Mt transmission case (5MT) Diagram Suzuki SX4
- Year
- -
- Sales region
- Africa
- drive
- 4WD
- transmission
- MT
- grade
- STD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
11851-50F00-000 HOOK,ENGINE |
11851-50F00-000 |
US $3.20 |
||
|
2
|
2
24711-80J20-000 CASE,TRANSAXLE,R |
24711-80J20-000 |
US $510.40 |
||
|
3
|
3
24721-79J00-000
Case,transaxle left
|
24721-79J00-000 |
— | ||
| replacement | |||||
|
3
|
3
24721-79J02-000 CASE,TRANSAXLE,L |
24721-79J02-000 |
US $542.08 |
||
|
4
|
4
24725-59J20-000 PLATE,LEFT CASE |
24725-59J20-000 |
US $26.68 |
||
|
5
|
5
24730-54G20-000
Cover,transaxle side
|
24730-54G20-000 |
— | ||
| replacement | |||||
|
5
|
5
24730-54G21-000 COVER,TRANSAXLE SIDE |
24730-54G21-000 |
US $41.81 |
||
|
6
|
6
24810-70C00-000 GUTTER,INPUT OIL |
24810-70C00-000 |
US $5.30 |
||
|
7
|
7
24815-79J00-000 PLATE,BREATHER COVER |
24815-79J00-000 |
US $2.43 |
||
|
8
|
8
24821-59J00-000 UNION,BREATHER |
24821-59J00-000 |
US $2.43 |
||
|
9
|
9
24825-63J00-000 HOSE,BREATHER |
24825-63J00-000 |
US $3.04 |
||
|
10
|
10
27991-65D01-000 PLUG,BREATHER |
27991-65D01-000 |
US $1.92 |
||
|
11
|
11
09103-06285-000 BOLT(6X12)Bolt (6x12) |
09103-06285-000 |
from US $1.28 |
||
|
12
|
12
09117-08050-000 BOLT(8X20) |
09117-08050-000 |
US $2.24 |
||
|
13
|
13
09135-06027-000 BOLT(6X12) |
09135-06027-000 |
from US $1.07 |
||
|
14
|
14
09168-14011-000 GASKET(14X20X1.5) |
09168-14011-000 |
from US $1.56 |
||
|
15
|
15
09206-15001-000 PIN(12.4X15X17) |
09206-15001-000 |
US $29.80 |
||
|
16
|
16
09246-16010-000
PLUG
|
09246-16010-000 |
— | ||
| replacement | |||||
|
16
|
16
09246-16021-000 Plug,t/m Oil Drain |
09246-16021-000 |
from US $3.26 |
||
|
17
|
17
09247-14048-000 PLUG |
09247-14048-000 |
US $12.50 |
||
|
18
|
18
09250-26005-000 CAP(OD:36) |
09250-26005-000 |
US $6.56 |
||
|
19
|
19
01550-0820A-000 BOLTBolt, funnel bracket |
01550-0820A-000 |
from US $0.96 |
||
|
20
|
20
01550-0840A-000 BOLT |
01550-0840A-000 |
from US $1.12 |
||
|
21
|
21
01550-1035A-000 BOLTBolt, fr fork upper |
01550-1035A-000 |
from US $5.06 |
||
|
22
|
22
01550-1245A-000 BOLT |
01550-1245A-000 |
US $1.44 |
||
|
23
|
23
01550-1255A-000 Bolt |
01550-1255A-000 |
US $21.70 |
||
|
24
|
24
01550-1275A-000 BOLT |
01550-1275A-000 |
US $1.92 |
||
|
25
|
25
04211-13149-000 PIN |
04211-13149-000 |
from US $3.20 |
||
|
26
|
26
08316-1012A-000 NUT |
08316-1012A-000 |
from US $0.96 |
||
|
27
|
27
37610-76G10-000 SWITCH ASSY,BACK UP |
37610-76G10-000 |
from US $13.48 |
||
|
28
|
28
09280-11002-000 O RING(D:1.9,ID:11.4) |
09280-11002-000 |
from US $0.65 |
||
