Rear seat (2DR:JX, JLX) Diagram Suzuki SIDEKICK
- Year
- -
- Sales region
- Canada
- transmission
- AT
- grade
- JA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
87105-60AB0-000
Cushion sub assy, rh
|
87105-60AB0-000 |
— | ||
|
2
|
2
87180-60AG0-G75
Cover, cushion rh
JX:92 MODEL,93 MODEL |
87180-60AG0-G75 |
— | ||
|
2
|
2
87180-60AG0-B7V
Cover, cushion rh
JX:94 MODEL,95 MODEL |
87180-60AG0-B7V |
— | ||
|
2
|
2
87180-60AB0-G76
Cover, cushion rh
JLX:92 MODEL,93 MODEL |
87180-60AB0-G76 |
— | ||
|
2
|
2
87180-60AB0-B7S
Cover, cushion rh
JLX:94 MODEL,95 MODEL |
87180-60AB0-B7S |
— | ||
|
2
|
2
87180-60AG0-G94
Cover, cushion rh
JX:92 MODEL,93 MODEL |
87180-60AG0-G94 |
— | ||
|
2
|
2
87180-60AG0-E0M
Cover, cushion rh
JX LIMITED |
87180-60AG0-E0M |
— | ||
|
3
|
3
87291-60A10-000 CUSHION,RR SEAT |
87291-60A10-000 |
US $1.95 |
||
|
4
|
4
02142-05163-000
Bolt
|
02142-05163-000 |
— | ||
| replacements | |||||
|
4
|
4
02142-0516B-000 SCREW |
02142-0516B-000 |
from US $0.80 |
||
|
4
|
4
02142-0516A-000 SCREWScrew |
02142-0516A-000 |
from US $0.76 |
||
|
5
|
5
08322-01053-000
Washer
|
08322-01053-000 |
— | ||
| replacements | |||||
|
5
|
5
08322-0105B-000 WASHER |
08322-0105B-000 |
from US $0.76 |
||
|
5
|
5
08322-0105A-000 WASHERWasher, front |
08322-0105A-000 |
from US $0.80 |
||
|
6
|
6
87191-60AB0-5PK
Board, cushion under rh
(BLACK) |
87191-60AB0-5PK |
— | ||
| replacement | |||||
|
6
|
6
87191-63A10-5PK
BOARD,RR SEAT CUSH UND,R
(BLACK) |
87191-63A10-5PK |
— | ||
|
7
|
7
02142-06163-000
Screw
|
02142-06163-000 |
— | ||
| replacement | |||||
|
7
|
7
02142-0616A-000 SCREW |
02142-0616A-000 |
from US $0.76 |
||
|
8
|
8
09169-06071-000 WASHERWasher, rr side |
09169-06071-000 |
from US $0.96 |
||
|
9
|
9
87305-60AB0-000
Back sub assy, rh
|
87305-60AB0-000 |
— | ||
|
10
|
10
87380-60AG1-G75
Cover, back rh
JX:92 MODEL,93 MODEL |
87380-60AG1-G75 |
— | ||
|
10
|
10
87380-60AG1-B7V
Cover, back rh
JX:94 MODEL,95 MODEL |
87380-60AG1-B7V |
— | ||
|
10
|
10
87380-60AB1-G76
Cover, back rh
JLX:92 MODEL,93 MODEL |
87380-60AB1-G76 |
— | ||
|
10
|
10
87380-60AB1-B7S
Cover, back rh
JLX:94 MODEL,95 MODEL |
87380-60AB1-B7S |
— | ||
|
10
|
10
87380-60AG1-G94
Cover, back rh
JX:92 MODEL,93 MODEL |
87380-60AG1-G94 |
— | ||
|
10
|
10
87380-60AG1-E0M
Cover, back rh
JX LIMITED |
87380-60AG1-E0M |
— | ||
|
11
|
11
87210-60A11-5PK
Reclining assy, rh
->87210-60A12-5PK |
87210-60A11-5PK |
— | ||
