Front suspension (FRONT SUSPENSION) Diagram Suzuki SAMURAI
- Year
- -
- Sales region
- Africa
- grade
- JA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
41110-84C00-000
Spring assy, front
|
41110-84C00-000 |
— | ||
|
2
|
2
42110-80000-000
Bumper, spring
|
42110-80000-000 |
— | ||
| replacement | |||||
|
2
|
2
42110-80010-000 BUMPER,FR SPRING |
42110-80010-000 |
from US $14.81 |
||
|
3
|
3
01107-08163-000
Bolt m8x1.25x16
|
01107-08163-000 |
— | ||
| replacements | |||||
|
3
|
3
01500-0816B-000 BoltBolt |
01500-0816B-000 |
from US $0.96 |
||
|
3
|
3
01500-08163-000
Bolt
|
01500-08163-000 |
— | ||
|
4
|
4
41230-70A00-000 SEAT,FRONT SPRING,R |
41230-70A00-000 |
from US $14.72 |
||
|
5
|
5
41240-70A00-000 SEAT,FR SPRING,L |
41240-70A00-000 |
from US $20.27 |
||
|
6
|
6
41411-84CB0-000
U bolt,rh
|
41411-84CB0-000 |
— | ||
|
7
|
7
41411-84CA0-000
U bolt, lh
|
41411-84CA0-000 |
— | ||
|
8
|
8
08321-A3112-300
Washer
|
08321-A3112-300 |
— | ||
|
9
|
9
08310-00123-000
Nut
|
08310-00123-000 |
— | ||
| replacement | |||||
|
9
|
9
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
|
10
|
10
09305-13002-000 BUSH |
09305-13002-000 |
from US $1.55 |
||
|
11
|
11
09305-13002-000 BUSH |
09305-13002-000 |
from US $1.55 |
||
|
12
|
12
41461-84CA0-000
Plate, shackle inner
|
41461-84CA0-000 |
— | ||
|
13
|
13
41462-84CA0-000
Plate, shackle outer
|
41462-84CA0-000 |
— | ||
|
14
|
14
41463-82000-000 PIN,SHACKLE |
41463-82000-000 |
from US $4.37 |
||
|
15
|
15
08321-A3110-300
Washer plain
|
08321-A3110-300 |
— | ||
|
16
|
16
08310-00103-000
Nut
|
08310-00103-000 |
— | ||
| replacements | |||||
|
16
|
16
08310-0010B-000 NUT |
08310-0010B-000 |
from US $0.83 |
||
|
16
|
16
08310-0010A-000 NUT |
08310-0010A-000 |
from US $0.80 |
||
|
17
|
17
41331-62020-000 BUSH |
41331-62020-000 |
from US $17.91 |
||
|
18
|
18
09103-12048-000 BOLT(12X90)12X90 |
09103-12048-000 |
from US $6.17 |
||
|
19
|
19
09180-12035-000 SPACER(12X16X64.5)12X16X64.5 |
09180-12035-000 |
from US $2.24 |
||
|
20
|
20
08321-A3112-300
Washer
|
08321-A3112-300 |
— | ||
|
21
|
21
08310-00123-000
Nut
|
08310-00123-000 |
— | ||
| replacement | |||||
|
21
|
21
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
|
22
|
22
41600-84CA0-000
Absorber, front shock
|
41600-84CA0-000 |
— | ||
|
23
|
23
08310-00123-000
Nut
|
08310-00123-000 |
— | ||
| replacement | |||||
|
23
|
23
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
|
24
|
24
08322-01163-000
Washer
|
08322-01163-000 |
— | ||
| replacement | |||||
|
24
|
24
08322-0116A-000 WASHER |
08322-0116A-000 |
from US $0.80 |
||
|
25
|
25
09160-12073-000 WASHER(12.5X32X2.3)Washer (12.5x32x2.3) 12.5X32X2.3 |
09160-12073-000 |
from US $0.79 |
||
|
26
|
26
08310-00123-000
Nut
|
08310-00123-000 |
— | ||
| replacement | |||||
|
26
|
26
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
|
27
|
27
08321-B3108-300
Washer
|
08321-B3108-300 |
— | ||
