rear light sheet (2006-06-01~2007-06-01) Diagram Suzuki KEI/SWIFT
- Year
- 2005 - 2011
- Sales region
- Japan
- drive
- 2WD
- transmission
- AT
- grade
- R
- air bag
- 2AB
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
86401-66J10-DJT
Headrestraint assy,rr
ブラック; R,RH; 2006-06-01~2007-06-01 |
86401-66J10-DJT |
— | ||
| replacement | |||||
|
1
|
1
86401-66J11-DJT
HEADRESTRAINT ASSY,RR(BLACK)
ブラック; R,RH; 2006-06-01~2007-06-01 |
86401-66J11-DJT |
— | ||
|
2
|
2
87180-57K00-CLS
Trim,rr cush,r(black)
ブラック,シートベルト P4Z(グレー); 2AB; 2006-06-01~2007-06-01 |
87180-57K00-CLS |
— | ||
|
2
|
2
87180-57K00-DZT
Trim comp,rr cush,r
ブラック/レッド/グレー,シートベルト 5PK(ブラック); 2AB; 2006-06-01~2007-06-01 |
87180-57K00-DZT |
— | ||
| replacement | |||||
|
2
|
2
87180-57K01-DZT
TRIM,RR CUSHION,R(BLACK/RED)
ブラック/レッド/グレー,シートベルト 5PK(ブラック); 2AB; 2006-06-01~2007-06-01 |
87180-57K01-DZT |
— | ||
|
3
|
3
87105-57K01-000
CUSHION S/ASSY,RR,R
2006-06-01~2007-06-01 |
87105-57K01-000 |
— | ||
|
4
|
4
87134-63J00-000 BUSH,CUSH LOCK LEVER2006-06-01~2007-06-01 |
87134-63J00-000 |
US $5.89 |
||
|
5
|
5
87153-63J01-000 BOLT,RR CUSH LEG2006-06-01~2007-06-01 |
87153-63J01-000 |
US $13.73 |
||
|
6
|
6
87154-63J00-000 COLLAR,SPRING2006-06-01~2007-06-01 |
87154-63J00-000 |
US $13.14 |
||
|
7
|
7
87157-63J00-000 BUSH,RR CUSH LEG2006-06-01~2007-06-01 |
87157-63J00-000 |
US $4.64 |
||
|
8
|
8
87158-63J00-000 SPRING,RR CUSH LEG2006-06-01~2007-06-01 |
87158-63J00-000 |
US $69.55 |
||
|
9
|
9
87460-63J02-000 LOCK ASSY,RR CUSH,R2006-06-01~2007-06-01 |
87460-63J02-000 |
US $90.90 |
||
|
10
|
10
09103-11002-000 BOLT(7/16X22)2006-06-01~2007-06-01 |
09103-11002-000 |
US $18 |
||
|
11
|
11
09403-04306-000 CLAMPConnector, choke rod 2006-06-01~2007-06-01 |
09403-04306-000 |
US $20.20 |
||
|
12
|
12
08316-1008A-000 NUTNut, idle gear shaft 2006-06-01~2007-06-01 |
08316-1008A-000 |
from US $0.76 |
||
|
13
|
13
08316-1008A-000 NUTNut, idle gear shaft 2006-06-01~2007-06-01 |
08316-1008A-000 |
from US $0.76 |
||
|
14
|
14
87119-63J00-P4Z COVER,RR SEAT CUSH,Rグレー; 2006-06-01~2007-06-01 |
87119-63J00-P4Z |
US $66.24 |
||
|
15
|
15
03241-0512A-000 SCREW2006-06-01~2007-06-01 |
03241-0512A-000 |
from US $0.68 |
||
|
16
|
16
03241-0516A-000 SCREW2006-06-01~2007-06-01 |
03241-0516A-000 |
from US $0.76 |
||
|
17
|
17
87159-65DA0-000 CUSHION,RR CUSH2006-06-01~2007-06-01 |
87159-65DA0-000 |
US $3.90 |
||
|
18
|
18
09387-19001-000 RING2006-06-01~2007-06-01 |
09387-19001-000 |
US $1.76 |
||
|
19
|
19
87171-63J02-P4Z
COVER,HINGE INSIDE R
グレー; 2006-06-01~2007-06-01 |
87171-63J02-P4Z |
— | ||
|
20
|
20
87301-63JA0-CLS
バックアッシ,リヤ,ライト
ブラック,シートベルト P4Z(グレー); 2AB; 2006-06-01~2007-06-01 |
87301-63JA0-CLS |
— | ||
| replacement | |||||
|
20
|
20
87301-63JA1-CLS
Back assy,rr,r(red/black)
ブラック,シートベルト P4Z(グレー); 2AB; 2006-06-01~2007-06-01 |
87301-63JA1-CLS |
— | ||
|
20
|
20
87301-63JA0-DZT
バックアッシ,リヤ,ライト
ブラック/レッド/グレー,シートベルト 5PK(ブラック); 2AB; 2006-06-01~2007-06-01 |
87301-63JA0-DZT |
— | ||
| replacement | |||||
|
20
|
20
87301-63JA1-DZT
Back assy,rr,r(red/black)
ブラック/レッド/グレー,シートベルト 5PK(ブラック); 2AB; 2006-06-01~2007-06-01 |
87301-63JA1-DZT |
— | ||
|
21
|
21
85341-63J10-P4Z
GUIDE,HEADRESTRAINT
グレー; 2006-06-01~2007-06-01 |
85341-63J10-P4Z |
— | ||
| replacements | |||||
|
21
|
21
85341-63J11-P4Z
GUIDE,HEADRESTRAINT
