Brake master cylinder (TURBO DIESEL) Diagram Suzuki SAMURAI
- Year
- -
- Sales region
- Europe
- grade
- JA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
0
|
0
51000-A56B0-000
Main cylinder servo assy
|
51000-A56B0-000 |
— | ||
|
1
|
1
00000-A0072-100
Main cylinder
|
00000-A0072-100 |
— | ||
|
2
|
2
00000-A0072-200
Seal gasket
|
00000-A0072-200 |
— | ||
|
3
|
3
00000-A0072-300
Tank repair set
|
00000-A0072-300 |
— | ||
|
4
|
4
00000-A0028-300
Plug
|
00000-A0028-300 |
— | ||
|
5
|
5
00000-A0098-300
Boster assy
|
00000-A0098-300 |
— | ||
|
6
|
6
00000-A0072-000
Repair set
|
00000-A0072-000 |
— | ||
|
7
|
7
51010-C8302-100
Vacuum hose
|
51010-C8302-100 |
— | ||
|
8
|
8
51911-85C00-000
Clamp, return hose
|
51911-85C00-000 |
— | ||
|
9
|
9
11029-86CA0-000
Vacuum pump
|
11029-86CA0-000 |
— | ||
|
10
|
10
09160-86CA8-000
Plain washer
8x22-2.5 |
09160-86CA8-000 |
— | ||
|
11
|
11
08321-86CA1-000
Spring washer
8X17-0.8 |
08321-86CA1-000 |
— | ||
|
12
|
12
01570-86CA6-000
Screw h
8x125-16 |
01570-86CA6-000 |
— | ||
|
13
|
13
45071-86CA0-000
Vacuum pum pulley
|
45071-86CA0-000 |
— | ||
|
14
|
14
01500-06123-000
Bolt, front
|
01500-06123-000 |
— | ||
| replacement | |||||
|
14
|
14
01500-0612A-000 Bolt |
01500-0612A-000 |
from US $0.76 |
||
|
15
|
15
08321-01063-000
Washer, lock
|
08321-01063-000 |
— | ||
| replacement | |||||
|
15
|
15
08321-0106A-000 WASHER,LOCK |
08321-0106A-000 |
from US $0.76 |
||
|
16
|
16
00069-86CA0-000
Screw
|
00069-86CA0-000 |
— | ||
|
17
|
17
08322-01083-000
WASHER
|
08322-01083-000 |
— | ||
| replacements | |||||
|
17
|
17
08322-0108B-000 WASHER |
08322-0108B-000 |
from US $0.96 |
||
|
17
|
17
08322-0108A-000 WASHER |
08322-0108A-000 |
from US $0.96 |
||
|
18
|
18
09159-86CA0-000
Connecting rod bolt
|
09159-86CA0-000 |
— | ||
|
19
|
19
01500-08203-000
Bolt
|
01500-08203-000 |
— | ||
| replacement | |||||
|
19
|
19
01500-0820A-000 Bolt |
01500-0820A-000 |
from US $0.80 |
||
|
20
|
20
08321-01083-000
Lock washer
|
08321-01083-000 |
— | ||
| replacements | |||||
|
20
|
20
08321-0108B-000 WASHER,LOCK |
08321-0108B-000 |
from US $0.76 |
||
|
20
|
20
08321-0108A-000 WASHER,LOCK |
08321-0108A-000 |
from US $0.88 |
||
|
21
|
21
09160-86CA0-000
Washer
|
09160-86CA0-000 |
— | ||
|
22
|
22
17921-86CA0-000
Arm,vaccum pump
|
17921-86CA0-000 |
— | ||
|
23
|
23
17521-86CA0-000
Belt, vaccum pump
|
17521-86CA0-000 |
— | ||
|
24
|
24
51812-85C00-000
Pin
|
51812-85C00-000 |
— | ||
|
25
|
25
00000-A0116-400
Fork
|
00000-A0116-400 |
— | ||
|
26
|
26
51811-85C00-000
Cylinder pin
|
51811-85C00-000 |
— | ||
