at - plastic material re-gear (AT:N32A; 2008-04-01~) Diagram Suzuki ESCUDO
- Year
- 2008 - 2011
- Sales region
- Japan
- Engine
- N32A
- transmission
- AT
- grade
- XS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
24120-64J10-000
Shaft,output
AT:N32A; 2008-04-01~ |
24120-64J10-000 |
— | ||
| replacement | |||||
|
1
|
1
24120-64JT0-000
SHAFT SET,OUTPUT
AT:N32A; 2008-04-01~ |
24120-64JT0-000 |
— | ||
|
2
|
2
24124-64JT0-000
BEARING SET,THRUST NO.9
AT:N32A; 2008-04-01~ |
24124-64JT0-000 |
— | ||
|
3
|
3
24211-54J10-000
SHAFT,INTERMEDIATE
AT:N32A; 2008-04-01~ |
24211-54J10-000 |
— | ||
|
4
|
4
24212-54J10-000
HUB,FORWARD CLUTCH
AT:N32A; 2008-04-01~ |
24212-54J10-000 |
— | ||
|
5
|
5
24214-54JT0-000
BEARING SET,THRUST NO.2
AT:N32A; 2008-04-01~ |
24214-54JT0-000 |
— | ||
|
6
|
6
24769-54J50-000
CIRCLIP,ONE WAY CLUTCH NO.3
AT:N32A; 2008-04-01~ |
24769-54J50-000 |
— | ||
|
7
|
7
24910-54J11-000
HUB,REVERSE CLUTCH
AT:N32A; 2008-04-01~ |
24910-54J11-000 |
— | ||
|
8
|
8
24914-54J10-000
BEARING,THRUST NDL NO.4
AT:N32A; 2008-04-01~ |
24914-54J10-000 |
— | ||
|
9
|
9
24916-54J10-000 WASHER,REV CL DRUM THRUSTAT:N32A; 2008-04-01~ |
24916-54J10-000 |
from US $11.89 |
||
|
10
|
10
24920-54J11-000
GEAR,FR PLNTY
AT:N32A; 2008-04-01~ |
24920-54J11-000 |
— | ||
|
11
|
11
24934-54JT0-000
BEARING SET,THRUST NO.5
AT:N32A; 2008-04-01~ |
24934-54JT0-000 |
— | ||
|
12
|
12
24941-54J10-000
GEAR,MIDDLE PLANETARY SUN
AT:N32A; 2008-04-01~ |
24941-54J10-000 |
— | ||
|
13
|
13
24950-54J10-000
GEAR,MIDDLE PLANETARY
AT:N32A; 2008-04-01~ |
24950-54J10-000 |
— | ||
|
14
|
14
24900-54JT0-000
GEAR SET,PLANETARY
AT:N32A; 2008-04-01~ |
24900-54JT0-000 |
— | ||
|
15
|
15
24952-54J11-000
HUB,DIRECT CLUTCH
AT:N32A; 2008-04-01~ |
24952-54J11-000 |
— | ||
|
16
|
16
24954-54JT0-000
BEARING SET,THRUST NO.3
AT:N32A; 2008-04-01~ |
24954-54JT0-000 |
— | ||
|
17
|
17
24956-54JT0-000
BEARING SET,THRUST NO.6
AT:N32A; 2008-04-01~ |
24956-54JT0-000 |
— | ||
|
18
|
18
24957-54J10-000 WASHER,FR PLNTY CARRIER THRAT:N32A; 2008-04-01~ |
24957-54J10-000 |
from US $9.57 |
||
|
19
|
19
24959-54J10-000
CIRCLIP
AT:N32A; 2008-04-01~ |
24959-54J10-000 |
— | ||
|
20
|
20
24974-54JT0-000
BEARING SET,THRUST NO.7
AT:N32A; 2008-04-01~ |
24974-54JT0-000 |
— | ||
|
21
|
21
24984-54J10-000
BEARING,THRUST N0.8
AT:N32A; 2008-04-01~ |
24984-54J10-000 |
— | ||
|
22
|
22
24990-54J10-000
GEAR,RR PLNTY RING
AT:N32A; 2008-04-01~ |
24990-54J10-000 |
— | ||
|
23
|
23
24991-54J10-000
FLANGE,FR PLNTY RING GEAR
AT:N32A; 2008-04-01~ |
24991-54J10-000 |
— | ||
|
24
|
24
24992-54J11-000
FLANGE,RR PLNTY RING GEAR
AT:N32A; 2008-04-01~ |
24992-54J11-000 |
— | ||
|
25
|
25
24999-54J10-000
CIRCLIP,RR PLNTY FLANGE
AT:N32A; 2008-04-01~ |
24999-54J10-000 |
— | ||
|
26
|
26
26760-54J50-000
CLUTCH ASSY,ONE WAY NO.3
AT:N32A; 2008-04-01~ |
26760-54J50-000 |
— | ||
|
27
|
27
26763-54J50-000 RACE,ONE WAY CLUTCH NO.3AT:N32A; 2008-04-01~ |
26763-54J50-000 |
from US $26.46 |
||
