Rear seat (REAR SEAT) Diagram Suzuki SIDEKICK
- Year
- -
- Sales region
- Caribbean
- grade
- JA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
|
87002-60A10-000
Seat compl.assy,l/h
TYPE 1,JX |
87002-60A10-000 |
— | ||
|
|
87002-63A11-000
Seat compl.assy,l/h
TYPE 3 |
87002-63A11-000 |
— | ||
|
|
87002-B63A1-100
Seat compl.assy,l/h
TYPE 2,JX |
87002-B63A1-100 |
— | ||
|
|
87002-C63A1-100
Seat compl.assy,l/h
TYPE 2,JA |
87002-C63A1-100 |
— | ||
|
|
87002-D60A1-000
Seat compl.assy,l/h
TYPE 1JA |
87002-D60A1-000 |
— | ||
|
|
87001-60A10-000
Seat compl.assy,r/h
TYPE 1,JX |
87001-60A10-000 |
— | ||
|
|
87001-63A11-000
Seat compl.assy,r/h
TYPE 3 |
87001-63A11-000 |
— | ||
|
|
87001-B63A1-100
Seat compl.assy,r/h
TYPE 2,JX |
87001-B63A1-100 |
— | ||
|
|
87001-C63A1-100
Seat compl.assy,r/h
TYPE 2,JA |
87001-C63A1-100 |
— | ||
|
|
87001-D60A1-000
Seat compl.assy,r/h
TYPE 1,JA |
87001-D60A1-000 |
— | ||
|
1
|
1
87101-60A10-000
Cushion assy,r/h
TYPE 1,JX |
87101-60A10-000 |
— | ||
|
1
|
1
87101-63A10-000
Cushion assy,r/h
TYPE 3 |
87101-63A10-000 |
— | ||
|
1
|
1
87101-B63A1-000
Cushion assy,r/h
TYPE 2,JX |
87101-B63A1-000 |
— | ||
|
1
|
1
87101-C63A1-000
Cushion assy,r/h
TYPE 2,JA |
87101-C63A1-000 |
— | ||
|
1
|
1
87101-D60A1-000
Cushion assy,r/h
TYPE 1,JX |
87101-D60A1-000 |
— | ||
|
2
|
2
87180-60A10-000
Cushion ,r/h
TYPE 1:JX,TYPE 3 |
87180-60A10-000 |
— | ||
|
2
|
2
87180-F60A1-000
Cushion ,r/h
TYPE 2:JX |
87180-F60A1-000 |
— | ||
|
3
|
3
87291-60A10-000 CUSHION,RR SEAT |
87291-60A10-000 |
US $1.95 |
||
|
4
|
4
02142-05166-000
Screw
|
02142-05166-000 |
— | ||
| replacements | |||||
|
4
|
4
02142-0516B-000 SCREW |
02142-0516B-000 |
from US $0.96 |
||
|
4
|
4
02142-0516A-000 SCREWScrew |
02142-0516A-000 |
from US $0.76 |
||
|
5
|
5
08322-11066-000
E ring
|
08322-11066-000 |
— | ||
| replacement | |||||
|
5
|
5
08322-0106B-000 WASHER |
08322-0106B-000 |
from US $0.76 |
||
|
6
|
6
87191-60A10-5PK
Board, cushion under rh
TYPE 1 |
87191-60A10-5PK |
— | ||
| replacement | |||||
|
6
|
6
87191-63A10-5PK
BOARD,RR SEAT CUSH UND,R
TYPE 1 |
87191-63A10-5PK |
— | ||
|
6
|
6
87191-63A10-000
Cushion cover,r/h
|
87191-63A10-000 |
— | ||
|
7
|
7
02142-05164-000
Screw
|
02142-05164-000 |
— | ||
| replacements | |||||
|
7
|
7
02142-0516B-000 SCREW |
02142-0516B-000 |
from US $0.96 |
||
|
7
|
7
02142-0516A-000 SCREWScrew |
02142-0516A-000 |
from US $0.76 |
||
|
8
|
8
09169-06034-000
Washer
|
09169-06034-000 |
— | ||
| replacement | |||||
|
8
|
8
09169-06071-000 WASHERWasher, rr side |
09169-06071-000 |
from US $0.96 |
||
|
9
|
9
87301-60A10-000
Back assy,r/h
TYPE 1:JK |
87301-60A10-000 |
— | ||
|
9
|
9
87301-60A11-000
Back assy,r/h
TYPE 3 |
87301-60A11-000 |
