Rear windscr.wip (REAR WINDSCR.WIP) Diagram Suzuki SIDEKICK
- Year
- -
- Sales region
- Caribbean
- grade
- JE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35283-00000-000
Rear screenwiper eng
JH,LIFISA |
35283-00000-000 |
— | ||
|
1
|
1
35311-00000-000
Motor assy, rear wiper
JH,BERMAN |
35311-00000-000 |
— | ||
|
1
|
1
38810-A61A0-000
Rear screenwiper eng
|
38810-A61A0-000 |
— | ||
|
2
|
2
01107-06123-000
Bolt 6x1x16
|
01107-06123-000 |
— | ||
| replacements | |||||
|
2
|
2
01500-0612A-000 BOLT |
01500-0612A-000 |
from US $0.76 |
||
|
2
|
2
01500-06123-000
Bolt, front
|
01500-06123-000 |
— | ||
|
2
|
2
01107-06203-000 JoltBolt, front JH |
01107-06203-000 |
US $0.75 |
||
| replacement | |||||
|
2
|
2
01500-0620A-000 BOLTJH |
01500-0620A-000 |
from US $0.76 |
||
|
3
|
3
02007-00000-000
Washer
|
02007-00000-000 |
— | ||
|
3
|
3
08310-11066-000
Nut
JH |
08310-11066-000 |
— | ||
| replacements | |||||
|
3
|
3
08310-0006B-000 NUTNut gear shift link rod JH |
08310-0006B-000 |
from US $0.76 |
||
|
3
|
3
08310-0006A-000 NUTJH |
08310-0006A-000 |
from US $0.76 |
||
|
4
|
4
35284-00000-000
Arm assy
JH,LIFISA |
35284-00000-000 |
— | ||
|
4
|
4
38821-A61A0-000
Arm assy
|
38821-A61A0-000 |
— | ||
|
4
|
4
38821-B61A0-000
Arm assy
JH,BERMAN |
38821-B61A0-000 |
— | ||
|
5
|
5
35285-00000-000
Brush assy
JH,LIFISA |
35285-00000-000 |
— | ||
|
5
|
5
35310-00000-000
Brush assy
JH,BERMAN |
35310-00000-000 |
— | ||
|
5
|
5
38822-A61A0-000
Brush assy
|
38822-A61A0-000 |
— | ||
|
6
|
6
35013-00000-000
Tuyau essuie glace
JH |
35013-00000-000 |
— | ||
|
6
|
6
38842-61A00-000 NOZZLE,RR WASHER |
38842-61A00-000 |
US $15.79 |
||
|
7
|
7
02028-00000-000
Pipe connector
JH |
02028-00000-000 |
— | ||
|
7
|
7
38842-B61A0-000
Pipe connector
|
38842-B61A0-000 |
— | ||
|
8
|
8
38491-61A00-000 HOSE,WASHER L:1300Hose, washer (l:1300->80) |
38491-61A00-000 |
US $5.12 |
||
|
9
|
9
38496-61A00-000 VALVE,CHECK |
38496-61A00-000 |
from US $1.71 |
||
|
10
|
10
38491-61A10-000 HOSE,WASHER L:2100 |
38491-61A10-000 |
US $5.44 |
||
|
11
|
11
38835-61A00-000
HOSE,WASHER
|
38835-61A00-000 |
— | ||
|
12
|
12
38838-82000-000 CONNECTOR |
38838-82000-000 |
US $1.32 |
||
|
13
|
13
38839-82000-000 GROMMET |
38839-82000-000 |
US $8.83 |
||
|
14
|
14
38491-55111-000
ホース,ウォッシャ,L:1000
|
38491-55111-000 |
— | ||
| replacement | |||||
|
14
|
14
38491-61A00-000 HOSE,WASHER L:1300Hose, washer (l:1300->80) |
38491-61A00-000 |
US $5.12 |
||
|
15
|
15
38496-66010-000
コネクタ
|
38496-66010-000 |
— | ||
| replacement | |||||
|
15
|
15
38496-56B00-000 CONNECTOR |
38496-56B00-000 |
from US $1.60 |
||
|
16
|
16
36930-A8200-000
Adhesive sheet
|
36930-A8200-000 |
— | ||
|
17
|
17
03111-15125-000
Tapping screw
|
03111-15125-000 |
— | ||
| replacements | |||||
|
17
|
17
03111-15123-000
SCREW
|
03111-15123-000 |
— | ||
|
17
|
17
03111-1512A-000 Screw |
03111-1512A-000 |
US $10.30 |
||
|
18
|
18
08316-16066-000
Nut
|
08316-16066-000 |
— | ||
| replacement | |||||
|
18
|
18
08316-1006B-000 NUT |
08316-1006B-000 |
from US $0.76 |
||
