||
| replacement | |||||
|
5
|
5
49114-64G10-000 SEAL SET5DR:J18A; 1998-05-01~2000-02-01 |
49114-64G10-000 |
from US $45.60 |
||
|
6
|
6
49115-56B30-000 BOLT SET5DR:J18A; 1998-05-01~2000-02-01 |
49115-56B30-000 |
US $10.56 |
||
|
7
|
7
49130-64G20-000
BRACKET,PUMP MOUNT
5DR:J18A; 1998-05-01~2000-02-01 |
49130-64G20-000 |
— | ||
|
8
|
8
09103-08254-000 BOLT(8X20)Bolt, rear 5DR:J18A; 1998-05-01~2000-02-01 |
09103-08254-000 |
from US $4.13 |
||
|
9
|
9
01550-08203-000
Bolt
5DR:J18A; 1998-05-01~2000-02-01 |
01550-08203-000 |
— | ||
| replacements | |||||
|
9
|
9
01550-0820B-000 Bolt5DR:J18A; 1998-05-01~2000-02-01 |
01550-0820B-000 |
from US $0.91 |
||
|
9
|
9
01550-0820A-000 BOLTBolt, funnel bracket 5DR:J18A; 1998-05-01~2000-02-01 |
01550-0820A-000 |
from US $0.96 |
||
|
10
|
10
49140-60G00-000 TANK ASSY,POWER STEERING5DR:J18A; 1998-05-01~2000-02-01 |
49140-60G00-000 |
US $131.38 |
||
|
11
|
11
49223-60G12-000
Pipe assy,rtn gear side
5DR:J18A; 1998-05-01~2000-02-01 |
49223-60G12-000 |
— | ||
|
12
|
12
49210-64G11-000 PIPE ASSY,HIGH PRESSURE5DR:J18A; 1998-05-01~2000-02-01 |
49210-64G11-000 |
US $237.36 |
||
|
13
|
13
49211-63G02-000
ガスケット,プレッシャパイプ
5DR:J18A; 1998-05-01~2000-02-01 |
49211-63G02-000 |
— | ||
| replacement | |||||
|
13
|
13
49211-63G03-000 GASKET,PRESSURE PIPE5DR:J18A; 1998-05-01~2000-02-01 |
49211-63G03-000 |
US $4.96 |
||
|
14
|
14
09360-16008-000 UNION5DR:J18A; 1998-05-01~2000-02-01 |
09360-16008-000 |
US $88.30 |
||
|
15
|
15
49222-64G00-000
HOSE,SUCTION
5DR:J18A; 1998-05-01~2000-02-01 |
49222-64G00-000 |
— | ||
|
16
|
16
09400-24301-000 CLAMP5DR:J18A; 1998-05-01~2000-02-01 |
09400-24301-000 |
US $1.92 |
||
|
17
|
17
09401-16405-000 CLAMP5DR:J18A; 1998-05-01~2000-02-01 |
09401-16405-000 |
from US $5.46 |
||
|
18
|
18
09116-06146-000 BOLT(6X25)Bolt (6x20) 5DR:J18A; 1998-05-01~2000-02-01 |
09116-06146-000 |
US $3.71 |
||
| replacement | |||||
|
18
|
18
09116-06150-000 BOLT(6X25)Bolt, air cleaner chamber 5DR:J18A; 1998-05-01~2000-02-01 |
09116-06150-000 |
from US $1.28 |
||
|
19
|
19
49150-60G00-000 BRACKET ASSY,PS TANK5DR:J18A; 1998-05-01~2000-02-01 |
49150-60G00-000 |
US $10.16 |
||
|
20
|
20
09180-06038-000 SPACER(6.1X9X7.5)Spacer (6.1x9x7.5) 5DR:J18A; 1998-05-01~2000-02-01 |
09180-06038-000 |
from US $1.52 |
||
|
21
|
21
09320-08501-000 CUSHION5DR:J18A; 1998-05-01~2000-02-01 |
09320-08501-000 |
from US $5.17 |
||
|
22
|
22
09136-06133-000 BOLT(6X16)Screw 5DR:J18A; 1998-05-01~2000-02-01 |
09136-06133-000 |
US $12.50 |
||
|
23
|
23
49220-64G10-000 PIPE ASSY,LOW PRESSURE RETURN5DR:J18A; 1998-05-01~2000-02-01 |
49220-64G10-000 |
US $123.65 |
||