| replacement | |||||
|
11
|
11
87210-60A12-5PK
RECLINING,RR SEAT,R
->87210-60A12-5PK |
87210-60A12-5PK |
— | ||
|
11
|
11
87210-60A12-5PK
RECLINING,RR SEAT,R
2S3TA01C N6403721~,2S3TA01V N6403869~ |
87210-60A12-5PK |
— | ||
|
12
|
12
87222-60A10-5PK
カバー,リヤリクライニングアッパ,ライト(ブラック)
(BLACK),2S3TA01C N6403720,~2S3TA01V N6403868 |
87222-60A10-5PK |
— | ||
|
13
|
13
01570-08163-000
Bolt
|
01570-08163-000 |
— | ||
| replacement | |||||
|
13
|
13
01570-0816A-000 BOLT |
01570-0816A-000 |
from US $0.96 |
||
|
14
|
14
01570-08163-000
Bolt
|
01570-08163-000 |
— | ||
| replacement | |||||
|
14
|
14
01570-0816A-000 BOLT |
01570-0816A-000 |
from US $0.96 |
||
|
15
|
15
87211-60A10-5PK KNOB,RR SEAT RECLINING |
87211-60A10-5PK |
US $9.53 |
||
|
16
|
16
87221-60A10-5PK
カバー,リヤシートリクライニングロア,ライト(ブラック
(BLACK) |
87221-60A10-5PK |
— | ||
| replacement | |||||
|
16
|
16
87221-70E00-5PK COVER,RR SEAT RECLINING LWR,R(BLACK) |
87221-70E00-5PK |
US $7.36 |
||
|
17
|
17
08332-11086-000
E ring
|
08332-11086-000 |
— | ||
| replacement | |||||
|
17
|
17
08332-1108A-000 E RING |
08332-1108A-000 |
from US $0.96 |
||
|
18
|
18
87106-60AB0-000
Cushion sub assy, lh
|
87106-60AB0-000 |
— | ||
|
19
|
19
87580-60AG0-G75
Cover, cushion lh
JX:92 MODEL,93 MODEL |
87580-60AG0-G75 |
— | ||
|
19
|
19
87580-60AG0-B7V
Cover, cushion lh
JX:94 MODEL,95 MODEL |
87580-60AG0-B7V |
— | ||
|
19
|
19
87580-60AB0-G76
Cover, cushion lh
JLX:92 MODEL,93 MODEL |
87580-60AB0-G76 |
— | ||
|
19
|
19
87580-60AB0-B7S
Cover, cushion lh
JLX:94 MODEL,95 MODEL |
87580-60AB0-B7S |
— | ||
|
19
|
19
87580-60AG0-G94
Cover, cushion lh
JX:92 MODEL,93 MODEL |
87580-60AG0-G94 |
— | ||
|
19
|
19
87580-60AG0-E0M
Cover, cushion lh
3X LIMITED |
87580-60AG0-E0M |
— | ||
|
20
|
20
87591-60AB1-5PK
Board, cushion under lh
(BLACK) |
87591-60AB1-5PK |
— | ||
|
21
|
21
87306-60AB0-000
Back sub assy, lh
|
87306-60AB0-000 |
— | ||
|
22
|
22
87780-60AG1-G75
Cover, back lh
JX:92 MODEL,93 MODEL |
87780-60AG1-G75 |
— | ||
|
22
|
22
87780-60AG1-B7V
Cover, back lh
JX:94 MODEL,95 MODEL |
87780-60AG1-B7V |
— | ||
|
22
|
22
87780-60AB1-G76
Cover, back lh
JLX:92 MODEL,93 MODEL |
87780-60AB1-G76 |
— | ||
|
22
|
22
87780-60AB1-B7S
Cover, back lh
JLX:94 MODEL,95 MODEL |
87780-60AB1-B7S |
— | ||
|
22
|
22
87780-60AG1-G94
Cover, back lh
JX:92 MODEL,93 MODEL |
87780-60AG1-G94 |
— | ||
|
22
|
22
87780-60AG1-E0M
Cover, back lh
JX LIMITED |
87780-60AG1-E0M |
— | ||
|
23
|
