front-drive shaft (2WD:AT:(G,X,S); 1998-09-01~1999-11-01) Diagram Suzuki KEI/SWIFT
- Year
- 1999 - 2011
- Sales region
- Japan
- Engine
- K6A
- supercharge
- TURBO
- drive
- 2WD
- transmission
- AT
- Number of doors
- 5DR
- grade
- NORMAL
- number of the gears
- 4AT
- air bag
- AB
- abs
- ABS
- splr
- SPLR
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
44101-78G30-000
シャフトアッシ,フロントドライブ,ライト
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44101-78G30-000 |
— | ||
| replacement | |||||
|
1
|
1
44101-73H25-000 SHAFT ASSY,FRONT DRIVE,R2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44101-73H25-000 |
US $1,334.20 |
||
|
2
|
2
44118-76G30-000
Boot set, wheel side
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44118-76G30-000 |
— | ||
| replacement | |||||
|
2
|
2
44118-76G60-000 BOOT SET,WHEEL SIDE2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44118-76G60-000 |
US $81.33 |
||
|
3
|
3
44124-86011-000 BAND,BOOT2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44124-86011-000 |
US $6.81 |
||
|
4
|
4
44222-51F00-000 BAND,BOOT2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44222-51F00-000 |
US $10.23 |
||
|
5
|
5
44117-78G10-000
JOINT ASSY,DIFF SIDE
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44117-78G10-000 |
— | ||
| replacement | |||||
|
5
|
5
44117-78G11-000 JOINT ASSY,DIFF SIDE2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44117-78G11-000 |
US $322 |
||
|
6
|
6
44119-75F00-000
BOOT SET,DIFF SIDE
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44119-75F00-000 |
— | ||
| replacement | |||||
|
6
|
6
44119-60DD2-000 BOOT SET,DIFF SIDE2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44119-60DD2-000 |
US $69.92 |
||
|
7
|
7
44111-64B90-000 RING,SNAP2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44111-64B90-000 |
US $2.80 |
||
|
8
|
8
44124-86011-000 BAND,BOOT2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44124-86011-000 |
US $6.81 |
||
|
9
|
9
44122-86010-000 BAND,BOOTClamp, differential side outer boot 2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44122-86010-000 |
from US $9.02 |
||
|
10
|
10
09381-24001-000 RING,SNAPRing (od:24,d:1.6) 2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
09381-24001-000 |
from US $1.60 |
||
|
11
|
11
44411-78G10-000
DAMPER SET
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44411-78G10-000 |
— | ||
| replacement | |||||
|
11
|
11
44411-78GB0-000 DAMPER SET2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44411-78GB0-000 |
US $87.22 |
||
|
12
|
12
44102-76G80-000
Shaft assy, front drive lh
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44102-76G80-000 |
— | ||
| replacement | |||||
|
12
|
12
44102-76G84-000 SHAFT ASSY,FRONT DRIVE,L2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44102-76G84-000 |
US $1,393 |
||
|
13
|
13
44118-76G30-000
Boot set, wheel side
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44118-76G30-000 |
— | ||
| replacement | |||||
|
13
|
13
44118-76G60-000 BOOT SET,WHEEL SIDE2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44118-76G60-000 |
US $81.33 |
||
|
14
|
14
44222-51F00-000 BAND,BOOT2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44222-51F00-000 |
US $10.23 |
||
|
15
|
15
44124-86011-000 BAND,BOOT2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44124-86011-000 |
US $6.81 |
||
|
16
|
16
44117-76G40-000
JOINT ASSY,DIFF SIDE
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44117-76G40-000 |
— | ||
|
17
|
17
44119-78G10-000
BOOT SET,DIFF SIDE
2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44119-78G10-000 |
— | ||
| replacement | |||||
|
17
|
17
44119-75F61-000 BOOT SET,DIFF SIDE2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44119-75F61-000 |
US $69.92 |
||
|
18
|
18
44111-78010-000 RING,SNAP2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44111-78010-000 |
US $2.80 |
||
|
19
|
19
44112-78010-000 CIRCLIP2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44112-78010-000 |
from US $5.26 |
||
|
20
|
20
44122-86010-000 BAND,BOOTClamp, differential side outer boot 2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44122-86010-000 |
from US $9.02 |
||
|
21
|
21
44124-86011-000 BAND,BOOT2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
44124-86011-000 |
US $6.81 |
||
|
22
|
22
09381-24001-000 RING,SNAPRing (od:24,d:1.6) 2WD:AT:(G,X,S); 1998-09-01~1999-11-01 |
09381-24001-000 |
from US $1.60 |
||
