Mt clutch (TYPE 4:MT:JB419WD:RHD) Diagram Suzuki GRAND VITARA
- Year
- -
- Sales region
- Africa
- drive
- 2WD
- transmission
- MT
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
22000-80K00-000
Clutch set
|
22000-80K00-000 |
— | ||
| replacement | |||||
|
1
|
1
22000-80K01-000
CLUTCH SET
|
22000-80K01-000 |
— | ||
|
2
|
2
09103-06294-000 BOLT(6X13) |
09103-06294-000 |
US $21 |
||
|
3
|
3
23810-64J00-000
Cylinder assy,clutch master
|
23810-64J00-000 |
— | ||
| replacement | |||||
|
3
|
3
23810-64J21-000 CYLINDER ASSY,CLUTCH MASTER |
23810-64J21-000 |
from US $114.57 |
||
|
4
|
4
23820-64J00-000 CYLINDER ASSY,CLUTCH OPERATING |
23820-64J00-000 |
from US $117.47 |
||
|
5
|
5
23830-80K20-000
PIPE,CLUTCH OIL NO.1
|
23830-80K20-000 |
— | ||
|
6
|
6
23830-80K60-000 PIPE,CLUTCH OIL NO.2 |
23830-80K60-000 |
US $23.92 |
||
|
7
|
7
23856-64JA0-000 JOINT ASSY,CLUTCH PIPE |
23856-64JA0-000 |
from US $17.62 |
||
|
8
|
8
23871-64J00-000 BRACKET,CLUTCH OIL HOSE |
23871-64J00-000 |
US $4.32 |
||
|
9
|
9
23874-64J00-000 SLEEVE,CLUTCH PIPE JOINT |
23874-64J00-000 |
from US $1.85 |
||
|
10
|
10
23881-64J20-000 HOSE,CLUTCH RESERVOIR |
23881-64J20-000 |
US $35.20 |
||
|
11
|
11
09159-08127-000 NUT |
09159-08127-000 |
US $9.90 |
||
|
12
|
12
09200-10021-000 PIN |
09200-10021-000 |
US $1.28 |
||
|
13
|
13
09385-10006-000 PIN,SNAPPin |
09385-10006-000 |
from US $1.60 |
||
|
14
|
14
07130-0620A-000 BOLT |
07130-0620A-000 |
from US $0.91 |
||
|
15
|
15
08316-1006A-000 NUT |
08316-1006A-000 |
from US $0.80 |
||
