Front diff gear (FRONT DIFF GEAR) Diagram Suzuki SIDEKICK
- Year
- -
- Sales region
- All regions
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
0
|
0
27300-85C20-000
Diferential assy
R=8:39 |
27300-85C20-000 |
— | ||
|
1
|
1
27110-56B01-000 FLANGE,UNIVERSAL JOINT |
27110-56B01-000 |
US $131.20 |
||
|
2
|
2
27038-85F10-000
Bevel pinion & gear set, front
R=8:39 |
27038-85F10-000 |
— | ||
|
3
|
3
27315-60A01-000 SPACER,DRIVE BEVEL PINION |
27315-60A01-000 |
US $28 |
||
|
4
|
4
09181-35101-000 SHIM(35X42X0.5)Shim (t:0.5) T:0.50 |
09181-35101-000 |
from US $2.24 |
||
|
4
|
4
09181-35117-000 SHIM(35X42X1.12)T:1.12 |
09181-35117-000 |
US $21.70 |
||
|
4
|
4
09181-35118-000 SHIM(35X42X1.15)T:1.15 |
09181-35118-000 |
US $21.70 |
||
|
4
|
4
09181-35119-000 SHIM(35X42X1.18)T:1.18 |
09181-35119-000 |
US $2.24 |
||
|
4
|
4
09181-35121-000 SHIM(35X42X1.21)T:1.21 |
09181-35121-000 |
US $21.70 |
||
|
4
|
4
09181-35122-000 SHIM(35X42X1.24)T:1.24 |
09181-35122-000 |
US $21.70 |
||
|
4
|
4
09181-35124-000 SHIM(35X42X1.27)T:1.27 |
09181-35124-000 |
US $21.70 |
||
|
4
|
4
09181-35125-000 SHIM(35X42X1.3)T:1.30 |
09181-35125-000 |
US $21.70 |
||
|
5
|
5
21925-85C00-000
Bearing
|
21925-85C00-000 |
— | ||
|
6
|
6
21925-85C30-000
Bearing
|
21925-85C30-000 |
— | ||
|
7
|
7
09283-40027-000 SEAL,OIL(40x72x11x18) |
09283-40027-000 |
US $14.88 |
||
|
8
|
8
09159-20003-000
ナット
|
09159-20003-000 |
— | ||
| replacement | |||||
|
8
|
8
27375-60A00-000 NUT,UNIVERSAL JOINT |
27375-60A00-000 |
US $7.84 |
||
|
9
|
9
27450-85C00-000
Carrier assy, diff front
|
27450-85C00-000 |
— | ||
|
10
|
10
21941-85C30-000
Bolt
|
21941-85C30-000 |
— | ||
|
11
|
11
09103-08247-000 BOLT(8X23) |
09103-08247-000 |
from US $4.13 |
||
|
12
|
12
21941-85C60-000
Bolt
|
21941-85C60-000 |
— | ||
|
13
|
13
08321-A3112-300
Washer
|
08321-A3112-300 |
— | ||
|
14
|
14
09283-35008-000
Seal, oil (35x62x10)
|
09283-35008-000 |
— | ||
| replacement | |||||
|
14
|
14
09283-35052-000 SEAL,OIL(35X62X14.8) |
09283-35052-000 |
from US $10.34 |
||
|
15
|
15
21941-85C10-000
Bolt
|
21941-85C10-000 |
— | ||
|
16
|
16
21925-85C60-000
Bearing
|
21925-85C60-000 |
— | ||
|
17
|
17
27461-83000-000 ADJUSTER,DIFF SIDE BEARING |
27461-83000-000 |
US $7.52 |
||
|
18
|
18
27462-63202-000 PLATE,BEARING LOCK |
27462-63202-000 |
US $2.74 |
||
|
19
|
19
01550-08123-000
Bolt
|
01550-08123-000 |
— | ||
| replacements | |||||
|
19
|
19
01550-0812B-000 BoltPlug, drain |
01550-0812B-000 |
from US $0.96 |
||
|
19
|
19
01550-0812A-000 BOLT |
01550-0812A-000 |
from US $0.91 |
||
|
20
|
20
27471-60A10-000 SHAFT,FRONT DRIVE |
27471-60A10-000 |
US $198.72 |
||
|
21
|
21
44111-65D00-000 RING,SNAP |
44111-65D00-000 |
US $1.60 |
||
|
22
|
22
08133-62067-000 BEARING |
08133-62067-000 |
US $24 |
||
|
23
|
23
08331-41629-000
Circlip
|
08331-41629-000 |
— | ||
| replacement | |||||
|
23
|
23
08331-4162A-000 CIRCLIP |
08331-4162A-000 |
from US $4.26 |
||
|
24
|
24
21941-85C00-000
Bolt
|
21941-85C00-000 |
— | ||
|
25
|
25
08321-A3110-300
Washer plain
|
08321-A3110-300 |
— | ||
|
26
|
26
08310-00103-000
Nut
|
08310-00103-000 |
— | ||
| replacements | |||||
|
26
|
26
08310-0010B-000 NUT |
08310-0010B-000 |
from US $0.80 |
||
|
26
|
26
08310-0010A-000 NUT |
08310-0010A-000 |
from US $0.80 |
||
|
27
|
27
27331-83020-000 PINION,DIFFERENTIAL |
27331-83020-000 |
US $49.40 |
||
| replacements | |||||
|
27
|
27
27331-76A20-000
PINION,DIFFERENTIAL
|
27331-76A20-000 |
— | ||
|
27
|
27
27331-76A21-000 Pinion,differential |
27331-76A21-000 |
from US $43.75 |
||
|
28
|
28
27341-83000-000 GEAR,DIFF |
27341-83000-000 |
US $72.20 |
||
|
29
|
29
09164-15006-000 WASHER |
09164-15006-000 |
US $1.67 |
||
|
30
|
30
27351-64B20-000 SHAFT,DIFF SIDE PINION |
27351-64B20-000 |
US $20.80 |
||
|
31
|
31
09205-05007-000 PIN,SPRING(5X36) |
09205-05007-000 |
US $1.76 |
||
|
32
|
32
27411-60A50-000
Case, diff rh
|
27411-60A50-000 |
— | ||
|
33
|
33
27421-60A02-000
ケース,ディファレンシャル
|
27421-60A02-000 |
— | ||
|
34
|
34
09160-35013-000 WASHER(35X46X0.8)T:0.8 |
09160-35013-000 |
from US $2.74 |
||
|
34
|
34
21945-85C10-000
Washer
T:0.3 |
21945-85C10-000 |
— | ||
