Clutch (CLUTCH) Diagram Suzuki SIERRA
- Year
- -
- Sales region
- Pacific
- grade
- JA
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
12111-A63B0-000
Piston
TYPE 2,TYPE 3 |
12111-A63B0-000 |
— | ||
|
1
|
1
12111-83000-0B0
PISTON,STD MARK 2
H 104555 |
12111-83000-0B0 |
— | ||
|
2
|
2
12140-82051-050
Ring set, piston
|
12140-82051-050 |
— | ||
| replacement | |||||
|
2
|
2
12140-82X50-050 RING SET,PISTON OS:0.50Ring set, piston (os:0.50) |
12140-82X50-050 |
US $67.48 |
||
|
3
|
3
12151-A8200-000
Piston Pin
|
12151-A8200-000 |
— | ||
|
4
|
4
12160-86002-000
Connrod assy
|
12160-86002-000 |
— | ||
| replacement | |||||
|
4
|
4
12160-86021-000 CONNROD ASSY |
12160-86021-000 |
US $217.60 |
||
|
5
|
5
09159-08033-000 NUT |
09159-08033-000 |
from US $1.34 |
||
|
7
|
7
12221-82600-000
CRANKSHAFT
H 104555 |
12221-82600-000 |
— | ||
|
9
|
9
12300-82820-000
Bearing set, crank thrust (STD)
|
12300-82820-000 |
— | ||
| replacement | |||||
|
9
|
9
12300-60840-000 BEARING SET,CRANK THRUST (STD) |
12300-60840-000 |
from US $9.70 |
||
|
10
|
10
09283-32026-000
オイルシール,32X47X6
|
09283-32026-000 |
— | ||
| replacement | |||||
|
10
|
10
09283-32042-000 SEAL,OIL(32X47X6) |
09283-32042-000 |
from US $8.03 |
||
|
11
|
11
12611-83000-000
Pulley,crankshaft
W/AIR CORD. |
12611-83000-000 |
— | ||
|
12
|
12
09103-A1200-800
Fastening screw
|
09103-A1200-800 |
— | ||
|
13
|
13
12618-60B00-000
BOLT,CRANK PULLEY
|
12618-60B00-000 |
— | ||
|
14
|
14
08341-31059-000 KEYKey |
08341-31059-000 |
from US $1.49 |
||
|
15
|
15
12631-82000-000 PULLEY,CRANK TIMING BELT |
12631-82000-000 |
US $91.20 |
||
|
16
|
16
12635-78401-000 GUIDE,TIMING BELT |
12635-78401-000 |
from US $3.65 |
||
|
17
|
17
12620-83000-000
FLYWHEEL
|
12620-83000-000 |
— | ||
|
18
|
18
04221-06129-000 PIN |
04221-06129-000 |
from US $0.96 |
||
|
19
|
19
09103-10068-000
Bolt
|
09103-10068-000 |
— | ||
| replacement | |||||
|
19
|
19
09100-10275-000 BOLT(10X18.5) |
09100-10275-000 |
US $1.44 |
||
|
20
|
20
12623-A60A0-000
Thrust bearing
|
12623-A60A0-000 |
— | ||
|
21
|
21
09283-68002-000 SEAL,OIL(68X86X8) |
09283-68002-000 |
from US $22.68 |
||
|
22
|
22
11341-82000-000
Housing, oil seal
|
11341-82000-000 |
— | ||
| replacement | |||||
|
22
|
22
11341-82001-000
HOUSING,OIL SEAL
|
11341-82001-000 |
— | ||
|
23
|
23
11349-A8201-000
Gasket
TYPE 1 |
11349-A8201-000 |
— | ||
|
23
|
23
11349-B60A1-000
Gasket
TYPE 2,TYPE 3 |
11349-B60A1-000 |
— | ||
|
24
|
24
01517-06203-000
Bolt
|
01517-06203-000 |
— | ||
| replacements | |||||
|
24
|
24
01550-0620B-000 BOLTBolt, inspection cap |
01550-0620B-000 |
from US $0.76 |
||
|
24
|
24
01550-0620A-000 BOLT |
01550-0620A-000 |
from US $0.76 |
||
|
25
|
25
01517-06253-000
ボルト
|
01517-06253-000 |
— | ||
| replacements | |||||
|
25
|
25
01550-0625A-000 BOLTBolt |
01550-0625A-000 |
from US $0.96 |
||
|
25
|
25
01550-0625B-000 BOLTBolt, head cover |
01550-0625B-000 |
from US $0.91 |
||
|
26
|
26
04211-A0910-900
Coupille centrage
|
04211-A0910-900 |
— | ||
|
27
|
27
12351-A8200-000
S/ rest semi-bearing
|
12351-A8200-000 |
— | ||