23
87610-60A11-5PK
リクライニングアッシ,リヤシート,レフト(ブラック)
->87610-60A12-5PK |
87610-60A11-5PK |
— | ||
| replacement | |||||
|
23
|
23
87610-60A12-5PK
RECLINING,RR SEAT,L
->87610-60A12-5PK |
87610-60A12-5PK |
— | ||
|
23
|
23
87610-60A12-5PK
RECLINING,RR SEAT,L
2S3TA01C N6403721~,2S3TA01V N6403869~ |
87610-60A12-5PK |
— | ||
|
24
|
24
87622-60A10-5PK
カバー,リヤリクライニングアッパ,レフト(ブラック)
(BLACK),2S3TA01C N6403720,~2S3TA01V N6403868 |
87622-60A10-5PK |
— | ||
|
25
|
25
87621-60A10-5PK
カバー,リヤリクライニングロア,レフト(ブラック)
(BLACK) |
87621-60A10-5PK |
— | ||
| replacement | |||||
|
25
|
25
87621-70E00-5PK COVER,RR SEAT RECLINING LWR,L(BLACK) |
87621-70E00-5PK |
US $7.36 |
||
|
26
|
26
87144-60A10-000 PIN,REAR SEAT STOPPER ROD |
87144-60A10-000 |
US $4.75 |
||
|
27
|
27
87277-60A10-000 WASHER,STOPPER ROD PIN |
87277-60A10-000 |
US $1.58 |
||
|
28
|
28
08322-21083-000 ワッシャ |
08322-21083-000 |
US $0.54 |
||
| replacements | |||||
|
28
|
28
08322-0108A-000 WASHER |
08322-0108A-000 |
from US $0.80 |
||
|
28
|
28
08322-0108B-000 WASHER |
08322-0108B-000 |
from US $0.80 |
||
|
29
|
29
09148-08002-000 NUT |
09148-08002-000 |
US $11 |
||
|
30
|
30
87270-60AB1-000
Rod, seat stopper
|
87270-60AB1-000 |
— | ||
| replacement | |||||
|
30
|
30
87270-60A11-000
STOPPER,REAR SEAT
|
87270-60A11-000 |
— | ||
|
31
|
31
87278-60AB0-000
Pin
|
87278-60AB0-000 |
— | ||
| replacement | |||||
|
31
|
31
87278-60A11-000 PIN,REAR SEAT STOPPER |
87278-60A11-000 |
US $1.80 |
||
|
32
|
32
09148-03011-000 NUT |
09148-03011-000 |
from US $2.84 |
||
|
33
|
33
87279-60AB1-000
Holder, stopper rod
|
87279-60AB1-000 |
— | ||
| replacement | |||||
|
33
|
33
87279-60A11-000 HOLDER,RR SEAT STOPPER |
87279-60A11-000 |
US $5.85 |
||
|
34
|
34
08322-01063-000
Washer
|
08322-01063-000 |
— | ||
| replacement | |||||
|
34
|
34
08322-0106B-000 WASHER |
08322-0106B-000 |
from US $0.76 |
||
|
35
|
35
09148-06005-000
Nut seat moldin
|
09148-06005-000 |
— | ||
| replacement | |||||
|
35
|
35
09148-06008-000 NUTNut, adjuster knob |
09148-06008-000 |
from US $0.83 |
||
|
36
|
36
87810-60A10-000
ADJUSTER,RR SEAT SLIDE OUTER,R
|
87810-60A10-000 |
— | ||
|
37
|
37
87820-60A10-000
ADJUSTER,RR SEAT SLIDE INNER,R
|
87820-60A10-000 |
— | ||
|
38
|
38
87836-60A00-5PK
KNOB,LOCK LEVER,R
|
87836-60A00-5PK |
— | ||
|
39
|
39
87910-60A10-000
ADJUSTER,RR SEAT SLIDE OUTER,R
|
87910-60A10-000 |
— | ||
|
40
|
40
87920-60A10-000
Adjuster, inside lh seat
|
87920-60A10-000 |
