Headlamp (HEADLAMP) Diagram Suzuki GRAND VITARA
- Year
- -
- Sales region
- Middle east
- grade
- BASE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35300-78J01-000
HEADLAMP ASSY,L
|
35300-78J01-000 |
— | ||
|
2
|
2
35100-78J01-000 HEADLAMP ASSY,R |
35100-78J01-000 |
from US $570.24 |
||
|
3
|
3
35003-78J01-000
BULB,HEADLAMP
|
35003-78J01-000 |
— | ||
| replacement | |||||
|
3
|
3
35003-78J02-000 BULB,HEADLAMP |
35003-78J02-000 |
US $52.26 |
||
|
4
|
4
35001-78J00-000 BULB(#3457NA) |
35001-78J00-000 |
US $9.38 |
||
|
5
|
5
35002-78J00-000 BULB |
35002-78J00-000 |
US $14.68 |
||
|
6
|
6
35002-78J00-000 BULB |
35002-78J00-000 |
US $14.68 |
||
|
7
|
7
48159-78J01-000
Bolt
|
48159-78J01-000 |
— | ||
|
8
|
8
35102-78J00-000
NUT,M4.2X1.41
|
35102-78J00-000 |
— | ||
|
9
|
9
73114-78J00-000
BOLT,M4.2X1.41X25
|
73114-78J00-000 |
— | ||
|
10
|
10
35500-78J00-000 LAMP ASSY,FR FOGUPPER,UPPER SUNROOF |
35500-78J00-000 |
US $203.51 |
||
|
11
|
11
35550-78J00-000
ADJUSTER,FR FOG LAMP
UPPER,UPPER SUNROOF |
35550-78J00-000 |
— | ||
|
12
|
12
35005-78J00-000
Bulb(#h11)
UPPER,UPPER SUNROOF |
35005-78J00-000 |
— | ||
| replacement | |||||
|
12
|
12
35005-78J01-000 BULB(#H11)UPPER,UPPER SUNROOF |
35005-78J01-000 |
US $48.21 |
||
|
13
|
13
36613-78J20-000
Harness,fwd lamp wiring
BASE |
36613-78J20-000 |
— | ||
| replacement | |||||
|
13
|
13
36613-78J10-000
HARNESS,FWD LAMP WIRING
BASE |
36613-78J10-000 |
— | ||
|
13
|
13
36613-78J30-000
Harness, head lamp
UPPER,UPPER SUNROOF |
36613-78J30-000 |
— | ||
| replacement | |||||
|
13
|
13
36613-78J10-000
HARNESS,FWD LAMP WIRING
UPPER,UPPER SUNROOF |
36613-78J10-000 |
— | ||
