Parking brake (PARKING BRAKE) Diagram Suzuki GRAND VITARA
- Year
- -
- Sales region
- U.S.A.
- drive
- 2WD
- transmission
- MT
- grade
- BASE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
54620-77K00-000 PLATE ASSY,BRAKE BACKING,R |
54620-77K00-000 |
US $104.80 |
||
|
2
|
2
54630-77K00-000 PLATE ASSY,BRAKE BACKING,L |
54630-77K00-000 |
from US $40.59 |
||
|
3
|
3
54600-77K00-000 SHOE SET,PARKING BRAKE |
54600-77K00-000 |
from US $92.74 |
||
|
4
|
4
53753-67H00-000 PUSH NUT,PARKING LEVER |
53753-67H00-000 |
from US $1.22 |
||
|
5
|
5
54640-77K00-000 LEVER ASSY,OPERATING,R |
54640-77K00-000 |
from US $9.25 |
||
|
6
|
6
54650-77K00-000 LEVER ASSY,OPERATING,L |
54650-77K00-000 |
from US $9.25 |
||
|
7
|
7
54660-77K00-000 ADJUSTER ASSY |
54660-77K00-000 |
from US $7.67 |
||
|
8
|
8
54670-77K00-000 ANCHOR ASSY |
54670-77K00-000 |
US $38.27 |
||
|
9
|
9
54681-77K00-000 STRUT |
54681-77K00-000 |
US $7.68 |
||
|
10
|
10
54691-77K00-000 SPRING,RETURN UPPER |
54691-77K00-000 |
US $3.83 |
||
|
11
|
11
54692-77K00-000 SPRING,RETURN LOWER |
54692-77K00-000 |
US $2.56 |
||
|
12
|
12
54693-77K00-000 SPRING,SHOE HOLD |
54693-77K00-000 |
US $1.60 |
||
|
13
|
13
54695-77K00-000 PIN,SHOE HOLD |
54695-77K00-000 |
US $1.60 |
||
|
14
|
14
54694-77K00-000 WASHER CUP |
54694-77K00-000 |
from US $1.60 |
||
|
15
|
15
54696-77K00-000 SPRING,ANTIRATTLE |
54696-77K00-000 |
US $3.09 |
||
|
16
|
16
54696-77K00-000 SPRING,ANTIRATTLE |
54696-77K00-000 |
US $3.09 |
||
|
17
|
17
53247-52D00-000
Bolt,serration
|
53247-52D00-000 |
— | ||
| replacement | |||||
|
17
|
17
53247-77K00-000 BOLT,SERRATION |
53247-77K00-000 |
US $1.82 |
||
|
18
|
18
01550-0610B-000 BoltBolt |
01550-0610B-000 |
from US $0.80 |
||
|
19
|
19
09159-16022-000 NUT |
09159-16022-000 |
US $29.10 |
||