グレー; 2006-06-01~2007-06-01 |
85341-63J11-P4Z |
— | ||
|
21
|
21
85341-63J12-P4Z Guide,headrestraintグレー; 2006-06-01~2007-06-01 |
85341-63J12-P4Z |
US $7.36 |
||
|
22
|
22
85840-63J10-P4Z
GUIDE,HEADRESTRAINT
グレー; 2006-06-01~2007-06-01 |
85840-63J10-P4Z |
— | ||
| replacements | |||||
|
22
|
22
85840-63J11-P4Z
GUIDE COMP,HEADRESTRAINT
グレー; 2006-06-01~2007-06-01 |
85840-63J11-P4Z |
— | ||
|
22
|
22
85840-63J12-P4Z Guide Comp,headrestraintグレー; 2006-06-01~2007-06-01 |
85840-63J12-P4Z |
US $9.12 |
||
|
23
|
23
87225-53JA0-P4Z
Cover,tether anchor
グレー; 2006-06-01~2007-06-01 |
87225-53JA0-P4Z |
— | ||
| replacement | |||||
|
23
|
23
87225-53JB0-P4Z COVER,TETHER ANCHORグレー; 2006-06-01~2007-06-01 |
87225-53JB0-P4Z |
US $6.51 |
||
|
24
|
24
87380-63JA0-CLS
トリム,リヤバック,ライト
ブラック,シートベルト P4Z(グレー); 2AB; 2006-06-01~2007-06-01 |
87380-63JA0-CLS |
— | ||
| replacement | |||||
|
24
|
24
87380-63JA1-CLS
トリム,リヤバック,ライト
ブラック,シートベルト P4Z(グレー); 2AB; 2006-06-01~2007-06-01 |
87380-63JA1-CLS |
— | ||
|
24
|
24
87380-63JA0-DZT
トリム,リヤバック,ライト
ブラック/レッド/グレー,シトベルト 5PK(ブラック); 2AB; 2006-06-01~2007-06-01 |
87380-63JA0-DZT |
— | ||
| replacement | |||||
|
24
|
24
87380-63JA1-DZT
トリム,リヤバック,ライト
ブラック/レッド/グレー,シトベルト 5PK(ブラック); 2AB; 2006-06-01~2007-06-01 |
87380-63JA1-DZT |
— | ||
|
25
|
25
87305-63JA0-P4Z
バックアッシ,リヤバックライト(グレー)
グレー; 2006-06-01~2007-06-01 |
87305-63JA0-P4Z |
— | ||
|
26
|
26
87480-62J00-000
Lock assy,rr back,r
2006-06-01~2007-06-01 |
87480-62J00-000 |
— | ||
| replacement | |||||
|
26
|
26
87480-62J02-000 LOCK ASSY,RR BACK,R2006-06-01~2007-06-01 |
87480-62J02-000 |
US $76.54 |
||
|
27
|
27
87483-80J00-P4Z
Knob,rr back lock
グレー; 2006-06-01~2007-06-01 |
87483-80J00-P4Z |
— | ||
|
28
|
28
87484-80J01-000
Case,rr back lock
2006-06-01~2007-06-01 |
87484-80J01-000 |
— | ||
| replacement | |||||
|
28
|
28
87484-80J11-000 CASE,RR BACK LOCK2006-06-01~2007-06-01 |
87484-80J11-000 |
US $10.56 |
||
|
29
|
29
87485-79J00-000 WIRE,RR BACK LOCK,R2006-06-01~2007-06-01 |
87485-79J00-000 |
US $4.05 |
||
|
30
|
30
87486-79J00-000 SPRING,BACK KNOB2006-06-01~2007-06-01 |
87486-79J00-000 |
US $9.68 |
||
|
31
|
31
01550-0835A-000 BOLT2006-06-01~2007-06-01 |
01550-0835A-000 |
from US $1.06 |
||
|
32
|
32
87482-80J00-P4Z BEZEL,RR BACK LOCK BTNグレー; 2006-06-01~2007-06-01 |
87482-80J00-P4Z |
US $3.53 |
||
|
33
|
33
09387-19001-000 RING2006-06-01~2007-06-01 |
09387-19001-000 |
US $1.76 |
||
|
34
|
34
87333-63J01-000 BOLT,RR SEAT HINGE OUTER2006-06-01~2007-06-01 |
87333-63J01-000 |
US $3.75 |
||
|
35
|
35
87334-63J01-000 BUSH,HINGE OTR2006-06-01~2007-06-01 |
87334-63J01-000 |
US $3.09 |
||
|
36
|
36
87172-63J01-P4Z COVER,HINGE OUTSIDE,Rグレー; 2006-06-01~2007-06-01 |
87172-63J01-P4Z |
US $7.62 |
||
|
37
|
37
87491-63J00-P4Z COVER,RR CUSH HINGE FRグレー; 2006-06-01~2007-06-01 |
87491-63J00-P4Z |
US $6.88 |
||
|
38
|
38
87492-63J00-P4Z COVER,RR CUSH HINGE RRグレー; 2006-06-01~2007-06-01 |
87492-63J00-P4Z |
US $10.67 |
||
|
39
|
39
87870-63J01-000 STRIKER,RR BACK R2006-06-01~2007-06-01 |
87870-63J01-000 |
US $34.96 |
||
|
40
|
40
01551-0820A-000 BOLT2006-06-01~2007-06-01 |
01551-0820A-000 |
from US $0.96 |
||
|
41
|
41
01551-1025A-000 Bolt2006-06-01~2007-06-01 |
01551-1025A-000 |
US $1.12 |
||
|
42
|
42
08316-1010A-000 NUTNut, kick starter 2006-06-01~2007-06-01 |
08316-1010A-000 |
from US $0.76 |
||