— | ||
|
9
|
9
87301-D60A1-000
Back assy,r/h
TYPE 1:JA |
87301-D60A1-000 |
— | ||
|
9
|
9
87301-D60A1-100
Back assy,r/h
TYPE 2:JA |
87301-D60A1-100 |
— | ||
|
9
|
9
87301-F60A1-100
Back assy,r/h
TYPE 2:JK |
87301-F60A1-100 |
— | ||
|
10
|
10
87380-60A10-000
Back assy,r/h
TYPE 1:JK,TYPE 3 |
87380-60A10-000 |
— | ||
|
10
|
10
87380-D60A1-000
Back assy,r/h
TYPE 1,TYPE 2:JA |
87380-D60A1-000 |
— | ||
|
10
|
10
87380-F60A1-000
Back assy,r/h
TYPE 2:JK |
87380-F60A1-000 |
— | ||
|
11
|
11
87210-60A12-5PK
RECLINING,RR SEAT,R
|
87210-60A12-5PK |
— | ||
|
12
|
12
87105-60A10-000
クッションサブアッシ,リヤシート,ライト
|
87105-60A10-000 |
— | ||
|
13
|
13
01137-08166-000
BOLT
|
01137-08166-000 |
— | ||
| replacement | |||||
|
13
|
13
01570-0816A-000 Bolt |
01570-0816A-000 |
from US $1.12 |
||
|
14
|
14
01137-08166-000
BOLT
|
01137-08166-000 |
— | ||
| replacement | |||||
|
14
|
14
01570-0816A-000 Bolt |
01570-0816A-000 |
from US $1.12 |
||
|
15
|
15
87211-60A10-000
Reclining assy pull
|
87211-60A10-000 |
— | ||
|
16
|
16
87221-60A10-000
Reclin.assy cover,rh
|
87221-60A10-000 |
— | ||
|
17
|
17
08332-11084-000
Hinge clip
|
08332-11084-000 |
— | ||
|
18
|
18
87102-60A10-000
Cushion assy,l/h
|
87102-60A10-000 |
— | ||
|
18
|
18
87102-63A10-000
Cushion assy,l/h
TYPE 3 |
87102-63A10-000 |
— | ||
|
18
|
18
87102-B63A1-000
Cushion assy,l/h
TYPE 1:JX |
87102-B63A1-000 |
— | ||
|
18
|
18
87102-C63A1-000
Cushion assy,l/h
TYPE 2:JA |
87102-C63A1-000 |
— | ||
|
18
|
18
87102-D60A1-000
Cushion assy,l/h
TYPE 1:JA |
87102-D60A1-000 |
— | ||
|
19
|
19
87580-60A10-000
Cushion ,l/h
TYPE 1,JX,TYPE 3 |
87580-60A10-000 |
— | ||
|
19
|
19
87580-D60A1-000
Cushion ,l/h
TYPE 1,TYPE 2:JA |
87580-D60A1-000 |
— | ||
|
19
|
19
87580-F60A1-000
Cushion ,l/h
TYPE 2:JX |
87580-F60A1-000 |
— | ||
|
20
|
20
87591-60A11-000
Cushion cover,l/h
TYPE 1 |
87591-60A11-000 |
— | ||
|
20
|
20
87591-63A10-000
Cushion cover,l/h
|
87591-63A10-000 |
— | ||
|
21
|
21
87302-60A10-000
Back assy,l/h
TYPE 1,JX |
87302-60A10-000 |
— | ||
|
21
|
21
87302-60A11-000
Back assy,l/h
TYPE 3 |
87302-60A11-000 |
— | ||
|
21
|
21
87302-D60A1-000
Back assy,l/h
TYPE 1:JA |
87302-D60A1-000 |
— | ||
|
21
|
21
87302-D60A1-100
Back assy,l/h
TYPE 1:JA |
87302-D60A1-100 |
— | ||
|
21
|
21
87302-F60A1-100
Back assy,l/h
TYPE 2:JX |
87302-F60A1-100 |
— | ||
|
22
|
22
87780-60A10-000
Back ,l/h
TYPE 1:JX,TYPE 3 |
87780-60A10-000 |
— | ||
|
22
|
22
87780-D60A1-000
Back ,l/h
TYPE 1,TYPE 3:JA |
87780-D60A1-000 |
— | ||
|
22
|
22
87780-F60A1-000
Back ,l/h
TYPE 2:JX |
87780-F60A1-000 |
— | ||
|
23
|
23
87610-60A12-5PK
RECLINING,RR SEAT,L
|
87610-60A12-5PK |
— | ||
|
24
|
24
87195-60A10-000
Back cover
|
87195-60A10-000 |
— | ||
|
25
|
25
87621-60A10-000
