Air cleaner (J20B:CVT) Diagram Suzuki SX4
- Year
- -
- Sales region
- Africa
- drive
- 2WD
- transmission
- MT
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
13700-54L00-000 CLEANER ASSY,AIR |
13700-54L00-000 |
US $213.44 |
||
|
2
|
2
13780-54L00-000 ELEMENT,AIR CLEANER |
13780-54L00-000 |
US $21.44 |
||
|
3
|
3
13755-80J00-000 CLIP,AIR CLEANER |
13755-80J00-000 |
US $5.63 |
||
|
4
|
4
13877-80J00-000 COLLAR,AIR CLNR |
13877-80J00-000 |
US $5 |
||
|
5
|
5
13878-80J00-000 CUSHION,AIR CLNR |
13878-80J00-000 |
US $3.72 |
||
|
6
|
6
13723-54L00-000
GROMMET,AIR CLEANER
|
13723-54L00-000 |
— | ||
|
7
|
7
13733-54L10-000 BRACKET,AIR CLNR |
13733-54L10-000 |
US $51.15 |
||
|
8
|
8
13733-54L20-000 BRACKET,AIR CLNR |
13733-54L20-000 |
US $7.80 |
||
|
9
|
9
13761-54L00-000 RESONATOR,AIR CLNR OUT HOSE |
13761-54L00-000 |
US $14.68 |
||
|
10
|
10
13881-54L00-000
HOSE,AIR CLEANER OUTLET
|
13881-54L00-000 |
— | ||
|
11
|
11
01550-0620A-000 BOLT |
01550-0620A-000 |
from US $0.76 |
||
|
12
|
12
09402-82511-000 CLAMP |
09402-82511-000 |
US $65.90 |
||
|
13
|
13
01550-0612A-000 BOLT |
01550-0612A-000 |
from US $0.76 |
||
|
14
|
14
01550-0816A-000 BOLTBolt, rear |
01550-0816A-000 |
from US $0.91 |
||
|
15
|
15
13765-54L00-000 PIPE,AIR CLNR SUCTION |
13765-54L00-000 |
US $48.21 |
||
|
16
|
16
13766-54L00-000 HOSE,AIR SUCTION |
13766-54L00-000 |
US $38.27 |
||
|
17
|
17
13811-54L00-000 BRACKET,SUCT PIPE |
13811-54L00-000 |
US $8.02 |
||
|
18
|
18
02162-0616A-000 SCREW |
02162-0616A-000 |
from US $1.04 |
||
| replacement | |||||
|
18
|
18
02162-0616B-000 SCREWBolt, adjust |
02162-0616B-000 |
from US $0.80 |
||
|
19
|
19
02162-0612A-000 SCREWBolt, bracket |
02162-0612A-000 |
from US $0.80 |
||
|
20
|
20
13800-54L00-000 SENSOR ASSY, MAF |
13800-54L00-000 |
from US $290.27 |
||
|
21
|
21
03511-0412A-000 SCREW |
03511-0412A-000 |
from US $0.76 |
||
