propeller shaft (4WD; 1988-09-01~1989-02-01) Diagram Suzuki FRONTE
- Year
- 1988 - 1989
- Sales region
- Japan
- Engine
- 4V
- supercharge
- CARB
- drive
- 4WD
- transmission
- MT
- Number of doors
- 5DR
- grade
- FI
- number of the gears
- 5MT
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
27101-75B01-000
シャフトアッシ,プロペラ
4WD; 1988-09-01~1989-02-01 |
27101-75B01-000 |
— | ||
| replacement | |||||
|
1
|
1
27101-55E03-000
シャフトアッシ,プロペラ
4WD; 1988-09-01~1989-02-01 |
27101-55E03-000 |
— | ||
|
2
|
2
01787-10203-000
ボルト
4WD; 1988-09-01~1989-02-01 |
01787-10203-000 |
— | ||
| replacement | |||||
|
2
|
2
01580-1020A-000 Bolt4WD; 1988-09-01~1989-02-01 |
01580-1020A-000 |
US $19.50 |
||
|
3
|
3
27114-74B00-000
ワッシャ,ジョイントボルト
4WD; 1988-09-01~1989-02-01 |
27114-74B00-000 |
— | ||
|
4
|
4
07110-08453-000
ボルト
4WD; 1988-09-01~1989-02-01 |
07110-08453-000 |
— | ||
| replacement | |||||
|
4
|
4
07130-0845B-000 BOLTBolt, muffler support 4WD; 1988-09-01~1989-02-01 |
07130-0845B-000 |
from US $1.37 |
||
|
4
|
4
07110-08503-000
ボルト
4WD; 1988-09-01~1989-02-01 |
07110-08503-000 |
— | ||
| replacement | |||||
|
4
|
4
07130-0850A-000 BOLT4WD; 1988-09-01~1989-02-01 |
07130-0850A-000 |
from US $1.60 |
||