Reclin.assy cover.lh
|
87621-60A10-000 |
— | ||
|
26
|
26
87144-60A10-000 PIN,REAR SEAT STOPPER ROD |
87144-60A10-000 |
from US $2 |
||
|
27
|
27
87277-60A10-000 WASHER,STOPPER ROD PIN |
87277-60A10-000 |
from US $0.59 |
||
|
28
|
28
08322-21086-000
Washer 8mm
|
08322-21086-000 |
— | ||
| replacements | |||||
|
28
|
28
08322-0108B-000 WASHER |
08322-0108B-000 |
from US $0.96 |
||
|
28
|
28
08322-0108A-000 WASHER |
08322-0108A-000 |
from US $0.96 |
||
|
29
|
29
09148-08002-000 NUT |
09148-08002-000 |
US $11 |
||
|
30
|
30
87270-60A11-000 STOPPER,REAR SEAT |
87270-60A11-000 |
US $14.22 |
||
|
31
|
31
87278-60A11-000 PIN,REAR SEAT STOPPER |
87278-60A11-000 |
from US $0.65 |
||
|
32
|
32
09148-03004-000
Nut
|
09148-03004-000 |
— | ||
| replacement | |||||
|
32
|
32
09148-03011-000 NUT |
09148-03011-000 |
from US $2.84 |
||
|
33
|
33
87279-60A10-000
ホルダ,リヤシートストッパ
TYPE 1 |
87279-60A10-000 |
— | ||
| replacement | |||||
|
33
|
33
87279-60A11-000 HOLDER,RR SEAT STOPPERTYPE 1 |
87279-60A11-000 |
from US $2.43 |
||
|
33
|
33
87279-60A11-000 HOLDER,RR SEAT STOPPER |
87279-60A11-000 |
from US $2.43 |
||
|
34
|
34
08322-11066-000
E ring
|
08322-11066-000 |
— | ||
| replacement | |||||
|
34
|
34
08322-0106B-000 WASHER |
08322-0106B-000 |
from US $0.76 |
||
|
35
|
35
09148-06005-000
Nut seat moldin
|
09148-06005-000 |
— | ||
| replacement | |||||
|
35
|
35
09148-06008-000 NUTNut, adjuster knob |
09148-06008-000 |
from US $0.83 |
||
|
36
|
36
87810-60A00-000
Adjuster, outside rh seat
|
87810-60A00-000 |
— | ||
| replacement | |||||
|
36
|
36
87810-60A10-000
ADJUSTER,RR SEAT SLIDE OUTER,R
|
87810-60A10-000 |
— | ||
|
37
|
37
87820-60A00-000
Adjuster, inside rh seat
|
87820-60A00-000 |
— | ||
| replacement | |||||
|
37
|
37
87820-60A10-000
ADJUSTER,RR SEAT SLIDE INNER,R
|
87820-60A10-000 |
— | ||
|
38
|
38
87836-60A00-5PK
KNOB,LOCK LEVER,R
|
87836-60A00-5PK |
— | ||
|
39
|
39
87910-60A00-000
Adjuster, outside lh seat
|
87910-60A00-000 |
— | ||
| replacement | |||||
|
39
|
39
87910-60A10-000
ADJUSTER,RR SEAT SLIDE OUTER,R
|
87910-60A10-000 |
— | ||
|
40
|
40
87920-60A00-000
Adjuster, inside lh seat
|
87920-60A00-000 |
— | ||
| replacement | |||||
|
40
|
40
87920-60A02-000
Adjuster, lh seat inside
|
87920-60A02-000 |
— | ||
|
41
|
41
87936-60A00-5PK
KNOB,LOCK LEVER,L
|
87936-60A00-5PK |
— | ||
|
42
|
42
01734-08255-000
ボルト
|
01734-08255-000 |
— | ||
| replacements | |||||
|
42
|
42
01570-0825A-000 Bolt |
01570-0825A-000 |
from US $1.06 |
||
|
42
|
42
01570-0825B-000 Bolt |
01570-0825B-000 |
from US $1.28 |
||
|
43
|
43
87831-60A10-000
Cover, seat lock outer rh
|
87831-60A10-000 |
— | ||
|
44
|
44
03211-15105-000
Screw
|
03211-15105-000 |
— | ||
