Front seat (RHD:LIMITED) Diagram Suzuki GRAND VITARA
- Year
- -
- Sales region
- Africa
- transmission
- AT
- grade
- LIMITED
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
85105-65D91-000
クッションサブアッシ,フロント
|
85105-65D91-000 |
— | ||
|
2
|
2
85105-65D11-000
CUSHION SUB ASSY,FR
|
85105-65D11-000 |
— | ||
|
3
|
3
85180-65D90-GE3
Trim comp,fr cush
|
85180-65D90-GE3 |
— | ||
|
4
|
4
85180-65D10-GE3
Trim comp,fr cush
|
85180-65D10-GE3 |
— | ||
|
5
|
5
85150-74F11-000
Tray assy, front seat under
|
85150-74F11-000 |
— | ||
| replacement | |||||
|
5
|
5
85150-80G10-000 TRAY ASSY,FR UNDER |
85150-80G10-000 |
US $72 |
||
|
6
|
6
86521-65DA0-000 BRACKET,UNDER TRAY |
86521-65DA0-000 |
US $82.40 |
||
|
7
|
7
03242-05123-000
Screw, inner cover
|
03242-05123-000 |
— | ||
| replacement | |||||
|
7
|
7
03241-0512A-000 SCREW |
03241-0512A-000 |
from US $0.68 |
||
|
8
|
8
85211-65DA0-T01 KNOB,RECL,R |
85211-65DA0-T01 |
US $4.67 |
||
|
9
|
9
85221-65DF0-T01
Cover, reclining outside rh
|
85221-65DF0-T01 |
— | ||
| replacement | |||||
|
9
|
9
85220-65DF0-T01
Cover,recl outside,r(gray)
|
85220-65DF0-T01 |
— | ||
|
10
|
10
03242-05163-000
Screw
|
03242-05163-000 |
— | ||
| replacement | |||||
|
10
|
10
03241-0516A-000 SCREW |
03241-0516A-000 |
from US $0.76 |
||
|
11
|
11
85241-65DA0-T01 COVER,RECL,INSIDE,R |
85241-65DA0-T01 |
US $30.73 |
||
|
12
|
12
85250-65DA0-000 ROD,FR SEAT ADJUSTER |
85250-65DA0-000 |
US $15.53 |
||
|
13
|
13
85305-65DS1-000
Back sub assy,fr,r
|
85305-65DS1-000 |
— | ||
|
14
|
14
85306-65DS1-000
Back sub assy,fr,l
|
85306-65DS1-000 |
— | ||
|
15
|
15
85341-72C10-T01 GUIDE,HEADRESTRAINT |
85341-72C10-T01 |
US $6.04 |
||
|
16
|
16
85840-72C10-T01 GUIDE,HEADRESTRAINT |
85840-72C10-T01 |
US $15.12 |
||
|
17
|
17
85501-65DQ0-W88
ARMREST ASSY,FR,R
|
85501-65DQ0-W88 |
— | ||
|
18
|
18
85502-65DQ0-W88
ARMREST ASSY,FR,L
|
85502-65DQ0-W88 |
— | ||
|
19
|
19
85541-65DQ0-000 SHAFT,FR ARMREST |
85541-65DQ0-000 |
US $8.24 |
||
|
20
|
20
86170-80G00-T01 KNOB,SUPPORT |
86170-80G00-T01 |
US $29.62 |
||
|
21
|
21
78463-78000-000 SNAP |
78463-78000-000 |
US $1.60 |
||
|
22
|
22
08332-11063-000
E ring
|
08332-11063-000 |
— | ||
| replacements | |||||
|
22
|
22
08332-1106B-000 E RINGCirclip |
08332-1106B-000 |
from US $0.86 |
||
|
22
|
22
08332-1106A-000 E RINGE ring, pinion |
08332-1106A-000 |
from US $0.91 |
||
|
23
|
23
85380-65DS0-GE3
Trim comp,fr back,r
|
85380-65DS0-GE3 |
— | ||
|
24
|
24
85880-65DS0-GE3
TRIM,FR BACK,L
|
85880-65DS0-GE3 |
— | ||
|
25
|
25
86401-52DC0-R1G
HEADRESTRAINT ASSY
|
86401-52DC0-R1G |
— | ||
|
26
|
26
86603-65D10-000
ADJUSTER ASSY,FR OUTSIDE,R
|
86603-65D10-000 |
— | ||
|
27
|
27
86601-65D10-000
Adjuster assy,fr inside,r
|
86601-65D10-000 |
— | ||
|
28
|
28
86691-65DA0-000 HANDLE,FR SEAT ADJ |
86691-65DA0-000 |
US $16.56 |
||
|
29
|
29
01550-08123-000
Bolt
|
01550-08123-000 |
— | ||
| replacements | |||||
|
29
|
29
01550-0812B-000 BoltPlug, drain |
01550-0812B-000 |
from US $0.91 |
||
|
29
|
29
01550-0812A-000 BOLT |
01550-0812A-000 |
from US $0.91 |
||
|
30
|
30
01550-10203-000
Bolt
|
01550-10203-000 |
— | ||
| replacement | |||||
|
30
|
30
01550-1020A-000 BOLTBolt, bal sprocket |
01550-1020A-000 |
from US $0.96 |
||
|
31
|
31
85711-65DA0-T01 KNOB,RECL,L |
85711-65DA0-T01 |
US $9.58 |
||
|
32
|
32
85721-65DA0-T01
カバー,リクライニングアウトサイド,レフト(グレー)
|
85721-65DA0-T01 |
— | ||
| replacement | |||||
|
32
|
32
85720-65DA0-T01 COVER,RCLNG OUTSIDE,L |
85720-65DA0-T01 |
US $46.37 |
||
|
33
|
33
85741-65DA0-T01 COVER,RECL,INSIDE,L |
85741-65DA0-T01 |
US $30.73 |
||
|
34
|
34
86604-65DR0-000
ADJUSTER ASSY,FR OUTSIDE,L
|
86604-65DR0-000 |
— | ||
|
35
|
35
86602-65D10-000 ADJUSTER ASSY,FR INSIDE,L |
86602-65D10-000 |
US $211.60 |
||
|
36
|
36
86891-65DA0-000 HANDLE,FR SEAT ADJUSTER |
86891-65DA0-000 |
US $16.56 |
||
|
37
|
37
85491-65DA0-T01 COVER,ADJUSTER,FR,R |
85491-65DA0-T01 |
US $9.12 |
||
|
38
|
38
85492-65DA0-T01 COVER,ADJUSTER,FR,L |
85492-65DA0-T01 |
US $4.16 |
||
|
39
|
39
85496-65DA0-T01 COVER,ADJUSTER,OUTSIDE,R |
85496-65DA0-T01 |
US $9.44 |
||
|
40
|
40
85495-65DA0-T01 COVER,ADJUSTER BRACKET,INSIDE |
85495-65DA0-T01 |
US $4.64 |
||
|
41
|
41
85996-65DA0-T01 COVER,ADJUSTER,OUTSIDE,L |
85996-65DA0-T01 |
US $4.64 |
||
|
42
|
42
01551-10253-000
Bolt
|
01551-10253-000 |
— | ||
| replacement | |||||
|
42
|
42
01551-1025A-000 Bolt |
01551-1025A-000 |
US $1.12 |
||
