Front suspension (FRONT SUSPENSION) Diagram Suzuki SIERRA
- Year
- -
- Sales region
- All regions
- grade
- S
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
41110-83301-000
SPRING ASSY,FRONT
<-41110-83300 |
41110-83301-000 |
— | ||
|
2
|
2
42110-80010-000 BUMPER,FR SPRING |
42110-80010-000 |
US $23.55 |
||
|
3
|
3
01107-08163-000
Bolt m8x1.25x16
|
01107-08163-000 |
— | ||
| replacements | |||||
|
3
|
3
01500-0816B-000 BoltBolt |
01500-0816B-000 |
from US $0.80 |
||
|
3
|
3
01500-08163-000
Bolt
|
01500-08163-000 |
— | ||
|
4
|
4
08321-21083-000
Washr,lk8.2x15.
|
08321-21083-000 |
— | ||
| replacements | |||||
|
4
|
4
08321-0108B-000 WASHER,LOCK |
08321-0108B-000 |
from US $0.76 |
||
|
4
|
4
08321-0108A-000 WASHER,LOCK |
08321-0108A-000 |
from US $0.80 |
||
|
5
|
5
41230-83301-000
Seat, spring rh
|
41230-83301-000 |
— | ||
|
6
|
6
41240-83001-000 SEAT,FR SPRING,L |
41240-83001-000 |
US $53.20 |
||
|
7
|
7
41411-83010-000 U-BOLT,FR SPRING,R86 MODEL |
41411-83010-000 |
US $12.77 |
||
|
8
|
8
41411-83010-000 U-BOLT,FR SPRING,R87 MODEL,88 MODEL |
41411-83010-000 |
US $12.77 |
||
|
9
|
9
41411-83020-000 U-BOLT,FR SPRING INR,R87 MODEL,88 MODEL |
41411-83020-000 |
US $12.59 |
||
| replacement | |||||
|
9
|
9
41411-83010-000 U-BOLT,FR SPRING,R87 MODEL,88 MODEL |
41411-83010-000 |
US $12.77 |
||
|
10
|
10
41411-83000-000 U-BOLT,FR SPRING,L |
41411-83000-000 |
US $18.24 |
||
|
11
|
11
08321-31123-000
ロックワッシャ
|
08321-31123-000 |
— | ||
| replacement | |||||
|
11
|
11
08321-0112A-000 WASHER,LOCK |
08321-0112A-000 |
from US $0.76 |
||
|
12
|
12
08310-12123-000
ナット
|
08310-12123-000 |
— | ||
| replacement | |||||
|
12
|
12
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
|
13
|
13
09305-13002-000 BUSH |
09305-13002-000 |
from US $1.37 |
||
|
14
|
14
41461-77300-000 PLATE,INNER<-41461-79000 |
41461-77300-000 |
US $11.52 |
||
|
15
|
15
41462-77300-000 PLATE,OUTER<-41462-79000 |
41462-77300-000 |
US $11.52 |
||
|
16
|
16
41463-82000-000 PIN,SHACKLE |
41463-82000-000 |
US $6.08 |
||
|
17
|
17
08321-31103-000
ロックワッシャ
|
08321-31103-000 |
— | ||
| replacements | |||||
|
17
|
17
08321-0110A-000 WASHER,LOCK |
08321-0110A-000 |
from US $0.80 |
||
|
17
|
17
08321-0110B-000 WASHER,LOCKWasher, knuckle end |
08321-0110B-000 |
from US $0.80 |
||
|
18
|
18
08310-12103-000
Nut
|
08310-12103-000 |
— | ||
| replacements | |||||
|
18
|
18
08310-0010B-000 NUT |
08310-0010B-000 |
from US $0.80 |
||
|
18
|
18
08310-0010A-000 NUT |
08310-0010A-000 |
from US $0.80 |
||
|
19
|
19
41331-62020-000 BUSH |
41331-62020-000 |
from US $12.76 |
||
|
20
|
20
09100-12025-000
ボルト,12X92
|
09100-12025-000 |
— | ||
| replacements | |||||
|
20
|
20
09103-12044-000 BOLT(12X87) |
09103-12044-000 |
from US $2.27 |
||
|
20
|
20
09103-12048-000 BOLT(12X90) |
09103-12048-000 |
US $8.48 |
||
|
21
|
21
09180-12035-000 SPACER(12X16X64.5) |
09180-12035-000 |
from US $2.13 |
||
|
22
|
22
08321-31123-000
ロックワッシャ
|
08321-31123-000 |
— | ||
| replacement | |||||
|
22
|
22
08321-0112A-000 WASHER,LOCK |
08321-0112A-000 |
from US $0.76 |
||
|
23
|
23
08310-12123-000
ナット
|
08310-12123-000 |
— | ||
| replacement | |||||
|
23
|
23
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
|
24
|
24
41600-80001-000
アブソーバアッシ,ショック,フロント
|
41600-80001-000 |
— | ||
| replacements | |||||
|
24
|
24
41600-82C01-000 ABSORBER ASSY,FR SHOCK |
41600-82C01-000 |
US $209.60 |
||
|
24
|
24
08310-0010B-000 NUT |
08310-0010B-000 |
from US $0.80 |
||
|
24
|
24
08310-0010A-000 NUT |
08310-0010A-000 |
from US $0.80 |
||
|
24
|
24
08310-00103-000
Nut
|
08310-00103-000 |
— | ||
|
25
|
25
09320-16006-000
ブッシュ
|
09320-16006-000 |
— | ||
| replacement | |||||
|
25
|
25
41781-52010-000 BUSHING,SHOCK ABSORBER NO.1 |
41781-52010-000 |
US $2.24 |
||
|
26
|
26
09320-10024-000 CUSHION |
09320-10024-000 |
from US $2.48 |
||
|
27
|
27
09169-15002-000 WASHER |
09169-15002-000 |
US $7.68 |
||
|
28
|
28
09165-10002-000 WASHER |
09165-10002-000 |
from US $2.08 |
||
|
29
|
29
08310-12103-000
Nut
|
08310-12103-000 |
— | ||
| replacements | |||||
|
29
|
29
08310-0010B-000 NUT |
08310-0010B-000 |
from US $0.80 |
||
|
29
|
29
08310-0010A-000 NUT |
08310-0010A-000 |
from US $0.80 |
||
|
30
|
30
08310-22103-000 ナット |
08310-22103-000 |
US $1.07 |
||
| replacements | |||||
|
30
|
30
08310-0010A-000 NUT |
08310-0010A-000 |
from US $0.80 |
||
|
30
|
30
08310-0010B-000 NUT |
08310-0010B-000 |
from US $0.80 |
||
|
31
|
31
08322-21163-000
New Genuine Part
|
08322-21163-000 |
— | ||
| replacement | |||||
|
31
|
31
08322-0116A-000 WASHER |
08322-0116A-000 |
from US $0.80 |
||
|
32
|
32
09160-12073-000 WASHER(12.5X32X2.3)Washer (12.5x32x2.3) |
09160-12073-000 |
from US $0.96 |
||
|
33
|
33
08310-12123-000
ナット
|
08310-12123-000 |
— | ||
| replacement | |||||
|
33
|
33
08310-0012A-000 NUT |
08310-0012A-000 |
from US $0.76 |
||