— | ||
|
41
|
41
87936-60A00-5PK
KNOB,LOCK LEVER,L
|
87936-60A00-5PK |
— | ||
|
42
|
42
01550-08163-000
Bolt, holder
|
01550-08163-000 |
— | ||
| replacements | |||||
|
42
|
42
01550-0816B-000 BOLT |
01550-0816B-000 |
from US $0.91 |
||
|
42
|
42
01550-0816A-000 BOLTBolt, rear |
01550-0816A-000 |
from US $0.91 |
||
|
43
|
43
87831-60A10-5PK
COVER,RR SEAT LOCK OUTER,R
(BLACK) |
87831-60A10-5PK |
— | ||
|
44
|
44
03211-05103-000
New Genuine Part
|
03211-05103-000 |
— | ||
| replacement | |||||
|
44
|
44
03211-0510A-000 SCREW |
03211-0510A-000 |
US $0.80 |
||
|
45
|
45
87834-60A10-5PK
COVER,RR SEAT LOCK INNER,R
(BLACK) |
87834-60A10-5PK |
— | ||
|
46
|
46
03241-04123-000
Screw
|
03241-04123-000 |
— | ||
| replacement | |||||
|
46
|
46
03242-0412B-000 SCREW |
03242-0412B-000 |
from US $0.80 |
||
|
47
|
47
03241-04123-000
Screw
|
03241-04123-000 |
— | ||
| replacement | |||||
|
47
|
47
03242-0412B-000 SCREW |
03242-0412B-000 |
from US $0.80 |
||
|
48
|
48
87835-60A10-5PK
COVER,RR SEAT OUTER LOCK,R
(BLACK) |
87835-60A10-5PK |
— | ||
|
49
|
49
87931-60A10-5PK
COVER,RR SEAT LOCK OUTER,L
(BLACK) |
87931-60A10-5PK |
— | ||
|
50
|
50
87934-60A10-5PK
COVER,RR SEAT LOCK INNER,L
(BLACK) |
87934-60A10-5PK |
— | ||
|
51
|
51
87935-60A10-5PK
COVER,RR SEAT OUTER LOCK,L
(BLACK) |
87935-60A10-5PK |
— | ||
|
52
|
52
87899-60A10-000
ROD,RR SEAT SLIDE ADJUSTER
|
87899-60A10-000 |
— | ||
|
53
|
53
08332-11055-000
E-ring
|
08332-11055-000 |
— | ||
| replacement | |||||
|
53
|
53
08332-1105A-000 E RING |
08332-1105A-000 |
from US $0.91 |
||
|
54
|
54
87840-60A10-000 STRIKER,SEAT LOCK OUTER,R |
87840-60A10-000 |
US $38.40 |
||
|
55
|
55
87890-60A11-000
STRIKER,RR SEAT LOCK
|
87890-60A11-000 |
— | ||
|
56
|
56
01550-10203-000
Bolt
|
01550-10203-000 |
— | ||
| replacement | |||||
|
56
|
56
01550-1020A-000 BOLTBolt, bal sprocket |
01550-1020A-000 |
from US $0.96 |
||
|
57
|
57
87940-60A10-000
STRIKER,SEAT LOCK OUTER,L
|
87940-60A10-000 |
— | ||
|
58
|
58
01570-08203-000
Bolt
|
01570-08203-000 |
— | ||
| replacements | |||||
|
58
|
58
01570-0820B-000 Bolt |
01570-0820B-000 |
US $17.30 |
||
|
58
|
58
01570-0820A-000 BOLT |
01570-0820A-000 |
from US $0.96 |
||
|
59
|
59
09387-19001-000 RING |
09387-19001-000 |
US $1.76 |
||
|
60
|
60
87898-60A20-000
Label, seat caution
|
87898-60A20-000 |
— | ||
| replacement | |||||
|
60
|
60
87898-56B20-000
Label, seat caution
|
87898-56B20-000 |
— | ||