| replacement | |||||
|
44
|
44
03211-15103-000 SCREW |
03211-15103-000 |
US $11.40 |
||
|
45
|
45
87834-60A10-000
Out.lock cover,r/h
|
87834-60A10-000 |
— | ||
|
46
|
46
03241-04126-000
Screw l:12
|
03241-04126-000 |
— | ||
| replacement | |||||
|
46
|
46
03242-0412B-000 SCREW |
03242-0412B-000 |
from US $0.84 |
||
|
47
|
47
03241-94105-000
Screw
|
03241-94105-000 |
— | ||
|
48
|
48
87835-60A10-000
Cover, seat outer lock rh
|
87835-60A10-000 |
— | ||
|
49
|
49
87931-60A10-000
Cover, seat lock outer lh
|
87931-60A10-000 |
— | ||
|
50
|
50
87934-60A10-000
Inner cover,l/h
|
87934-60A10-000 |
— | ||
|
51
|
51
87933-60A10-000
Outer cover,l/h
|
87933-60A10-000 |
— | ||
|
52
|
52
87899-60A10-000
ROD,RR SEAT SLIDE ADJUSTER
|
87899-60A10-000 |
— | ||
|
53
|
53
08332-A1105-800
Annrau
|
08332-A1105-800 |
— | ||
|
54
|
54
87840-60A10-000 STRIKER,SEAT LOCK OUTER,R |
87840-60A10-000 |
from US $12.78 |
||
|
55
|
55
87890-60A10-000
ストライカ,リヤシートロック
|
87890-60A10-000 |
— | ||
| replacement | |||||
|
55
|
55
87890-60A11-000
STRIKER,RR SEAT LOCK
|
87890-60A11-000 |
— | ||
|
56
|
56
01517-10205-000
Bolt,lower
|
01517-10205-000 |
— | ||
| replacement | |||||
|
56
|
56
01550-1020A-000 BoltBolt, bal sprocket |
01550-1020A-000 |
from US $0.96 |
||
|
57
|
57
87940-60A10-000 STRIKER,SEAT LOCK OUTER,L |
87940-60A10-000 |
US $14.20 |
||
|
58
|
58
01517-08165-000
Bolt, side
|
01517-08165-000 |
— | ||
| replacements | |||||
|
58
|
58
01550-0816B-000 Bolt |
01550-0816B-000 |
from US $0.91 |
||
|
58
|
58
01550-0816A-000 BoltBolt, rear |
01550-0816A-000 |
from US $0.91 |
||
|
59
|
59
09387-19001-000 RING |
09387-19001-000 |
from US $0.77 |
||
|
60
|
60
87825-60400-000
Operation cable
|
87825-60400-000 |
— | ||
|
61
|
61
09148-06005-000
Nut seat moldin
|
09148-06005-000 |
— | ||
| replacement | |||||
|
61
|
61
09148-06008-000 NUTNut, adjuster knob |
09148-06008-000 |
from US $0.83 |
||
|
62
|
62
87399-60A10-000
プロテクタ,リヤシートバックヒンジ,ライト
|
87399-60A10-000 |
— | ||
| replacement | |||||
|
62
|
62
87399-70E00-000 PROTECTOR,RR SEAT BACK HINGE,R |
87399-70E00-000 |
US $9.16 |
||
|
63
|
63
87799-60A10-000
プロテクタ,リヤシートバックヒンジ,レフト
|
87799-60A10-000 |
— | ||
| replacement | |||||
|
63
|
63
87799-70E00-000 PROTECTOR,RR SEAT BACK HINGE,L |
87799-70E00-000 |
US $9.16 |
||
|
64
|
64
87299-60A10-000
Protector, cushion hinge
|
87299-60A10-000 |
— | ||
| replacement | |||||
|
64
|
64
87299-70E00-000 PROTECTOR,RR SEAT CUSH HINGE |
87299-70E00-000 |
US $5.48 |
||
|
65
|
65
87198-60A10-000
SUPPORT,SEAT LOCK CABLE SIDE,R
|
87198-60A10-000 |
— | ||
|
66
|
66
87398-60A10-000
Fix.cabl.bracket,l/h
|
87398-60A10-000 |
— | ||
|
67
|
67
87199-60A11-000
SUPPROT,RR SEAT LOCK CABLE FR
|
87199-60A11-000 |
— | ||
