intermediate shaft (M15A; 2003-06-01~2005-03-01) Diagram Suzuki KEI/SWIFT
- Year
- 2003 - 2011
- Sales region
- Japan
- Engine
- M15A
- drive
- 2WD
- transmission
- MT
- Number of doors
- 3DR
- grade
- SS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
27800-60J00-000 SHAFT ASSY,DRIVE INTERMEDIATEM15A; 2003-06-01~2005-03-01 |
27800-60J00-000 |
US $404.80 |
||
|
2
|
2
09381-25002-000 RING,SNAPM15A; 2003-06-01~2005-03-01 |
09381-25002-000 |
from US $1.80 |
||
|
3
|
3
27841-64G00-000 SEAL,DRIVE INTERMEDIATEM15A; 2003-06-01~2005-03-01 |
27841-64G00-000 |
from US $10.19 |
||
|
4
|
4
08331-41586-000
Circlip
M15A; 2003-06-01~2005-03-01 |
08331-41586-000 |
— | ||
| replacement | |||||
|
4
|
4
08331-4158A-000 CIRCLIPM15A; 2003-06-01~2005-03-01 |
08331-4158A-000 |
from US $2.56 |
||
|
5
|
5
09262-28030-000
Bearing,28x58x16
M15A; 2003-06-01~2005-03-01 |
09262-28030-000 |
— | ||
| replacement | |||||
|
5
|
5
27831-68L10-000 BEARING,DRIVE INTERMEDIATEM15A; 2003-06-01~2005-03-01 |
27831-68L10-000 |
from US $29.61 |
||
|
6
|
6
01550-10403-000
Bolt
M15A; 2003-06-01~2005-03-01 |
01550-10403-000 |
— | ||
| replacements | |||||
|
6
|
6
01550-1040B-000 BOLTM15A; 2003-06-01~2005-03-01 |
01550-1040B-000 |
from US $3.74 |
||
|
6
|
6
01550-1040A-000 BOLTM15A; 2003-06-01~2005-03-01 |
01550-1040A-000 |
from US $1.12 |
||
